- Page 1 Installation and Homeowners Guide Veil Bathroom Heater S600 S600 K-21463T-0(Aircare) K-21463T-X-0(Cloud) K-21465T-0 KOHLER CHINA INVESTMENT CO., LTD NO.158, JIANG CHANG SAN ROAD, JING'AN DISTRICT, SHANGHAI, PRC POST CODE: 200436 200436 1367356-T01-A...
-
Page 2: Before You Begin
Unit: mm Junction Box Cover Ventilation Outlet 289 268 Inlet(where filter mat is installed) Hot Air Outlet Kohler Logo Kohler reserves the right to change marked dimensions without prior notice. © Copyright Kohler China Investment Co., Ltd. 2019 1367356-T01-A © 2019... -
Page 3: Specifications
SPECIFICATIONS K-21463T-0/K-21463T-X-0/ K-21463T-0/K-21463T-X-0/ Model K-21465T-0 K-21465T-0 Voltage/Frequency 220V~/50Hz 220V~/50Hz Rated Input Power 2750W 2750W Heater Power 2731W 2731W Fan Power Dry Clothing Power 2600W(Hot)/60W(Cool) 2600W( )/60W( Ventilation Power Air-care Power 31W( K-21463T-0/K-21463T-X-0 Only 31W( K-21463T-0/K-21463T-X-0) Lighting Power 19W 2 (108pcx 0.2W) 19W 2 (108 0.2W) Ventilation Volume... - Page 4 K-21465T-0 HOT MOTOR BLUE YELLOW/GREEN CAPACITOR OVER CURRENT FUSE 220V 50Hz BLUE THERMOSTAT THERMAL FUSE VENT MOTOR BLUE CAPACITOR ALL-POLE SWITCH (OPTIONAL) HEATER 1 BROWN BLUE HEATER 2 BROWN WHITE STEPPER MOTOR THE RATE OF THE POWER SWITCH GRAY BLUE MUST NOT BE LOWER THAN 250V 20A PINK WHITE...
-
Page 5: Preparation Before The Installation
PREPARATIONS BEFORE INSTALLATION A. Preparation before the installation 1. Open the hole of outlet window Make sure that the outlet window s position (it should be lower than the outlet of the bathroom heater to prevent the water come back to the bathroom heater from the outlet window), and open a round hole on the wall. -
Page 6: Packing List
C. Packing List 1367446 1367441 100 Air Outlet Window Fixed Column Assy. M6 Expansion Head 10 Expansion Pipe 1367447 100 Air Exhasut Pipe M6 Screw Rod Note: Initial Length: 140mm Stretch Length: 2000mm 140mm 2000mm 1285549 1285553 Clamp Lock Assy. / M6 Butterfly Nut 6 Washer 6Spring Washer... -
Page 7: Installation
INSTALLATION Caution before installation: 200mm The installed product must be 200mm or above away from curtains or other combustible materials. The distance between the ceiling where the product is 200mm mounted and the roof shall be 200mm or above. Ensure that the gap between the product edge and the 300mm wall is 300mm or above. - Page 8 2. Fix the power cord to the bathroom heater (1) Remove the screw on the wiring cover plate. (2) Open the wiring cover plate. (3) Lift the terminal protection cover. (4) Loosen the screw fixing the power cord clip. (5) Loosen the screw on the wiring terminal, insert the power cord (not supplied) connected to the indoor fixed line into the wiring terminal, tighten the wring terminal screw.
- Page 9 (3) Fix the suspender on the right position of the cement board, use the install template to adjust the M6 nut on the suspender. M6 Butterfly Nut M6 Nut Suspender 6 Washer Cement Board 6 Spring Washer M6 Nut Ceiling Surface Install template datum line (4) Fix the suspension bracket on the suspender by 8 8 BTP4*8...
- Page 10 (6) Install the air exhaust pipe 1) Fix the air exhaust pipe on the ventilation outlet assy. by the clamp. The pipeline connected to outside of the room must be slanted to prevent rain or condensed water from flowing backwards. Ventilation Outlet Assy.
- Page 11 4. Installing the Main Body Method 2 Ceiling mounting has not been installed. (1) Positioning and installation of the suspenders 1) Put the installation template to the position of fixed hole B on where the bathroom heater is going to be installed.
- Page 12 (5) Install the air exhaust pipe 1) Fix the air exhaust pipe on the ventilation outlet assy. by the clamp. The pipeline connected to outside of the room must be slanted to prevent rain or condensed water from flowing backwards. Ventilation Outlet Assy.
-
Page 13: Button Function
USER'S GUIDE A. Before Using Before using the remote control, please take off the battery insulating strip. Before using the remote controller, please wait for 5 seconds after the power source is connected. Battery Insulating Strip B. Paring Please press "Light" and "Light Off" together within 3 minutes after connecting to power source. - Page 14 D. Display Information Current Hour Minute Celsius Humidity HEATER HOT DRY COOL DRY 24H VENTILATION VENTILATION AIR-CARE AIR FLOW FIXED SWING MODE E. Activated mode During the standby mode, press any button to the activated mode , K-21463T-0 and K-21463T-X-0 will K-21463T-0 K-21463T-X-0 display room temperature and humidity, K-21465T-0 will...
-
Page 15: Temperature Setting
G. Temperature Setting (Only K-21463T-0/ ( K-21463T-0/K-21463T-X-0) K-21463T-X-0) Press "Heater" after the remote control is activated, and ° 40 C the screen will show temperature setting. Pressing "+" or "-" can increase or decrease the heating temperature. Pressing "Heater" again within 10 seconds will turn to time set. -
Page 16: Important Consumer Information
6. All installation staff should be well familiar with installation instruction. Notice: Troubleshooting needs to be done by professional of KOHLER CHINA. Users are not suggested to do this without help. Please remember that the checking and repairs done by users themselves could easily cause damage to the machine or cause physical harm to the person.
