MTI RAPIDDOC PRO KIOSK Installation Manual page 6

REMOVING THE ENCLOSURE (OR TABLET) VIA RFID
1 Place the RFID Access Card until the base clicks. NOTE:
Do not grab the tablet until after you hear the click.
REMOVING THE ENCLOSURE (OR TABLET) MANUALLY
1
Insert the Red Handle Tool into the security screw hole
at the side of the RapidDoc
Turn the Red Handle Tool clockwise until resistance is
felt (about halfway) and hold. NOTE: Do not grab the
tablet until after you twist the Red Handle Tool.
www.MTIGS.com | T:801.653.3807
-CONTROLLED DOCUMENT-
®
base-disk under the tablet.
063-00180 E-0
2
Remove the tablet using one hand on the bottom left or
right hand corner.
2
While holding the Red Handle Tool, remove the tablet
using one hand on the bottom left or right hand corner.
MTI P/N 063-00180 rev E ©2021 MTI All Rights Reserved
Status: Approved ECO-112676
6
