REMOVING THE LID

1
Lift up the front of the lid (above the ArmorActive logo). Lift up the front of the lid (above the ArmorActive logo).
CABLE ACCESS COVER
1
With the lid off of the kiosk base, place the Cable
Access Cover into the opening from the inside.

REPLACING THE LID

1
Tuck the RFID cable into the void in the base and
place the lid on the kiosk base.
www.MTIGS.com | T:801.653.3807
-CONTROLLED DOCUMENT- 063-00180 E-0 Status: Approved
®
PRO KIOSK INSTALLATION GUIDE
RAPIDDOC
2
Slide the lid back, using care when removing the lid as Slide the lid back, using care when removing the lid as
not to damage the RFID cable. not to damage the RFID cable.
2
Press until it clicks into place.
2
Slide the lid into place and press down on the lid.
