6. Appendix A. JTAG Pin-Out

SCR1 JTAG port is routed to the onboard Pmod connector JD in accordance with
Table 1. SCR1 JTAG Pin-Out
Net
TRSTn
TCK
TDO
TDI
SRSTn
TMS
JD bit
2
3
4
5
6
7
"Table
1".
PMod JD pin
3
4
7
8
9
10
13
