1: xmodem load @addr
g: start @addr
d: dump mem
m: modify mem
i: platform info
:
2. Press button "1"
3. Enter required starting TCM address (in hex), and press "Enter". Terminal starts to print "C"
character periodically, indicating receiver's requests to transmitter in accordance with
XMODEM protocol.
xload @addr
addr: f0000000
CCCCCCCC
4. In terminal program, open XMODEM upload menu. In minicom terminal you need to press
"Ctrl+A" and press "S". Then select "xmodem":
 +-[Upload]--+
 | zmodem
|
 | ymodem
|
 | xmodem
|
 | kermit
|
 | ascii
|
 +-----------+
5. In this example we use binary file with Dhrystone benchmark, which could be found in SDK
repository by the following path:
<SDK_HOME>/images/arty/scr1/scr1-arty-dhry21.tar.gz
Unpack it for further use.
6. Press "Enter". Then select required bin-file for loading (mark it and press "space" button for
minicom).
+------------------------[Select a file for upload]-------------------------+
|Directory: images/arty/scr1
| [..]
| dhry21-o3lto.bin
|
7. Press "Enter" button. Image transfer will start.
|
|
|
|
9
