+-----------[xmodem upload - Press CTRL-C to quit]---------------------+
|Sending dhry21-o3lto.bin, 107 blocks: Give your local XMODEM receive |
|command now.
|Bytes Sent: 13952
|
|Transfer complete
|
| READY: press any key to continue...
+----------------------------------------------------------------------+
8. When loading completes, status information will be shown:
Xmodem successfully received 13952 bytes

4.3. Example: Dhrystone run from TCM memory

1. Load dhry21-o3lto.bin to the TCM base address (0xf0000000) as described in the previous
section.
2. Select "g" menu item, then enter the test's launching address 0xf0000200. That will start
program execution.
1: xmodem load @addr
g: start @addr
d: dump mem
m: modify mem
i: platform info
xload @addr
addr: f0000000
CC
Xmodem successfully received 13952 bytes
start @addr
addr: f0000200
test start...
3. After benchmark completion you should see its results
Time: begin= 513848033, end= 513854416, diff= 6383
Microseconds for one run through Dhrystone: 12.766
Dhrystones per Second:
10
BPS:5468
78333
|
|
|
|
|
|
