INSTALLATION INSTRUCTIONS
ELECTRICAL PREPARATION
WARNING: The dishwasher is designed for an electrical supply of 120 V, 60 Hz, AC connected to a dedicated,
properly grounded electrical circuit with a fuse or breaker rated for 15 Amps.
The power-supply receptacle for the appliance shall be installed in a cabinet or on a wall adjacent to the under
counter space in which the appliance is to be installed.
PREPARATION FOR INSTALLING MOUNTING BRACKETS
WARNING: The mounting brackets in the parts bag should be used when the dishwasher is installed in the
cabinetry. Use of any parts other than the proper mounting brackets may result in damage to property or bodily
injury.
NOTE: There shall be an opening through the partition between the compartments that is large enough for the
attachment plug to pass through. The longest dimension of the opening shall not be more than 1.5 inch (38.1
mm).
NOTE: If the partition is wood, the edges of the cabinetry should be rounded and smooth. If it is metal, it
should be covered with an edge protector and care should be exercised when the appliance is installed or
removed to reduce the likelihood of damage to the power supply cord.
Wood or laminate counter tops
Stone or hard material counter tops
7
Figure 2
Place the two mounting
brackets into the top corners
of the dishwasher.
If necessary (according to the
counter-top board material),
bend the sides of the mounting
brackets.
