1.2 Specifications

Input
2 GE ports (max 64 IP input)
Types
Max 840Mbps for each GE input
UDP, UDP / RTP, 1-7 packets, FEC,
Stream
SPTS, MPTS
TS over UDP/RTP, unicast and multicast,
Transport Protocol
IGMP V2/V3
Packet Length 188/204 Bytes
Decoding Parameters
Video 4 mm
Audio F2.0
Data Fixed
Resolution
1080@60I, 1080@50I, 720@60P,
MPEG-2
720@50P, 576@50I, 480@60I
1080@60P ,1080@60I, 1080@50P,
H.265/H.264
1080@50I, 720@60P, 720@50P
Aspect Ratio 4:3/16:9
Modulation Parameters
Number of
up to 32
Channels
Connectors 75Ω, F-jack
Frequency Range 43.25 – 951.25MHz, Digital Modulation
Output Level Maximum 112dBμV
Return Loss ≥ 14dB
Spurious
Frequency ≥ 60dB
Distribution
Stereo Crosstalk > 55dB
Residual Carrier
1%
Accuracy
WEB Interface (TV Standard)
TV Standard NTSC
Video-Signal
≥ 60dB
to Noise Ratio
DT-NTSC-32 Manual
Network Interface
Management 1 x 100 Base-T Ethernet (RJ 45)
Data 2 x 1000 Base-T Ethernet (RJ 45)
IEEE802.3 Ethernet, RTP, ARP, IPv4,
Protocol TCP/ UDP,
HTTP, IGMPv2/v3
Others
CNR (after internal
60 dB
combining)
SNR (after internal
> 53 dB
combining)
Sampling
48, 44.1, 32
frequency
Output Volume
0 - 100 %
Adjustment
Image Resolution
480i/576i
Output
logo: JPG, BMP, PNG
OSD CAPTION: support multiple languages,
scrolling direction and speed customized
General
Operating 32 - 113°F (0 to 45°C)
Temperature
Storage -4 - 176°F (-20 - 80°C)
temperature
AC100V±10%, 50/60Hz or AC
Power Supply
220V±10%,50/60Hz
16.53" x 17.32" x 1.75" (420 x 440 x
Dimensions
44.5mm)
Weight 9.12 lbs (4.14 kg)
Warranty 1-Year Limited Warranty
