DT-QAM-ENCMOD-8 Manual Table of Contents Introduction ........................3 Features ........................3 Specifications ........................ 3 Safety Instructions ......................4 Unpacking and Handling ....................5 Installation ........................5 Front Panel ........................6 Rear Panel ........................6 Web Management ......................7 Quick IP Ethernet Connection Guide ................. 16 Common Troubleshooting .................. -
Page 3: Introduction
DT-QAM-ENCMOD-8 Manual Introduction The DT-QAM-ENCMOD-8 is designed with 8 HDMI input connectors. After encoding and multiplexing, the device will modulate the signals into DVB-T/ T2, DVB-C, ATSC, ISDB and DTMB standards. Thanks to its IP input port in the front panel, it can take in the IP signal and output in RF signal as well. -
Page 4: Safety Instructions
DT-QAM-ENCMOD-8 Manual TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER FROM THIS UNIT. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO PREVENT SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE... -
Page 5: Unpacking And Handling
Should any damage be discovered after unpacking the unit, immediately contact DataTronix at 800-688-9282. Installation The DT-QAM-ENCMOD-8 is designed to be installed in a rack shelf or a standard rack. Please fol- low the instructions below to install the DT-QAM-ENCMOD-8 digital modulator: 1. Connect the power plug to the jack 2. -
Page 6: Front Panel
4. POWER CORD: 12V 5A power source 5. ON/OFF SWITCH: Turns the unit on or off 6. GDN: For modulator grounding WARNING: For the protection of your equipment and its proper working, it is necessary to connect the DT-QAM-ENCMOD-8 to a ground connection. -
Page 7: Web Management
DT-QAM-ENCMOD-8 Manual Web Management Login: The DT-QAM-ENCMOD-8 has a user friendly interface for programming and monitoring the device. The user can access to the built-in web UI by logging into Google Chrome, Firefox or Microsoft Edge accounts. (The best browsers) - Page 8 DT-QAM-ENCMOD-8 Manual Serial Number: The unique ID for this modulator. Modulation: Indicates the RF output modulation. Software Version: If there’s something wrong with this device, please send this information to us. Temperature: Indicates the CPU working temperature in real-time. Rear Panel: Indicates the input connector status. The green color means the HDMI cable is well connected while the gray means disconnected.
- Page 9 DT-QAM-ENCMOD-8 Manual IP Signal Click the +Add button to add the IP address. >>>Choose the Multicast in normal situation and input your IP address. >>>Click Submit and the system will analysis the programs in IP address, which will be listed out in the Router.
- Page 10 DT-QAM-ENCMOD-8 Manual HDMI Signal Green light indicates normal working conditions. Greyed out indicates either the port Status is unused, or input is not detected. Channel 1-1 means the first HDMI port in the first card Enable Enable and disable the HDMI input port...
- Page 11 DT-QAM-ENCMOD-8 Manual Frequency Bars The usage indicator bar will move while the user sends programs to the output frequency. It is not recommended to exceed 80% of the total bandwidth. If the input bitrate exceeds 80%, the barcolor will turn Red from Green as a warning signal..
- Page 12 DT-QAM-ENCMOD-8 Manual STOP! DO NOT set the PMT PID, VIDEO PID and AUDIO PID with the same ID. Stream Information This information is a summary of the router list, which is very helpful to the operators. Output Channel List : In the OUTPUT page, we can reschedule the program and PIDs in a much easier...
- Page 13 DT-QAM-ENCMOD-8 Manual RF Setting In this page, you can set up the output modulation with its parameters and the output frequencies. Reminder: The output frequencies are 4 continuous ones. You only need to fill the first one and the system will show the other three.
- Page 14 DT-QAM-ENCMOD-8 Manual System Network Setting Making changes in this area can affect the system communication. PROCEED WITH CAUTION. Management in IP address should only be changed when it is necessary to manage the entire system from a different subnet. Otherwise, please leave what it is.
- Page 15 DT-QAM-ENCMOD-8 Manual System Parameter Upgrade system from file: Upgrade the modulator with the latest software. Restore to factory settings: The restore function will recover the input and output settings and the IP address to the factory mode. Reboot: To reboot the modulator. Export Settings: Back up the input and output settings to your computer.
-
Page 16: Quick Ip Ethernet Connection Guide
DT-QAM-ENCMOD-8 Manual Quick IP Ethernet Connection Guide NOTICE: Make sure you login your operation system as the administrator. 1. Go to “Window Start” 2. Go to Window Settings 3. Go to “ Network & Internet” 4. Go to “Ethernet” on the left side of the menu 5. - Page 17 DT-QAM-ENCMOD-8 Manual 7. Open Properties 8. Go to “Internet Protocol Version 4 (TCP/IPv4) 9. Go to “Properties” 10. Go to “Use the following IP address”...
-
Page 18: Common Troubleshooting
DT-QAM-ENCMOD-8 Manual 11. Set IP address Set IP address: 192.168.1.10 Set Subnet mask: 255.255.255.0 Set Default gateway: 192.168.1.1 12. Save all the settings. Common Troubleshooting Symptom Recommended Action Power LED is not lit. 1-1 means the first HDMI port in the first card Can’t login to the NMS... -
Page 19: Warranty
DT-QAM-ENCMOD-8 Manual Warranty DATATRONIX 1-Year Limited Warranty DATATRONIX. (the “Company”) warrants to the Original Purchaser that the item purchased is free from defects in workmanship or material under normal use. This warranty starts on the date of shipment of the hardware to the Original Purchaser. - Page 20 DT-QAM-ENCMOD-8 Manual the possibility of such damages, or for any claim brought against your by another party. Jurisdic- tions vary with regard to the enforceability of provisions excluding or limiting liability for incidental or consequential damages. You should check the laws of your local jurisdiction to find out whether the above exclusion applies to you.
