3.2.2 Parameters

Parameters → IP Input:
Clicking "IP Input", will display the interface as shown in Figure-3. Users can select the output
TS channels.
Click "+" to add IP input, and then select one channel to parse. It will display the interface where
users can choose the programs to output.
Figure-3
: To add input channel which come from Data1 or Data 2 or Data Module (front panel)
: To edit the input channel
: To delete the input channel
: To delete all inputs channel
Input Area
DT-NTSC-32 Manual
Output Area
12
