- Page 1 IOM Manual IOM Manual Series 52 Proximity Reed Switch www.flowlinevalves.com...
- Page 2 Flow Line Valve and Controls, L.L.C. 110 Main Project Road Schriever, LA 70395 P.O. Box 677 Schriever, LA 70395 Phone 985-414-6004 * Toll Free 800-815-9226 * Fax 985-414-6072 www.flowlinevalves.com Installation and Operations Manual Series 52 Installation Attach proper mounting bracket to the switchbox housing Engage switch box shaft to top of actuator shaft.
- Page 3 Electrical Wiring Remove switch box cover. Remove protection plug(s) from conduit entries and install conduit or other approved connection means. Engage wires in terminal strip using a small screwdriver (1/2” blade). Note: terminals 1, 2, & 3 are for the top switch and terminals 4, 5, &...
