MODEL ETH-IIRO-16 FAMILY
ETHERNET ISOLATED DIGITAL INPUT /
RELAY OUTPUT MODULES
USER MANUAL
FILE: ETH-IIRO-16.A2b

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETH-IIRO-16 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Acces I/O products ETH-IIRO-16 Series

  • Page 1 10623 Roselle Street, San Diego, CA 92121 • (858) 550-9559 • FAX (858) 550-7322 contactus@accesio.com • www.accesio.com MODEL ETH-IIRO-16 FAMILY ETHERNET ISOLATED DIGITAL INPUT / RELAY OUTPUT MODULES USER MANUAL FILE: ETH-IIRO-16.A2b...
  • Page 2 ACCES, nor the rights of others. IBM PC, PC/XT, and PC/AT are registered trademarks of the International Business Machines Corporation. Printed in USA. Copyright© by ACCES I/O Products Inc, 10623 Roselle Street, San Diego, CA 92121. All rights reserved. WARNING!! ALWAYS CONNECT AND DISCONNECT YOUR FIELD CABLING WITH THE COMPUTER POWER OFF.
  • Page 3 Warranty Prior to shipment, ACCES equipment is thoroughly inspected and tested to applicable specifications. However, should equipment failure occur, ACCES assures its customers that prompt service and support will be available. All equipment originally manufactured by ACCES which is found to be defective will be repaired or replaced subject to the following considerations. Terms and Conditions If a unit is suspected of failure, contact ACCES' Customer Service department.
  • Page 4: Table Of Contents

    Table of Contents Chapter 1: Introduction ...................... 5 Features ........................... 5 Factory Options ....................... 5 Typical Applications ....................... 5 Functional Description ....................6 OEM ETH/104 FORM FACTOR ..................6 Figure 1-1: Block Diagram ..................6 Ordering Guide ........................ 7 Model Options ......................... 7 Special Order ........................
  • Page 5: Chapter 1: Introduction

    Chapter 1: Introduction Features Ethernet 10/100 RJ45 connector for interfacing to CPU or network • DHCP or static IP assignment • 16 optically isolated inputs (3V to 31V) • 16 Form C electro-mechanical relays switch 1A • Internal, removable terminal board for easy wiring •...
  • Page 6: Functional Description

    Functional Description The ETH-IIRO-16 Series (4, 8 and 16 channels) is an ideal solution for adding portable, easy-to-install, isolated input and relay output digital I/O capabilities to any Ethernet network. It is excellent for controlling external relays, driving indicator lights, fuel pumps, high voltage control and more.
  • Page 7: Ordering Guide

    Ordering Guide ETH-IIRO-16 16 isolated digital inputs and 16 relays in enclosure with breakout board • ETH-IIRO-8 8 isolated digital inputs and 8 relays in enclosure with breakout board • ETH-IIRO-4 4 isolated digital inputs and 4 relays in enclosure with breakout board •...
  • Page 8: Optional Accessories

    Optional Accessories Six-foot ribbon cable assembly with • CAB50F-6 50-pin female connectors Screw terminal board, typically ships with standoffs but can also mount on • STB-50 SNAP-TRACK or DIN-SNAP Six inch length of SNAP-TRACK with • DIN-SNAP-6 two clips, for mounting one STB-50 screw terminal board on a DIN rail One foot length of SNAP-TRACK with four clips, for mounting up to two STB-50...
  • Page 9: Chapter 2: Installation

    Chapter 2: Installation Software Installation The software provided with this board is must be downloaded from the product page at https://accesio.com/files/packages/ETH-IIRO-16/Install.exe then installed onto your system. Hardware Installation The board can be installed on any Ethernet network or even just connected directly to a NIC in your PC.
  • Page 10: Chapter 3: Hardware Details

    Chapter 3: Hardware Details Option Selections Refer to the settings program installed with the software package. Also, refer to the Block Diagram and the Option Selection Map when reading this section of the manual. Figure 3-1: ETH-IIRO-16 Option Selection Map Ethernet Connector The Ethernet Connector is an industry standard RJ45 10/100 Base T type with integrated transmit / receive LEDs.
  • Page 11: Dc Power Screw Terminals

    DC Power Screw Terminals If a more secure retention method of providing the unit with power is desired, use these clearly marked screw terminals to connect regulated 5VDC. 50 and 34 Pin Box Headers These headers have standard 0.100" spacing between pins and are keyed to prevent improper connections.
  • Page 12: Chapter 4: Ethernet Address Information

    Chapter 4: Ethernet Address Information Use the provided AIOETHW.dll driver to access the Ethernet board. All units are shipped from the factory with an identical default MAC address: 00 08 DC 11 99 77. If you are using more than one device in the same ethernet environment you will need to change the MAC.
  • Page 13: Chapter 5: Programming

    Chapter 5: Programming TCP/IP This model family is TCP/IP. The source for our Windows DLL is installed with the samples, into the .\Win32\Driver.SRC\DLL\ directory. The intent is for any language able to send TCP/IP packets be able to utilize the unit. Client API To install the client, simply copy AIOETHW.dll next to the program that will use it, or to the 32-bit system directory.
  • Page 14: Packet Structure

    Low Level Interface Information The following information is provided for users who cannot or choose to not use AIOETHW.dll. This is necessary in non-windows operating systems. For your reference consider reading the source code for AIOETHW.dll provided with your software install. More information is available in the HTML API reference installed in your software directory Packet Structure A packet is a byte-lengthed string;...
  • Page 15: Chapter 6: Connector Pin Assignments

    Chapter 6: Connector Pin Assignments Isolated Inputs Connector Pins Form C Relay Outputs Connector Pins Pin Function Pin Function Pin Function Pin Function 1 Iso In 00 A 2 Iso In 00 B 1 Relay 15-NO 2 Relay 15-C 3 Iso In 01 A 4 Iso In 01 B 3 Relay 15-NC 4 Relay 14-NO...
  • Page 16: Chapter 7: Specifications

    Chapter 7: Specifications ISOLATED INPUTS Number of inputs: Sixteen Type: Non-polarized, optically isolated from each other and from the computer (CMOS compatible) Voltage Range: 3 to 31 DC or AC Rms (40 to 10000 Hz) Isolation: 500V*(see note) channel-to-ground or channel-to channel Input Resistance: 1.8K ohms in series with opto coupler Filter Response Times:...
  • Page 17: Customer Comments

    Customer Comments If you experience any problems with this manual or just want to give us some feedback, please email us at: manuals@accesio.com. Please detail any errors you find, we will reply with manual updates. 10623 Roselle Street, San Diego CA 92121 Tel.
