Nauticam NA-503-H User Manual

For smallhd 503 ultrabright on-camera monitor with hdmi 1.4 input / sdi input

Advertisement

Quick Links

For SmallHD 503 UltraBright On-Camera Monitor with HDMI 1.4 Input / SDI Input
NA - 503-H /
NA - 503-S
2
2
3
4
7
8
9
10
12
16
18
19
20
21
22
May, 2022
PN 17925 / 17925S
User Manual
Housing
Monitor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NA-503-H and is the answer not in the manual?

Questions and answers

Summary of Contents for Nauticam NA-503-H

  • Page 1: Table Of Contents

    May, 2022 NA - 503-H / NA - 503-S For SmallHD 503 UltraBright On-Camera Monitor with HDMI 1.4 Input / SDI Input PN 17925 / 17925S User Manual Housing Monitor Introduction Package Contents Important Instructions Part Names and Functions Housing Mount Opening the Housing Closing the Housing Setup Options...
  • Page 2: Introduction

    PACKAGE CONTENTS Make sure that you have all the included items listed below before using this product. If some items are missing or damaged, contact your local Nauticam dealer. NA - 503-H (HDMI) NA - 503-S (SDI)
  • Page 3: Important Instructions

    O-ring renewal between the atmosphere and inside the and port change. housing. Only the accesories specifi ed by Use only Nauticam lubricant on silicone Nauticam must be used. Third-party rubber O-ring. accessories may result in malfunctions or damage to the product.
  • Page 4: Part Names And Functions

    PART NAMES AND FUNCTIONS Rear View Right button Up button Left button Down button Power / BACK button F1 button F2 button Center selector...
  • Page 5 PART NAMES AND FUNCTIONS Front + Bottom Views M25 Accessory Port Zinc Anodes Mounting ball with screws HDMI / SDI cable...
  • Page 6 PART NAMES AND FUNCTIONS Top + Side Views Moisture alarm window M25 Accessory Port M16 Vacuum valve II M28-M16 Step Down Adaptor Housing unlock button...
  • Page 7: Housing Mount

    25096 SDI Cable in 0.75m length M16 Accessory port 25058 M16 SDI Bulkhead 1/4’’-20 UNC holes 17951 Nauticam Monitor Housing Mounting System M3 Screw holes 17958 Mounting Ball M25 Accessory port 25071 HDMI 1.4 cable (A-D) in 0.75m length 25096...
  • Page 8: Opening The Housing

    OPENING THE HOUSING * drawings as illustrations only depress housing unlock button turn housing lock latch anti-clockwise to open the housing fl ip open the back housing when lock latch is aligned to ‘open’ position...
  • Page 9: Closing The Housing

    CLOSING THE HOUSING * drawings as illustrations only before closing the housing, clean and lubricate the main O-ring make sure nothing is caught between front and back housing and that they are fully aligned before locking main O-ring insert the housing shaft into the shaft hole and then rotate the lock latch clockwise until you hear and feel it click into place...
  • Page 10: Setup Options

    SETUP OPTIONS - HDMI * drawings as illustrations only HDMI IN 25080 17925 M28-M16 Step Down NA-503-H Housing for Adapter SmallHD 503 UltraBright On-Camera Monitor (With HDMI 1.4 input) 25071 HDMI 1.4 (A-D) Cable in 0.75m length 25033 Standard HDMI Bulkhead...
  • Page 11 SETUP OPTIONS - SDI * drawings as illustrations only SDI IN 25080 M28-M16 Step Down 17925S Adapter NA-503-S Housing for SmallHD 503 UltraBright On-Camera Monitor (with 3G-SDI input support) 25096 SDI Cable in 0.75m length M16 SDI Bulkhead 25060 SDI Cable in 0.40m length SDI IN + SDI OUT 25064 / 25065 SDI Surface Cable...
  • Page 12: Cable Connection

    CABLE CONNECTION - HDMI IN * drawings as illustrations only HDMI Cable to Monitor Connector turn the two locking levers in the direction as shown connect the HDMI cable to the monitor HDMI connector then place the monitor inside the housing secure the monitor by turning the two locking levers towards the monitor...
  • Page 13 CABLE CONNECTION - SDI IN * drawings as illustrations only SDI Cable to Monitor Connector turn the two locking levers in the direction as shown connect the SDI cable to the monitor SDI connector then place the monitor inside the housing place the monitor inside the housing then secure the monitor by...
  • Page 14 CABLE CONNECTION - SDI OUT * drawings as illustrations only SDI Surface Cable to Monitor Housing *Please note that M16 SDI Bulkhead, 25060 SDI cable and SDI surface cable is not included in the package SDI Surface Cable Cap M16 SDI Bulkhead Cap M16 SDI Bulkhead M16 Plug unscrew the M16 plug from 25080 M28-M16 Step...
  • Page 15 CABLE CONNECTION - TO CAMERA HOUSING * drawings as illustrations only For Both HDMI + SDI Cable Bulklhead Extension Ring M24 - M16 Adpater remove the caps of HDMI/SDI cable and bulkhead connect the internal cable to the bulkhead (M28-M16/M24-M16 adapter and M16 Extension ring as shown if needed) connect the bulkhead onto camera housing...
  • Page 16: Preparation For Use

    PREPARATION FOR USE * drawings as illustrations only Coating housing O-ring Main O-ring remove the main O-ring using an O-ring remover clean the O-ring groove with a cloth and ensure that it is free from salt or other foreign materials lightly coat it with provided lubricant return the main O-ring by slowly pressing from one corner to the whole perimeter...
  • Page 17 PREPARATION FOR USE * drawings as illustrations only Setting up moisture alarm Alarm ON/OFF CR2032 Battery remove battery press the battery down until it insulation fi lm click into place switch on the alarm test the alarm - the moisture alarm - connect the wires with a window will fl...
  • Page 18: Pre-Installed M16 Vacuum Valve Ii

    PRE-INSTALLED M16 VACUUM VALVE II * drawings as illustrations only Vacuum valve system remove the cap from the pre-installed vacuum valve connect hand pump to the valve hand pump vacuum valve moisture alarm window pump several times until it reaches the target vacuum level close vacuum valve cap Moisture alarm window colour indication :...
  • Page 19: Care/Storage

    CARE/STORAGE Soak the housing system in fresh water Operate all controls and buttons at after salt water usage least 3 times while immersed in fresh water We recommand cleaning and inspecting Protect the housing with robust and the main O-ring each time after diving for shock-proof travel case during trans- any damage and every time the housing portation.
  • Page 20: Warranty

    NAUTICAM accepts no liability for any damage to and defects in the housing caused by improper use and/or poor maintenance; it is the responsibility of the own- er to carefully follow the instructions in our manuals.
  • Page 21: Specifications

    SPECIFICATIONS NA-503-H NA-503-S SmallHD 503 UltraBright On-Camera Monitor (With HDMI 1.4 input) SmallHD 503 UltraBright On-Camera Monitor (with 3G-SDI input support) Construction Construction Housing body Hard Anodized Aluminium Alloy Housing body Hard Anodized Aluminium Alloy Display window Abrasion Resistant Polycarbonate...
  • Page 22: Hdmi Cable Compatibility

    HDMI CABLE COMPATIBILITY 25036 and 25046 are both included in NA-503-H package 25036 HDMI (D-C) Cable in 190mm length Compatible Camera Nikon D500 D750 D7500 Canon 5DIV 5DSR 6DII 7DII 25046 HDMI (D-D) Cable in 200mm length Compatible Camera Sony...
  • Page 23 Nauticam Internationl Ltd. Rm 2203, CCT Telecom Bldg, 11 Wo Shing St, Fo Tan, Hong Kong Tel. +852 - 26902711 Fax. +852 - 26909778 URL. www.nauticam.com Gallery. www.nauticam.smugmug.com...
