- Page 1 HIGH EFFICIENCY SERIES SINGLE ZONE - MINI-SPLIT INSTALLATION MANUAL FOR SEA BREEZE MODELS AIR CONDITIONER HEAT PUMP SHE9A423ZGX SHE9H423ZGX SHE12A422ZGX SHE12H422ZGX SHE18A418ZGX SHE18H418ZGX SHE24A418ZGX SHE24H418ZGX 950-0192revA November 27, 2013...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Installation Steps Notes to Installer Parts Included with Indoor Unit Installer Supplied Parts Condensate Pump Decorative Channel Wall Brackets Installation Considerations General Information Select Locations for Indoor Unit Select Locations for Outdoor Unit Line Set Length Indoor Unit (Evaporator) installation Outdoor Unit (Condenser) installation Connecting Line Set Electrical Connection –... -
Page 3: Installation Steps
Installation Steps: Select the location for the indoor and outdoor unit. (page 5) Mount the indoor wall brackets. (page 6) Drill wall penetration holes. (page 6) Hang the indoor units. (page 7) Locate and mount the outdoor unit. (page 8) ... -
Page 4: Parts Included With Indoor Unit
PARTS INCLUDED WITH UNIT Indoor unit Outdoor Unit Wall Bracket Drain Fitting (only for Heat Pump units) Remote Control Installation Manual Batteries for Remote Control (2 AAA) Remote Control Holder Drain Tubing 6 ft. ... -
Page 5: Decorative Channel
Decorative Channel Route the bundled piping and wiring to the outdoor unit and connect per the OUTDOOR UNIT installation instructions. Our Plastic-Duct piping and wiring duct work provides a convenient and professional looking system to route and protect the pipes and wires. Please see the illustrations below: Wall Bracket The outdoor unit may be mounted using a wall bracket (optional) (Our Catalog # BR-440L for up to 440 lbs), or located in a freestanding position on the floor or pad (preferably slightly elevated). -
Page 6: Select Locations For Indoor Unit
Selecting locations for the Indoor unit 1. Determine the best location for mounting the Indoor unit. Ensure the dimensions requirement indicated be the arrows are followed. Space to the ceiling 6" Paying close attention to the air circulation in the room, these units throw air approximately 6"... -
Page 7: Indoor Unit (Evaporator) Installation
INDOOR UNIT (EVAPORATOR) INSTALLATION 1. Clearances and Mounting requirements (Indoor Unit) Enough space should be left around the unit to facilitate maintenance. Please view Figure. 2 for recommended dimensions: Wall Wall 6" Level Mark the middle Min. 6" 6" Min. Min. - Page 8 4. Identify Line Sets Mark the line sets as necessary to prevent crossed connections. Crossed line sets will prevent proper operation. 5. Identify Interconnect cables Connect interconnect cable and identify cable at both ends. Cable routed to terminal from rear of indoor unit. 6.
-
Page 9: Outdoor Unit (Condenser) Installation
OUTDOOR UNIT (CONDENSER) INSTALLATION The location must allow easy servicing and provide good air circulation as shown in the illustration below: OUTDOOR (CONDENSER) UNIT Shaded area must be clear Figure 8 (Top View) Mounting the Outdoor (condenser) Unit Follow the clearance guidelines in the diagram above. -
Page 10: Connecting Line Set
CONNECTING LINE SET Refrigerant Tubing After the outside unit is secured to the mounting location (Pad, Wall Brackets, etc.), route the line set(s) from the Indoor unit to the outdoor unit, and secure with clamps or Plastic-Duct as required. Installation Notes: ... -
Page 11: Electrical Connection - Notes
Bundle all lines, control cables and condensation drain together. Be sure to leave Suction Line ample length on control cable to allow for termination. Bundle can be secured together Liquid Line using vinyl tape. Condensation Drain Note: Condensation drain MUST be placed at the bottom of the bundle as shown in the Figure 12. -
Page 12: Connect The Cable To The Outdoor Unit - Notes
Connect the Cable to the Outdoor Unit For 9K, 12K and 18K unit: 1. Remove the handle on the right side of the outdoor unit. See Figure 14a. 2. Remove cable knock-outs (A water tight cable strain relief or conduit is recommended here). 3. -
Page 13: Typical Electrical Wiring Connections
Typical Electrical Wiring: 12 AWG STRANDED 3 Conductor Cable (minimum) (For 18K/24K Btu models) 14 AWG STRANDED 3 Conductor Cable (minimum) 14AWG STRANDED (For 9K/12K Btu models) 4 Conductor Cable (Recommended) Outdoor Unit Indoor Unit Figure 15 950-0192revA - 12 - November 27, 2013... -
Page 14: Connect The Cable To The Indoor Unit - Diagram
Electrical connection of the indoor unit Open the front cover by pressing inward on the sides of the cover near the bottom to release, then pull bottom of cover outwards. Figure 16 Feed the cable wire in from the rear of unit. Open the electric box cover;... -
Page 15: Evacuation Of The Refrigeration Tubes And Indoor Unit
EVACUATION OF THE REFRIGERATION TUBES AND INDOOR UNIT After connecting the indoor and outdoor units, evacuate the air from the line set and the indoor unit as follows: Leak Testing Shut-off Valve 1. Connect the charging hoses to the low side of the manifold and the Flare Nut service port of the suction valve (See figure 19). -
Page 16: Start Up Testing
START UP TESTING Preparation 1. Double check that all wiring has been properly connected. 2. Check that tubing has been properly connected and ensure the suction and liquid side service valves are fully open. 3. Review remote control functions in the Operators manual. Operational Test Note: The cooling test may be performed if the outdoor temperature is between 41 º... -
Page 17: Technical Specifications For Cooling Only
TECHNICAL SPECIFICATIONS FOR COOLING ONLY UNITS Model SHE9A423ZGX SHE12A422ZGX SHE18A418ZGX SHE24A418ZGX Function COOLING COOLING COOLING COOLING Low Ambient Control Rated Voltage 208-230V AC / 1 PH 208-230V AC / 1 PH 208-230V AC / 1 PH 208-230V AC / 1 PH Min. - Page 18 TECHNICAL SPECIFICATIONS FOR COOLING ONLY UNITS (cont) Model Of Outdoor Unit SHE9A423ZOGX SHE12A422ZOGX SHE18A418ZOGX SHE24A418ZOGX Product Code 243-4003-C 243-4004-C 243-4005-C 243-4006-C Compressor Brand MITSUBISHI SANYO MITSUBISHI MITSUBISHI Compressor Model KNB092FTAMC C-6RZ110H1A SNB130FGAMC SNB150FGAMC Compressor Type Rotary Rotary Rotary Rotary LRA (Amps) 13.8 18.5 Compressor RLA (Amps)
-
Page 19: Technical Specifications For Heat Pump
TECHNICAL SPECIFICATIONS FOR HEAT PUMP UNITS Model SHE9H423ZGX SHE12H422ZGX SHE18H418ZGX SHE24H418ZGX Function COOLING / HEATING COOLING / HEATING COOLING / HEATING COOLING / HEATING Low Ambient Control Rated Voltage 208-230V AC / 1 PH 208-230V AC / 1 PH 208-230V AC / 1 PH 208-230V AC / 1 PH Min. - Page 20 TECHNICAL SPECIFICATIONS FOR HEAT PUMP UNITS (cont) Model Of Outdoor Unit SHE9H423ZOGX SHE12H422ZOGX SHE18H418ZOGX SHE24H418ZOGX Product Code 243-2003-C 243-2004-C 243-2005-C 243-2006-C Compressor Brand MITSUBISHI SANYO MITSUBISHI MITSUBISHI Compressor Model KNB092FTAMC C-6RZ110H1A SNB130FGAMC SNB150FGAMC Rotary Rotary Rotary Rotary Compressor Type LRA (Amps) 13.8 18.5 4.59...
-
Page 21: Troubleshooting
TROUBLESHOOTING The first step in troubleshooting is to disconnect power for 30 seconds to allow the unit to reset. If this does not rectify the problem proceed with the troubleshooting chart below. Problem Troubleshooting Is the power off? Is the circuit protection device tripped? ... -
Page 22: Flash Codes On Outdoor Pc Board
This air conditioning system has been provided with built in self diagnostic error codes. Please refer to the following table for error code definitions: FLASH CODES ON OUTDOOR PC BOARD For 9K / 12K units Display on State of the lamps on the Malfunction indoor unit outdoor unit PCB... -
Page 23: 18K, 24K Units
Display on State of the lamps on the Malfunction indoor unit outdoor unit PCB Name of single Reasons Green - Red - Yellow - zone Error Code LED 2 LED 3 LED 4 High Voltage DC voltage is too high. Unit will operate 1 s On, Protection of DC normally when the voltage returns to... - Page 24 Display on State of the lamps on the Malfunction indoor unit outdoor unit PCB Name of single Reasons D40/ D41/ D42/ D43/ zone Error Code Indoor Ambient 1. Terminal connection is not reliable; Sensor Failure 2. Temperature sensor failure Indoor Tube 1.
- Page 25 Display on State of the lamps on the Malfunction indoor unit outdoor unit PCB Name of single Reasons D40/ D41/ D42/ D43/ zone Error Code High Supply 1. Complete unit under high voltage Voltage Protection 2. Outdoor main PCB failure. 1.
-
Page 26: Indoor Unit Error Codes
INDOOR UNIT ERROR CODES Running Cooling Heating Malfunction Name of single zone Display Short/open circuit of the liquid valve temp. sensor 19 Flashes Short/open circuit of the suction valve temp. sensor 22 Flashes Jumper failure 15 Flashes Trial operation Flashing Flashing Flashing Incorrect connection of communication wire or... -
Page 27: Ambient Sensor Resistance Values
Ambient Sensor (indoor and outdoor) Resistance Temp. Resistance Temp. Resistance Temp. Resistance （℉） （kΩ） （℉） （kΩ） （℉） （kΩ） -0.4 128.600 69.8 17.930 3.711 102.900 15.000 147.2 3.217 82.750 84.2 12.600 154.4 2.797 21.2 66.880 91.4 10.630 161.6 2.439 28.4 54.310 98.6 9.003 168.8... -
Page 28: Outdoor Electrical Wiring Diagram (9K Cooling Only & Heat Pump)
Wiring Diagram For Models (Outdoor unit): SHE9A423ZOGX, SHE9H423ZOGX 950-0192revA - 27 - November 27, 2013... -
Page 29: Outdoor Electrical Wiring Diagram (12K Cooling Only & Heat Pump)
Wiring Diagram For Models (Outdoor unit): SHE12A422ZOGX, SHE12H422ZOGX 950-0192revA - 28 - November 27, 2013... -
Page 30: Outdoor Electrical Wiring Diagram (18K Cooling Only)
Wiring Diagram For Models (Outdoor unit): SHE18A418ZOGX 950-0192revA - 29 - November 27, 2013... -
Page 31: Outdoor Electrical Wiring Diagram (18K Heat Pump)
Wiring Diagram For Models (Outdoor unit): SHE18H418ZOGX 950-0192revA - 30 - November 27, 2013... -
Page 32: Outdoor Electrical Wiring Diagram (24K Cooling Only)
Wiring Diagram For Models (Outdoor unit): SHE24A418ZOGX 950-0192revA - 31 - November 27, 2013... -
Page 33: Outdoor Electrical Wiring Diagram (24K Heat Pump)
Wiring Diagram For Models (Outdoor unit): SHE24H418ZOGX 950-0192revA - 32 - November 27, 2013... -
Page 34: Indoor Electrical Wiring Diagram
Wiring Diagram For Models (Indoor Unit): SHE9A4ZIGX, SHE9H4ZIGX, SHE12A4ZIGX, SHE12H4ZIGX, SHE18A4ZIGX, SHE18H4ZIGX, SHE24A4ZIGX, SHE24H4ZIGX, 950-0192revA - 33 - November 27, 2013... -
Page 35: Tubing Connection Diagram
SINGLE ZONE INVERTER CONNECTION DIAGRAM EVAPORATOR CONDENSER 9,000BTU AC & HP MAX LINE 1/4" Liquid Line LENGTH 49' TOTAL 3/8" Suction Line EVAPORATOR CONDENSER 12,000BTU AC & HP MAX LINE 1/4" Liquid Line LENGTH 66' TOTAL 1/2" Suction Line EVAPORATOR CONDENSER 18,000BTU AC &... -
Page 36: Warranty And Technical Support
WARRANTY INTERNATIONAL REFRIGERATION PRODUCTS warrants the accompanying split air conditioner or heat pump system to be free of defects in material and workmanship for the applications specified in the operation manual and installation manual for a period of one (1) year on parts and five (5) years on compressor, valid from the date of original retail purchase in the United States or Canada.
