Summary of Contents for Sea Breeze 420-0075
-
Page 1: Air Conditioner Installation
WINDOW AIR CONDITIONER INSTALLATION OPERATION CATALOG NO. PRODUCT CODE WH18ZM 420-0075 950-0054-revB 6-29-07 Page 1 of 17... -
Page 2: Table Of Contents
TABLE OF CONTENTS AIR CONDITIONER SAFETY………………………………………………………………..….2 NORMAL CARE AND MAINTENANCE…………………………………………………..3 INSTALLATION REQUIREMENTS………………………………………………………..5 INSTALLATION INSTRUCTIONS………………………………………………………………6 THRU-WALL INSTALLATION INSTRUCTIONS……………………………………………11 GENERAL OPERATING INSTRUCTIONS…………………………………………………..13 OPERATING CONTROLS……………………………………………………………………..14 TROUBLESHOOTING………………………………………………………………………….15 SPECIFICATIONS…………………………………………………………………………..16 WARRANTY……………………………………………………………………………………..17 TECHNICAL SUPPORT IF YOU NEED TECHNICAL SUPPORT, PLEASE CALL 1 (704) 504-8590 BETWEEN 8:00 AM TO 4:00 P.M. WHEN CALLING FOR TECHNICAL SUPPORT, PLEASE HAVE COMPLETE MODEL AND SERIAL NUMBER AVAILABLE. -
Page 3: Normal Care And Maintenance
Installation Complete step-by-step installation instructions are furnished with your unit. These instructions will be found on a separate page included with this manual or in the mounting kit assembly. Follow these instructions carefully. Keep these instructions with this manual for future reference. Your unit will be one of the following designs: •... - Page 4 Front Grill and filter removal 1. Remove two side Phillips screws attaching The front contains a removable grill that provides front to case easy access to the air filter. To clean the filter, 2. Remove inlet panel by pulling and lifting out grasp the filter handle and slide the filter out of the bottom.
-
Page 5: Installation Requirements
IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electrical shock, or injury when using your air conditioner: follow these basic precautions: • Plug into a grounded 3 prong outlet. • Do not remove ground prong. • Do not use an adapter. •... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Tools you will need: • Adjustable Wrench • Phillips Head Screwdriver • Flat Blade Screwdriver • Pencil • Ruler or tape measure • Level • Scissors or knife Page 6 of 17... - Page 7 WINDOW REQUIREMENTS REMOVE THE AIR CONDITIONER FROM THE These instructions are for a standard double-hung CASE window. You will need to modify them for other Remove the 2 shipping screws (if present) from the types of window. back of the case and discard them. The air conditioner can be installed without the Remove the locking screw and locking bracket from accordion panels if needed to fit in a narrow window.
- Page 8 PREPARE THE CASE Make sure the bolts and nuts are all of the way in Install the top mounting rail with 4 type B screws on both the left and right V-Supports. from inside the case. Insert the frames for the accordion panels into the top mounting rail and the bottom frame guides.
- Page 9 INSTALL THE CASE IN THE WINDOW (CONT.) Cut the foam top window gasket to the window width. Use a wood block (obtained locally) between the Stuff the foam between the glass and the window to leveling bolts and the wall if the wall is weak or if prevent air and insects from getting into the room.
- Page 10 INSTALL THE AIR CONDITIONER IN THE CASE Secure the front grill frame to the case with one (CONT.) type C screw. Remove the front grill from its box and remove the shipping tape. Grasp the inlet grill at the bottom corners and pull it forward.
-
Page 11: Thru-Wall Installation Instructions
THRU-WALL INSTALLATION INSTRUCTIONS INTRODUCTION This instruction provides guidelines for installing a compact air conditioner through an outside wall. Air conditioner Dimensions The following figures show the outside dimensions of the air conditioner with the chassis installed, and dimensions of the outer case with the chassis removed. - Page 12 GENERAL INSTRUCTIONS (CONT.) Placement of Outer Case in Opening Place the outer case in the opening, flush against one side of the opening. Use a carpenter’s level and ensure case is level from side to side and has a 3/8” slope from front to back (back of case must be 3/8”...
-
Page 13: General Operating Instructions
Ventilation louvers on top of case must not be obstructed. Do not attempt to install unit in walls thicker than 11 3/4 inches. _________________________________________________________________________________________ GENERAL OPERATING INSTRUCTIONS While operation of all units is similar, controls vary Drain Cup Installation and Use slightly from model. -
Page 14: Operating Controls
OPERATING CONTROLS Fan Control OFF Completely shuts off the unit. To prevent blowing fuses, wait two minutes after turning the Temperature Control unit off before turning it on again. Turn this control to the left for a warmer room temperature, to the right for a cooler room LOW COOL Filters and circulates room air with the temperature. -
Page 15: Troubleshooting
TROUBLESHOOTING The following is a list of problems that are sometimes encountered when using a room air conditioner. Possible cause and suggested remedies are given for each problem. • • UNIT WILL NOT RUN NOISY UNIT Push reset button on power cord. Tighten any loose parts. -
Page 16: Specifications
TECHNICAL SPECIFICATIONS MODEL WH18ZM BTU COOLING 18,000 – 17,600 BTU HEATING 11,000 – 8,600 EER RATING DEHUMIDIFICATION (pints/hour) AIRFLOW (CFM) 450 (MAX) VOLTAGE 230 – 208 VAC FREQUENCY 60 HZ AMPS COOLING 8.2 – 8.75 AMPS HEATING 15.4 – 13.93 WATTS COOLING 1885 –... -
Page 17: Warranty
WARRANTY International Refrigeration Products warrants the she product supplied is free from defects in material and workmanship. This warranty is valid as long as this product is properly handled, installed, operated and serviced in accordance with the Installation and Operating Instructions shipped with this unit, and warranty card is completed and mailed no later than 30 days after date of purchase.
