AIR CONDITIONER / HEAT PUMP
208/230 VAC Units
PTAC412CH3ZB
PTAC412HP3ZB
PTAC415CH3ZX
PTAC415HP3ZB
953-0111-revE
PTAC

SERVICE MANUAL

PTAC49CH3ZX
PTAC49HP3ZB
REFRIGERANT
265/277 VAC Unit
PTAC49CH3VX
PTAC49HP3VB
PTAC412CH3VX
PTAC412HP3VB
PTAC415CH3VX
PTAC415HP3VX
R410A
May 27, 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTAC49CH3ZX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sea Breeze PTAC49CH3ZX

  • Page 1: Service Manual

    PTAC AIR CONDITIONER / HEAT PUMP SERVICE MANUAL 208/230 VAC Units 265/277 VAC Unit PTAC49CH3ZX PTAC49CH3VX PTAC49HP3ZB PTAC49HP3VB PTAC412CH3ZB PTAC412CH3VX PTAC412HP3ZB PTAC412HP3VB PTAC415CH3ZX PTAC415CH3VX PTAC415HP3ZB PTAC415HP3VX REFRIGERANT R410A 953-0111-revE May 27, 2016...
  • Page 2: Table Of Contents

    Table of Contents SAFETY PRECAUTIONS ...........................2 SPECIFICATION ..........................……3 Specification of 208/230 VAC units………………………………………………………………………………...3 Specification of 265/277 VAC units………………………………………………………………………………...4 OUTLINE AND INSTALLATION DIMENSIONS ..................5 REFRIGERATION SYSTEM DIAGRAM ....................6 WIRING DIAGRAMS ......................... ……..7 PC Board ............................……..8 INSTALLATION INSTRUCTIONS ....................... 10 FUNCTION AND CONTROL ……………………………………………………………………………………..
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS IMPORTANT snow, leaves or rubbish. Please Read Before Starting. • The unit should be installed according to the This air conditioning system meets strict safety and instructions in order to minimize the risk of damage operating standards. As the installer or service person, it is from earthquakes, typhoons or strong winds.
  • Page 4: Specification

    TECHNICAL SPECIFICATIONS OF 208/230 UNITS Model Number PTAC49CH3ZX PTAC49HP3ZB PTAC412CH3ZB PTAC412HP3ZB PTAC415CH3ZX PTAC415HP3ZB Refrigerant type/charge R410A / 2.09 lb R410A /1.54 lb R410A / 1.74 lb R410A / 1.74 lb R410A / 2.38 lb R410A / 2.38 lb Voltage Input (V/PH/Hz)
  • Page 5: Specification Of 265/277 Vac Units

    TECHNICAL SPECIFICATIONS OF 265/277 UNITS Model Number PTAC49CH3VX PTAC49HP3VB PTAC412CH3VX PTAC412HP3VB PTAC415CH3VX PTAC415HP3VX Refrigerant type/charge R410A / 33.27 oz. R410A / 24.34 oz. R410A / 35.98 oz. R410A / 26.8 oz. R410A / 40.21 oz. R410A / 36.33 oz. Voltage Input (V/PH/Hz) 265-277V / 1/60 265-277V / 1/60 265-277V / 1/60...
  • Page 6: Outline And Installation Dimensions

    All specifications given at 265 VAC. OUTLINE AND INSTALLATION DIMENSION 4 2 1 . " 2 2 4 . "...
  • Page 7: Refrigeration System Diagram

    REFRIGERATION SYSTEM DIAGRAM Model: PTAC49CH3ZX, PTAC49CH3VX, PTAC412CH3ZX, PTAC412CH3VX, PTAC415CH3ZX, PTAC415CH3VX OR CROSS FAN AXIAL FAN HOT DISCHARGED AIR COOLED AIR COMPRESSOR OUTDOOR COILS INDOOR COILS ELECTRIC HEATER CAPILLARY REFRIGERANT FLOW DIRECTION Model: PTAC49HP3ZB, PTAC49HP3VB, PTAC412HP3ZX, PTAC412HP3VB, PTAC415HP3ZB, PTAC415HP3VX CENTRIFUGAL AXIAL FAN...
  • Page 8: Wiring Diagrams

    WIRING DIAGRAM Model: PTAC49CH3ZX, PTAC49CH3VX, PTAC412CH3ZB, PTAC412CH3VX, PTAC415CH3ZX, PTAC415CH3VX Model: PTAC49HP3ZB, PTAC49HP3VB, PTAC412HP3ZB, PTAC412HP3VB, PTAC415HP3ZB, PTAC415HP3VX...
  • Page 9: Pc Board

    PC BOARD Top View...
  • Page 10 Bottom View...
  • Page 11: Installation Instructions

    Units are shipped without a sleeve. In applications where unit is a replacement, it is recommended that a Sea Breeze sleeve be used. These units can retrofit General Electric, Amana, Trane, and Friedrich sleeves / grilles (be sure outdoor grille is installed on the sleeve).
  • Page 12 RETROFIT SLEEVE PREPARATION IMPORTANT: Inspect wall sleeve thoroughly prior to installation. Manufacturer does not assume responsibility for costs or damages due to defects in sleeve or for improper installation. WARNING ELECTRICAL SHOCK HAZARD Failure to follow this warning could result in personal injury or death.
  • Page 13 INSTALL UNIT INTOWALL SLEEVE 1. Carefully remove shipping tape from the front panel and vet door. See Fig.5. 2. Remove shipping screw from the vent door, if present. See Fig.6. 3. Remove front panel. See Fig.7. 4. Lift unit level and slide unit into wall sleeve until foam seal rests firmly against front of wall sleeve. 5.
  • Page 14: Function And Control

    FUNCTION AND CONTROL 1. Temperature Parameter • Indoor setting temperature (Tpeset) • Room temperature (Tamb) 2. System Basic Function In any circumstances, the compressor will delay 3 minutes for protection once it’s stated up. Once the compressor is started up, the compressor won’t stop with the change of the indoor temperature. While once the compressor is stopped, it can be started up only after 3 minutes delayed.
  • Page 15 55 ~ 80 ℉ (13 ~ 27 ° C). 4) OFF Mode If the OFF mode is selected, all the display will be closed except the power indicator and all the output are invalid. (Except the low temperature resistant protection) If the UP or Down button is pressed, the unit display will extinguish after it displays the ambient temperature for 15 seconds and the indoor indicator will also go out after illuminated 15 seconds.
  • Page 16 Error Codes: When the unit is energized, the STATUS LED illuminates. If there is any malfunction or protection, the STATUS LED will blink with the Error code. When the unit is in the OFF status, there is not an error code showing (except the low temperature resistant protection), and the protections - 6, 7, 8 in the following table will be illuminated.
  • Page 17 f) LOW TEMPERATURE RESISTANT PROTECTION (valid in wall thermostat mode) ON – invalid. OFF – valid. The default setting is OFF. 3) Configuration – Do not need hotel maintenance personnel to control (configuration is valid after B dial- up is energized, and the configuration is invalid after A dial-up is energized). a) Heat pump and Heat Cool units for selection.
  • Page 18 (Note: if room temperature displaying is set, the unit is in cooling mode or heating mode, timer will be displayed for 5 seconds, then turn to display set temperature for 5s and then turn to display ambient temperature.) a) Press mode button b) Re-energized after power failure c) Restart the unit d) Turn on the unit after EM turn off unite.
  • Page 19 compressor will stop running, outdoor fan will keep running continuously, and the indoor fan is running normally according to the wall thermostat signal. Quit condition: If the outdoor tube temperature ≤ 131 ℉(55 ° C) is over 2 minutes, this protection will be ended.
  • Page 20: Troubleshooting

    TROUBLESHOOTING Switch is at the OFF position; or socket and plug is loosened; or the power cord has malfunction; or power No power supply failed. Fuse is burned out Replace the fuse Inspect the power voltage. If it is lower 10% of the rated Supply voltage is too low voltage, please look for the reason, improve the power supply condition and add the regulated power supply.
  • Page 21 Check leakage, evacuate with vacuum-pump after Refrigerant is insufficient or leaking repairing leakage, and then charge refrigerant according the spec. Check if the system is blocked by observing the condensation of the evaporator and the pressure value Refrigeration system is blocked of the high pressure manometer, and then take measures to deal with the system.
  • Page 22 Refrigerant is insufficient or superabundance Adjust the quantity of the refrigerant Capillary is blocked and the suction temperature Replace capillary is rising. Protection is activated due to overheating The compressor can run smoothly or is blocked. Replace the compressor The air discharge valve is damaged. Check the contact point of the compressor with a multimeter to find out if it is conducted.
  • Page 23: Appendix: Ressistance Table Of Sensors

    Appendix Appendix 1: Resistance Table of Ambient Temperature Sensor for Indoor and Outdoor Units (15K) Temp. (℉) Resistance (kΩ) Temp. (℉) Resistance (kΩ) Temp. (℉) Resistance (kΩ) Temp. (℉) Resistance (kΩ) -2.2 138.1 18.75 138.2 3.848 208.4 1.071 -0.4 128.6 69.8 17.93 3.711...
  • Page 24 Appendix 2: Resistance Table of Outdoor and Indoor Tube Temperature Sensors (20K) Resistance (kΩ) Resistance (kΩ) Resistance (kΩ) Resistance (kΩ) Temp. (℉) Temp. (℉) Temp. (℉) Temp. (℉) -2.2 181.4 25.01 138.2 5.13 208.4 1.427 -0.4 171.4 69.8 23.9 4.948 210.2 1.386 162.1...
  • Page 25: Disassembly Procedure

    DISASSEMBLY PROCEDURE Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Note: The procedure below is for heat pump unit with electric heating. There is some difference between it and cooling only unit with electric heating. The difference is pointed out in the diagram; please refer to the related diagram direction.
  • Page 26 ~25~...
  • Page 27 ~26~...
  • Page 28 ~27~...
  • Page 29 ~28~...
  • Page 30 ~29~...
  • Page 31 ~30~...
  • Page 32 ~31~...
  • Page 33 ~32~...
