INSTALLATION
INSTRUCTIONS
MINI-SPLIT
AIR CONDITIONING SYSTEMS
FOR MODELS:
9A23YGX
12A23YGX
12A23ZGX
18A23ZGX
950-0027-REV-F
12-14-06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9A23YGX and is the answer not in the manual?

Questions and answers

Summary of Contents for Sea Breeze 9A23YGX

  • Page 1 INSTALLATION INSTRUCTIONS MINI-SPLIT AIR CONDITIONING SYSTEMS FOR MODELS: 9A23YGX 12A23YGX 12A23ZGX 18A23ZGX 950-0027-REV-F 12-14-06...
  • Page 2: Table Of Contents

    Table of contents Model Numbers…………………………………………………………………………………………………2 Unit Parts and Features………………………………………………………………………………………3 Installation Dimension Diagram………………………………………………………………………………5 Safety Warnings…………………………………………………………………………………………………7 Selection of Installation Location………………………………………………………………………………8 Indoor Unit Installation…………………………………………………………………………………………9 Outdoor Unit Installation………………………………………………………………………………………12 Testing…………………………………………………………………………………………………………14 Warranty………………………………………………………………………………………………………17 Specifications…………………………………………………………………………………………………18 Troubleshooting Chart………………………………………………………………………………………19 - - 1...
  • Page 3: Model Numbers

    Model Numbers Air Conditioning SYSTEM MODEL Indoor Unit 9A23YIGX 9A23YGX Outdoor Unit 9A23YOGX 9,000 BTU 115 VAC 13 SEER SYSTEM MODEL Indoor Unit 12A23YIGX 12A23YGX Outdoor Unit 12A23YOGX 12,000 BTU 115 VAC 13 SEER SYSTEM MODEL Indoor Unit 12A23ZIGX 12A23ZGX...
  • Page 4: Unit Parts And Features

    Unit Parts & Features (Models 9A23YGX, 12A23YGX, 12A23ZGX) - - 3...
  • Page 5 Unit Parts & Features (Cont) (Model 18A23ZGX) - - 4...
  • Page 6: Installation Dimension Diagram

    Installation Dimension Diagram (Models 9A23YGX, 12A23YGX, 12A23ZGX) - - 5...
  • Page 7 Installation Dimension Diagram (Model 18A23ZGX) - - 6...
  • Page 8: Safety Warnings

    Safety Warnings • Use Copper Wires only for Power Supply • Risk of electric shock can cause injury or death. Disconnect all electric power supplies before servicing or installation • Do not use excessive torque on flare nuts during connection of the refrigeration tubes, or service valve on discharge line may be damaged.
  • Page 9: Selection Of Installation Location

    Selecting of Installation Locations Indoor Unit: • Intake and outlet should not be obstructed. • The wall the unit is to be mounted on should allow for a clear hole for the condensation drain and the refrigeration lines. • The wall the unit is mounted on should be strong enough to bear the weight and vibration of the unit. •...
  • Page 10: Indoor Unit Installation

    If a disconnect switch is required for the indoor unit, it must be properly rated. (see specifications) POWER MODEL INTERCONNECTING SUPPLY WIRE CIRCUIT CIRCUIT WIRE GAUGE GAUGE AMAPCITY BREAKER FUSE SIZE 9A23YGX 16 AWG 14 AWG 10 AMP 15 AMP 15 AMP 12A23YGX 16 AWG 14 AWG 11.6 AMP 20 AMP 20 AMP...
  • Page 11 Indoor Unit Installation (Cont) Terminal Board Diagram NOTE: Power Connection cable is provided in the installation kit (sold separately). If the cable is not of sufficient length, it will be necessary to purchase cable for this purpose. Do not splice cable.
  • Page 12 Indoor Unit Installation (Cont) Prepare refrigeration Lines • Refrigeration Lines and wiring can be routed from the indoor unit several different ways using the cut-out access pieces on the back of the unit. • Bend the refrigeration lines carefully to the position needed to align with the drilled piping hole. Hang Indoor Unit •...
  • Page 13: Outdoor Unit Installation

    Outdoor unit Installation Connect Refrigeration Lines to Bundled Lines from Indoor Unit • Use standard A/C practices to attach the connection pipes to the proper pipes of the bundled lines coming through the wall from the indoor unit. • Tighten the flare nut of the connection pipes using a spanner and torque wrench.
  • Page 14 Outdoor Unit Installation (Cont) Position Outdoor unit • Review page 5 for assistance in selecting location for outdoor unit. • Make sure unit is positioned solidly and level on its foundation. Use leveling feet if necessary. • If possible affix unit to foundation using proper hardware. Connect refrigeration lines to Outdoor Unit •...
  • Page 15: Testing

    Testing Notes • Installation MUST be complete prior to testing. • System MUST be tested prior to operation. Leakage Test • Use standard A/C practices to properly check refrigeration tubes and connections for any leaks prior to system start up. Air Purging and Pressure Test •...
  • Page 16: Test Operation

    Testing (Cont) Test operation Before test operation • Do not switch on power before installation is complete. AUTO • Verify that all electrical connections are connected properly. TEST • Verify that valves of the line set have been opened. • Remove all construction materials such as boxes, packaging, etc from STO P operating area of the units.
  • Page 17 Testing (Cont) IF UNIT FAILS TO OPERATE PROPERLY ISSUE CHECK Verify that Red "Power" light is illuminated. Verify that line voltage is present between terminals 1 and 3 of indoor unit. Turn unit on with remote. (you should hear a "Beep" from indoor unit). Allow Unit will not operate 3-4 min.
  • Page 18: Warranty

    WARRANTY SEA BREEZE AIR warrants the accompanying split air conditioner or heat pump system to be free of defects in material and workmanship for the applications specified in the operation manual and installation manual for a period of one (1) year on parts and five (5) years on compressor, valid from the date of original retail purchase in the United States or Canada.
  • Page 19: Specifications

    MINI-SPLIT SPECIFICATIONS Model 9A23YGX 12A23YGX 12A23ZGX 18A23ZGX COOLING COOLING COOLING COOLING Function Rated Voltage 115V 115V 208-230V 208V-230 V Rated Frequency 60HZ 60HZ 60HZ 60HZ Total Capacity (BTU/Hr) 9000 12000 12000 18000 SEER Power Input (W) 1610 Rated Input (W)
  • Page 20: Troubleshooting Chart

    Mini-Split Error Codes ERROR EXPLANATION YELLOW GREEN NOTES CODE High Pressure protect Inside Anti-Freeze Protect Low Pressure Protect Compressor Discharge protect 6 sec Pause before Flash Sequence low pressure over current protect indoor-outdoor communication Error Mode conflict high Temp protect cold wind protect AC Voltage Low No Indoor motor feedback...
