ReChargX™ RX211 Instructions
For use in the Canon 116 series toner cartridges
The Canon 116 Series toner cartridges are most
frequently found in the Canon imageCLASS
MF8050Cn, MF 8030Cn, i-SENSYS LBP-5050, LBP
5050n and all other machines using the same
"underlying" engine.
These toner cartridges are quite easy to refill
using our ReChargX™ RX211 Premium Print
Toner Refill Kits.
Within these ReChargX™ RX211 Premium Print
Toner Refill Kit instructions we will be adding new
toner, emptying the waste hopper and replacing
the toner cartridge reset chip.
Note: We will be working with the Canon 116
Black cartridge throughout the instructions.
These instructions apply to all four cartridges
within this series (Black, Cyan, Magenta, Yellow).
Step 1: Orient the Toner Cartridge
Orient the cartridge on your work surface so the
cartridge handle is toward your chest and the
reset chip is on the left side, as shown by the
red circle in figure 1.
Step 2: Cover the Imaging Drum
Rotate the cartridge on your work surface so
the toner cartridge drum is toward the ceiling;
tape a piece of paper along the front edge of the
cartridge (figure 2a).
Fold the paper over the imaging drum and
tape the other side to the edge of the toner
cartridge (figures 2b and 2c).
TonerRefillKits.com
Mon - Fri 8am - 5pm ET © 1995-2011 ReChargX™, EmptyX, TonerRefillKits and TonerRefillKits.com, the TonerRefillKits logo, the
800.527.3712 or 352.343.7533 ReChargX™ and EmptyX logos are trademarks owned by TonerRefillkits, LLC. All rights reserved.
Figure 1: The Canon 116 Black toner cartridge
Figure 2a: Tape a piece of paper along the front edge of
the toner cartridge
Figure 2b: Fold the paper over the imaging drum
Figure 2c: Tape the paper over the imaging drum
