Getting Familiar With the controlCARD

4 Getting Familiar With the controlCARD

4.1 F280039C controlCARD Features

• F280039C Microcontroller – High-performance C2000 microcontroller is located on the controlCARD.
• 120-pin HSEC8 Edge Card Interface – Allows for compatibility with all of C2000's 180-pin controlCARD-
based application kits and controlCARDs. Compatibility with 100-pin controlCARDs can be accomplished
using the TMDSADAP180TO100 adapter card (sold separately).
• Built-in Isolated JTAG Emulation – An XDS110 emulator provides a convenient interface to Code
Composer Studio ™ without additional hardware. Flipping a switch allows an external JTAG emulator to be
used.
• Built-in Isolated Power Supply – Passes the 5-V supply from the USB-C connector through an isolation
barrier. Allows for the controlCARD to be completed powered and operated from the USB-C connector. The
F280039C is fully isolated from the USB port.
• Automatic Power Supply Switch – The controlCARD automatically switches to external 5-V power when
present. No additional configuration is required.
• Connectivity – The controlCARD contains connectors that allow the user to experiment with isolated
universal asynchronous receiver/transmitter (UART)/SCI with the F280039C MCU.
• Key Signal Breakout – Most GPIO, analog-to-digital converter (ADC), and other key signals routed to hard
gold connector fingers.
• Robust Power Supply Filtering – Single 5-V input supply powers an on-card 3.3-V LDO. All MCU inputs are
then decoupled using LC filters near the device.
• ADC Clamping – ADC inputs are clamped by protection diodes.
• Anti-Aliasing Filters – Noise filters (small RC filters) can be easily added on ADC input pins.

4.2 Assumed Operating Conditions

This kit is assumed to run at standard room conditions. Standard ambient temperature and pressure (SATP) with
moderate-to-low humidity is assumed.

4.3 Using the controlCARD

In order for the controlCARD to operate, the controlCARD's MCU must be powered. This is can be done through
the USB-C connector on the controlCARD or by inputting 5 V through the HSEC connector via an accompanying
baseboard. For example, if using a TMDSHSECDOCK docking station baseboard, 5-V DC should be input into
the docking station's J1 or J17. Then, S1 needs to be toggled to the appropriate position.
Based on the way the controlCARD is used, additional hardware settings will be necessary (see
When the controlCARD is used in a high-voltage setup, it is the user's responsibility to confirm that
the voltages and isolation requirements are identified and understood prior to energizing the board
or simulation. When energized, the controlCARD or components connected to the controlCARD
should not be touched. Furthermore, the capacitor C7:A should be removed to minimize the
possibility of leakage current flowing across the isolation barrier of the controlCARD.
S1:A
J1:A
4 TMS320F280039C controlCARD Information Guide
WARNING

Table 4-1. Emulator Switch Selections

Debug Using CCS and the On-
Card XDS110 Emulator
Position 1: ON (left)
Connect a USB-C cable between
J1:A and your computer.
In CCS, use this target
configuration: TMS320F280039C
device with an XDS110 emulator.
Copyright © 2022 Texas Instruments Incorporated
Debug Using CCS and an
External Emulator via the
Baseboard
Position 1: OFF (right)
---
SPRUIZ4B – MAY 2021 – REVISED JUNE 2022
www.ti.com
Table 4-1).
Standalone (Boot From FLASH
or Other Boot Mode)
Position 1: OFF (right)
---
