Heated Glass Overshelves
This manual contains important safety information
concerning the maintenance, use and operation of this
product. Failure to follow the instructions contained in this
manual may result in serious injury. If you're unable to
understand the contents of this manual, please bring it to
the attention of your supervisor. Do not operate this
equipment unless you have read and understood the
contents of this manual.
GLO-RAY
GR3 & GR3L Series
Installation &
Operating Manual
I&W #07.05.175.00
®
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso y
operación de este producto. Cualquier falla en el
seguimiento de las instrucciones contenidas en este
manual puede resultar en un serio daño. Si usted no
puede entender el contenido de este manual por
favor pregunte a su supervisor. No opere este
equipo al menos que haya leído y comprendido el
contenido de este manual.
Advertisement
Table of Contents
Related Manuals for Hatco GR3-27
Summary of Contents for Hatco GR3-27
- Page 1 Heated Glass Overshelves GR3 & GR3L Series Operating Manual This manual contains important safety information concerning the maintenance, use and operation of this product. Failure to follow the instructions contained in this manual may result in serious injury. If you’re unable to understand the contents of this manual, please bring it to the attention of your supervisor.
-
Page 2: Table Of Contents
NOTICE signifies the possibility of equipment or property damage only. Hatco Glo-Ray Heated Glass Overshelves are a product of extensive research and field testing. The materials used were selected for maximum durability, attractive appearance and optimum performance. -
Page 3: Important Safety Information
Some aftermarket or generic replacement parts do not have the characteristics that will allow them to operate safely in Hatco equipment. It is essential to use Hatco Replacement Parts when repairing Hatco equipment. Failure to... - Page 4 Form No. GR3M-0807 Damage to countertop material such as Corian generated from Hatco equipment is not covered Recommended counters. For other surfaces, verify that the material is suitable for temperature up to 180°F (82°C).
-
Page 5: Model Description
Standard wattage units may be used where there is an additional bottom source of heat, such as the Hatco Heated Base Overshelves GRS, GRSB, GRSBF, and GRSR. High wattage units are for use in installations where no bottom heat source is present. -
Page 6: Specifications
SPECIFICATIONS ELECTRICAL REQUIREMENTS Units are supplied from the factory equipped with a 3' (914 mm) flexible electrical conduit connection to the remote control box. ELECTRICAL RATING CHART – GR3 MODELS Model Voltage GR3-29 GR3H-29 GR3-35 GR3H-35 GR3-41 GR3H-41 ELECTRICAL RATING CHART – GR3L MODELS Model Voltage GR3L-29... -
Page 7: Installation
NOTICE Damage to countertop material such as Corian and similar products caused by heat generated from Hatco equipment is not covered under the Hatco warranty. Recommended for use over metallic counters. For other surfaces, verify that the material is suitable for temperature up to 180°F (82°C). -
Page 8: Mounting The Unit
Do not overtighten. Use of excessive force when tightening mounting countertop. NOTE: Hatco recommends a qualified electrician connect the appropriate electrical power source to Remote SPECIFICATIONS, WIRING DIAGRAM, or the unit identification plate for specific model watt and amp ratings. - Page 9 INSTALLATION REMOTE MOUNTED CONTROL BOX (RMB) Remote mounted control box should be installed by a qualified electrician. NOTE: When mounting the remote mounted control box insure space is available to access the GFCI reset button. NOTICE The Remote Mounted Control Box must be installed outside of the heat zone.
-
Page 10: Operation
(See Figure 7.) To reset the “GFCI” push the reset button in. If the “GFCI” continues to trip, contact your local Authorized Hatco Service Agency. ON/OFF Switch Heated Glass... -
Page 11: Maintenance
Some aftermarket or generic replacement parts characteristics that will allow them to operate safely in Hatco equipment. It is essential to use Hatco Replacement Parts when repairing Hatco equipment. Failure to use Hatco Replacement Parts may subject operators of the equipment to hazardous electrical voltage, resulting in electrical shock or burn. -
Page 12: Accessories
ACCESSORIES BREATH PROTECTOR(S) Accessory breath protector(s) are available from the factory. Refer to Figure 8 and follow these steps to install them. 1. Remove protective paper from acrylic surfaces. 2. Loosen 3 screws from underside of shelf. Slide mounting bracket into position with studs facing to the front and down. -
Page 13: Hatco Limited Warranty
Hatco reserves the right to accept or reject any such claim in whole or in part. Hatco will not accept the return of any Product without prior written approval from Hatco, and all such approved returns shall be made at Buyer’s sole expense. - Page 14 NOTES Form No. GR3M-0807...
- Page 15 NOTES Form No. GR3M-0807...
-
Page 16: Authorized Parts Distributors
Flanders GCS Service Indianapolis 317-545-9655 P.O. Box 340500, Milwaukee, WI 53234-0500 U.S.A. Parts & Service Fax (800) 690-2966 Printed in U.S.A. August 2007 HATCO AUTHORIZED PARTS DISTRIBUTORS NEW YORK Acme American Repairs, Inc. 319-323-1823 Brooklyn Alpro Service Co. 515-262-9308 Brooklyn...
