Table 6: Physical Data
Component
Nominal Tonnage
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu)
ARI net capacity (Btu)
EER
SEER
Nominal CFM
System power (KW)
Refrigerant type
Refrigerant charge (lb-oz)
System 1
ARI HEATING PERFORMANCE
47°F Capacity Rating (MBH)
System Power KW/COP
17°F Capacity Rating (MBH)
System Power KW/COP
HSPF BTU/Watts-hr
DIMENSIONS (inches)
Length
Width
Height
OPERATING WT. (lbs.)
COMPRESSORS
Type
Quantity
CONDENSER COIL DATA
Face area (Sq. Ft.)
Rows
Fins per inch
Tube diameter (in.)
Circuitry Type
Refrigerant Control
EVAPORATOR COIL DATA
Face area (Sq. Ft.)
Rows
Fins per inch
Tube diameter
Circuitry Type
Refrigerant control
CONDENSER FAN DATA
Quantity
Fan diameter (Inch)
Type
Drive type
No. speeds
Number of motors
Motor HP each
RPM
Nominal total CFM
DIRECT DRIVE EVAP FAN DATA
Quantity
Fan diameter (Inch)
Type
Drive type
No. speeds
Number of motors
Motor HP each
RPM
Frame size
14
Models
PHP024 PHP030 PHP036
2.0 2.5 3.0
25160 29700 37000
24660 29000 36000
11.95 11.5 11.3
13 13 13
900 1000 1150
2060 2500 3200
R-22 R-22 R-22
10-4 10-8 10-8
22400 25900 32100
1760/3.70 2100/3.60 2780/3.40
10500 12900 17300
1490/2.10 1770/2.15 2410/2.10
7.7 7.7 7.7
47-1/4 47-1/4 47-1/4
32-13/16 32-13/16 32-13/16
30-11/16 30-11/16 30-11/16
342 347 350
Recip Recip Recip
1 1 1
11.28 11.28 11.28
2 2 2
15 15 15
3/8 3/8 3/8
Intertwined Intertwined Intertwined Intertwined Intertwined Intertwined
TXV TXV TXV
4.67 4.67 4.67
4 4 4
13 13 13
3/8 3/8 3/8
Intertwined Intertwined Intertwined Intertwined Intertwined Intertwined
Orifice Orifice Orifice
1 1 1
20 20 20
Prop Prop Prop
Direct Direct Direct
1 1 1
1 1 1
1/4 1/4 1/4
850 850 1100
2500 2500 2850
1 1 1
10 x 7 10 x 7 10 x 7
Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
Direct Direct Direct
5 5 5
1 1 1
1/2 1/2 1/2
1100 1100 1100
48 48 48
PHP042 PHP048 PHP060
3.5 4.0 5.0
45800 50600 55700
44700 49300 53600
11.9 12.2 11.15
13 13 13
1400 1500 1750
3740 4030 4820
R-22 R-22 R-22
11-8 11-8 11-8
39600 43900 50000
3420/3.40 3750/3.45 4580/3.25
19900 23600 29000
2835/2.05 3400/2.05 3980/2.10
7.7 7.7 7.7
57-9/16 57-9/16 57-9/16
32-13/16 32-13/16 32-13/16
34-11/16 34-11/16 34-11/16
372 382 390
Recip Scroll Scroll
1 1 1
16 16 16
2 2 2
15 15 15
3/8 3/8 3/8
TXV TXV TXV
5.44 5.44 5.44
4 4 4
13 13 13
3/8 3/8 3/8
Orifice Orifice Orifice
1 1 1
22 22 22
Prop Prop Prop
Direct Direct Direct
1 1 1
1 1 1
1/3 1/3 1/3
1100 1100 1100
3200 3200 3200
1 1 1
11 x 10 11 x 10 11 x 10
Direct Direct Direct
5 5 5
1 1 1
1 1 1
1100 1100 1100
48 48 48
