Opera Relieve Overlay Instructions Manual page 13

15. Product Specifications
System Name
Power Unit (Air Pump) Model
Mattress Dimension
Number of Air Cells
Power Control Unit Dimension
Material
Power Input
Power Consumption
Power Control Unit Weight
Fuse Rating
Power Cord
Operating & Transportation & Storage
Conditions
IEC/EN Test Standards
Maximum Weight Capacity
RELIEVE Overlay Mattress System
SR303
2000x900x130mm (5" depth)
16 Cells
260x220x90mm
Power Unit_Plastic Case rated UL 94V- 0
Mattress Cell – 100 % nylon with TPU
lamination
Coverlet – Quilted nylontaffeta backing
220- 240Vac, 50Hz, 0.05A
Normal Operation: Max 6W
2.5 kgs
T1A 250V
Class II Type B, double insulated
IPX0, do not immerse power unit in any
liquid or spray any liquids directly on the
power unit.
This system is not AP/APG Protected.
Continuous operation
H05VV-F or H05VVH2-F,
2 x Min. 0.75mm 2
Temperature:5°C~40°C
Humidity:15%~60%
Atmospheric Pressure:700~1060hPA
Safety: IEC/EN 60601- 1_v3.0
EMC: IEC/EN 60601- 1- 2_v3
150kg
12
