Technical Specifications

Category
CPU, Memory
Firmware
Reset Circuit
Serial Interface
Serial Line Formats
Modem Control
Flow Control
Programmable I/O
Network Interface
Compatibility
Protocols Supported
LEDs
Management
Security
Internal Web Server
Temperature
Warranty
Included Software
EMI Compliance
xPico® 110 Embedded Device Server Integration Guide

Table 4-3 xPico 110 Technical Specification

Description
Lantronix DSTni-EX 186 CPU, 256-Kbyte zero wait state SRAM, 512-
Kbyte flash, 16-Kbyte boot ROM
Upgradeable via TFTP and serial port
Internal 200ms power-up reset pulse. Power-drop reset triggered at 2.6V.
External reset input causes an internal 200ms reset.
CMOS (Asynchronous) 3.3V-level signals
Rate is software selectable: 300 bps to 921600 bps
Data bits: 7 or 8 Stop bits: 1 or 2 Parity: odd, even, none
DTR/DCD, CTS, RTS <- Serial 1 only
Serial 1: XON/XOFF (software), CTS/RTS (hardware)
Serial 2: XON/XOFF (software)
16 PIO pins (software selectable), sink or source 4mA max.
10/100Mbps Ethernet, requires external magnetics and RJ45
Ethernet: Version 2.0/IEEE 802.3 (electrical), Ethernet II frame type
ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP, BOOTP, TFTP, Auto
IP, SMTP, and HTTP
Link, Activity, Link Speed, Duplex, System Status logic level outputs
Internal web server, SNMP (read only) Serial login, Telnet login
Password protection, locking features, optional Rijndael 256-bit encryption
Serves static Web pages and Java applets
Storage capacity: 384 Kbytes
Operating range:
-40°C to +85°C (-40°F to 185°F)
For details on the Lantronix warranty policy, go to our web site at
www.lantronix.com/support/warranty.
Windows 98/NT/2000/XP-based Lantronix® DeviceInstaller™
configuration software and Windows based Com Port Redirector
See A:Compliance.
4: Specifications
29
