HKTS 6 HOME THEATER SPEAKER SYSTEM Safety Information Introduction Included Speaker Placement Color-Coding System Mounting Options Speaker Connections Operation Volume Troubleshooting Specifications TABLE OF CONTENTS...
Read First! Important Safety Precautions! CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To prevent electric shock, do not use this (polarized) plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure.
While sophisticated electronics and state-of- the-art speaker components are hard at work within the HKTS 6 to make all of this happen, hookup and operation are simple. Color-keyed cables and connections and simple controls make the HKTS 6 easy to use.
Color-Coding System The HKTS 6 uses the channel color-coding system established by the Consumer Electronics Association to make setting up your home theater speaker system as easy as possible. Your system includes a set of colored stickers that may be placed near...
MOUNTING OPTIONS Satellites and Surrounds The satellite speakers may be placed on a shelf. They may be wall-mounted using the supplied brackets. On optional stands (FSTS1). MOUNTING OPTIONS Wall-Mounting Attach bracket to wall. If possible, position the speakers so that the mounting screws used connect directly to a wooden wall stud.
AC power source. The HKTS 6 should not be connected to an AC power source until all speaker wire connections have been made.
Page 8
SPEAKER CONNECTIONS (cont.) Use the supplied RCA-type patch cord to connect the line-level SUB or LFE output on your receiver or amplifier to the SUB input on the SUB-TS6 subwoofer. Connect the satellite and center speakers to the corresponding speaker terminals on your receiver or amplifier.
Standby mode, depend- ing on whether or not a signal is being sent to the HKTS 6 by your receiver or surround processor, and provided that the Auto/On switch ™ is moved to the left so that it is in the “Auto”...
TROUBLESHOOTING SYMPTOM SOLUTION If there is no sound from • Check that receiver/amplifier is on and a source is playing. • Check that the powered subwoofer is plugged in and its Power switch ¡ is switched on to the “ • ” position. any of the speakers: •...
1.1 lb/0.5kg All features and specifications are subject to change without notice. Harman Kardon and Power for the Digital Revolution are registered trademarks of Harman Kardon, Inc. Trademarks of Dolby Laboratories. DTS is a registered trademark of Digital Theater Systems, Inc.
