- Page 1 HKTS 60BQ/230 Home Theater Speaker System User Guide English Designed to Entertain. ™...
-
Page 2: Important Safety Instructions
ThaT may be of sufficienT magniTude To consTiTuTe a risk of elecTric shock To persons. see marking on back of producT. Harman Kardon® HKTS 60 Typographical Conventions We have employed certain conventions to help you use this manual: – (number in a circle) – Indicates a rear-panel control or connection on the illustration of the HKTS200SUB subwoofer ... -
Page 3: Description And Features
(or preamp/processor), amplifier and other devices are correct. In addition, a few minutes spent learning the functions of the various controls will enable you to take advantage of all the power and refinement the HKTS 60 is able to deliver. - Page 4 HKTS200SUB Rear-Panel Connections Use this control to adjust the HKTS200SUB’s volume. Turn Subwoofer Level Control: clockwise to increase the volume; turn counterclockwise to decrease the volume. Set this switch to ON to enhance the HKTS200SUB’s low- Bass Boost Switch: frequency performance.
-
Page 5: Speaker Placement
Speaker Placement Color-Coding System The HKTS 60 use the channel color-coding system established by the CEA to make setting up your home theater speaker system as easy as possible. The HKTS 60 systems include speaker wires with color bands on each end. - Page 6 NOTE: If you’re running the speaker wire through the wall you can bring it out directly behind the bracket location and insert it through the bottom opening in the wall portion of the wall-mount, as shown in the illustration. This will keep the wire completely hidden from view once the installation is complete.
-
Page 7: Connecting Satellite Speakers With Supplied Wall-Mount Brackets
Most electronics manufacturers, including Harman Kardon, use red to denote the ( + ) terminal and black for the ( – ) terminal. Newer Harman Kardon receivers conform to the CEA standard and therefore use a color other than red to denote the ( + ) terminal for some speaker positions. - Page 8 Left Front Front Left Speaker Cable (White Bands) – FRONT SURROUND + – RIGHT LEFT + – + – Receiver Surround Left Speaker Cable (Blue Bands) – Left Surround Connecting the Subwoofer to a Receiver or Preamp/Processor With a Dedicated Subwoofer Output Use this installation method for receivers and preamp/processors that have a dedicated subwoofer output with low-pass filtering (also called bass management).
- Page 9 Left Front Front Left Speaker Cable (White Bands) – FRONT SURROUND + – – RIGHT LEFT + – + – – – Receiver Surround Left Speaker Cable (Blue Bands) – Left Surround Connecting the Subwoofer to a Receiver or Preamp/Processor With Line Outputs Use this installation method for receivers and preamp/processors that do not have a dedicated subwoofer output, but do have preamp-level (volume-controlled) line outputs.
- Page 10 FRONT + – + – + – Trigger Cable (Black Ends) Connecting to a Trigger Voltage Source If your preamp/processor or another audio/video component has a trigger voltage connection that supplies between 3 and 30V (AC or DC), connect it to the HKTS200SUB’s .
-
Page 11: Operation
Operation Turning the Subwoofer On and Off Set the HKTS200SUB’s Power Switch to the ON position. If the is set to AUTO, the HKTS200SUB will • Power On Mode Switch automatically turn itself on when it receives an audio signal, and it will go into standby mode when it has received no audio signal for 15 minutes. -
Page 12: Specifications
© 2009 Harman International Industries, Incorporated. All rights reserved. Features, specifications and appearance are subject to change without notice. Harman Kardon is a trademark of Harman International Industries, Incorporated, registered in the United States and/or other countries. Designed to Entertain is a trademark of Harman International Industries, Incorporated.
