Harman Kardon HKTS 2 Owner's Manual

Owners manual
Hide thumbs Also See for HKTS 2:
Table of Contents

Advertisement

Quick Links

See also: Service Manual

SPECIFICATIONS

HKTS 2 System
Frequency Response
35Hz – 20kHz (–6dB)
Satellites
Recommended Power
10 – 50 watts
Impedance
8 ohms nominal
Sensitivity
86dB @ 1 watt/1 meter
Tweeter
One 1/2" dome, video-shielded
Midrange
One 3" driver, video-shielded
Dimensions (H x W x D)
4-5/8" x 3-1/8" x 3-3/4"
117mm x 79mm x 93mm
Weight
1.1 lb/0.5kg
Refinements may be made on occasion to existing products without notice,
but will always meet or exceed original specifications unless otherwise stated.
* Trademarks of Dolby Laboratories.
DTS is a registered trademark of Digital Theater Systems, Inc.
Center
Recommended Power
10 – 50 watts
Impedance
8 ohms nominal
Sensitivity
86dB @ 1 watt/1 meter
Tweeter
One 1/2" dome, video-shielded
Midrange
Dual 3" drivers, video-shielded
Dimensions (H x W x D)
3-1/2" x 7-5/8" x 3-3/4"
89mm x 194mm x 93mm
Weight
1.89 lb/0.86kg
Subwoofer
Amplifier
100 watts RMS
Bass
10" woofer, bass-reflex enclosure
Dimensions (H x W x D)
18-1/4" x 15-3/4" x 16-3/4"
464mm x 400mm x 425mm
Weight
35.8 lb/16.2kg
250 Crossways Park Drive, Woodbury, New York 11797
1-800/422-8027 (USA only) Fax: 516/682-3523
© 2000 Harman Kardon, Incorporated
Printed 9/00
Part No. ai5083

Advertisement

Table of Contents
loading

Related Manuals for Harman Kardon HKTS 2

Summary of Contents for Harman Kardon HKTS 2

  • Page 1: Specifications

    117mm x 79mm x 93mm Weight 1.1 lb/0.5kg Refinements may be made on occasion to existing products without notice, but will always meet or exceed original specifications unless otherwise stated. * Trademarks of Dolby Laboratories. DTS is a registered trademark of Digital Theater Systems, Inc.
  • Page 2 HKTS 2 Home-Theater Speaker System OWNER’S MANUAL ® Power for the digital revolution. ™...

  • Page 3: Table Of Contents

    Safety Information Introduction Included Speaker Placement Mounting Options Speaker Connections Speaker-Level Connection Guide Dolby* Pro Logic* (Non-Digital) – Speaker Level Dolby Pro Logic (Non-Digital) – Line Level Dolby Digital or DTS ® (or other Digital Surround Mode) Connection Operation Volume...
  • Page 4 RISK OF ELECTRIC SHOCK only from the type of power source indicated on the cles, as this can result in a risk of fire or electric DO NOT OPEN marking label. If you are not sure of the type of shock.

  • Page 5: Introduction

    HKTS 2 to make all of this mount brackets for the four satellites; and • Both line- and speaker-level inputs enable happen, hookup and operation are simple.

  • Page 6: Speaker Placement

    The front speakers should be placed the same distance from each other as they are the subwoofer is mostly omnidirectional, and this speaker may be placed in a con- from the listening position. They should be venient location in the room. However, the...

  • Page 7: Mounting Options

    On shelves. Attach plate to wall. The brackets should be placed, if possible, so that the screws will fasten into a wooden wall stud. If that is not possible, use properly selected wall anchors. The customer is responsible for proper...

  • Page 8: Speaker Connections

    Harman Kardon, use red to denote the (+) terminal and black for the (–) terminal. The (+) lead of the speaker wire is noted with a stripe. It is important to connect both speakers identically: (+) on the speaker to (+) on the amplifier and (–) on the speaker...

  • Page 9: Dolby* Pro Logic* (Non-Digital) – Speaker Level

    – Subwoofer woofer that are marked “Speaker-Level High Level Output” to the corresponding terminals on the back of your front left and right speakers. Connect your receiver or amplifier’s center, – and left and right surround-speaker Speaker-Level terminals to the corresponding terminals on...

  • Page 10: Dolby Pro Logic (Non-Digital) – Line Level

    Connect each speaker to the corresponding speaker terminals on your receiver or amplifier. Dolby Digital or DTS (or other Digital Surround Mode) Connection USE THIS INSTALLATION METHOD FOR DOLBY DIGITAL, DTS OR OTHER DIGITAL RECEIVER...

  • Page 11: Operation

    OPERATION Move the Master Power switch (marked turn red. When the subwoofer senses an If you will be away from home for an “Power” ¡) to the “ • ” (On) position to audio signal, it will automatically turn itself extended period of time, or if the sub- use the subwoofer.

  • Page 12: Troubleshooting

    “ • ” position. • If more than one pair of main speakers is • Check all wires and connections between being used, check the minimum impedance receiver/amplifier and speakers. Make sure requirements of your receiver/amplifier.
