Page 2
Fax: (214) 744-2401 excellent care of our customers. Email: info@teamxray.com Email: xray@rcamerica.com You can join thousands of XRAY fans and enthusiasts in our online community at: www.teamxray.com FAILURE TO FOLLOW THESE INSTRUCTIONS WILL BE CONSIDERED AS ABUSE AND/OR NEGLECT. SAFETY PRECAUTIONS WARNING: This product contains a chemical known to the state of California to for maximum performance.
Page 3
XRAY does not pay nor refund shipping on any component sent to XRAY or Part or parts missing from this kit must be reported within 30 days of purchase. No its distributors for warranty.
Page 4
Special Tool for turnbuckles, nuts (HUDY #181090) Tweezers Caster Clip Remover (#107612 - HUDY EXCLUSIVE Limited Edition) Scissors (HUDY #188990) Reamer (#107602 - HUDY EXCLUSIVE Limited Edition) Professional Multi Tool (HUDY #183011) Flywheel/Clutch Multi-Tool (HUDY #182010) Pinion Tool Set (XRAY #339901)
Page 5
NOT INCLUDED To ensure that you always have access to the most up-to-date version of the XRAY Set-up Book, XRAY will now be offering only the digital online version at our Website at www.teamxray.com. By offering this online version instead of including a hardcopy printed version in kits, you will always be assured of having the most up-to-date version.
Page 6
GRAPHITE GEAR DIFF BEVEL & SATELLITE GEARS (2+4) HUDY AIR VAC – VACUUM PUMP - ON-ROAD #335100 #335180 XRAY MULTI DIFFERENTIAL - ONE-WAY - SOLID - SET XRAY SUPERLIGHT SOLID AXLE SET - HUDY SPRING STEEL™ 335000 FRONT GEAR DIFFERENTIAL - SET...
Page 7
1. FRONT GEAR DIFFERENTIAL & SOLID AXLE 962051 ➊ S 5x10x0.2 ➋ STEP DETAIL CUTAWAY VIEW ➎ DETAIL ➍ 964050 S 5x15x0.3 ➌ ➎ ➏ 972050 980210 Use tweezers to insert pin. O 5x2 P 2x10 300.000cSt Silicone oil Fill differential up to the top of the diff pins.
Page 8
1. FRONT GEAR DIFFERENTIAL & SOLID AXLE 971240 903258 O 24x0.7 SFH M2.5x8 After disassembling the differential, the large O-ring may have an increased size and may be more difficult to re-install. We recommend either replacing the O-ring with a new one or carefully re-inserting the old O-ring in the diff cover.
Page 10
1. REAR GEAR DIFFERENTIAL 962051 S 5x10x0.2 ➋ ➊ DETAIL STEP DETAIL ➎ 964050 ➍ DETAIL S 5x15x0.3 ➏ ➌ 972050 O 5x2 ➎ 980210 Use tweezers to insert pin. P 2x10 60.000cSt Silicone oil Fill differential up to the top of the diff pins.
Page 11
1. REAR GEAR DIFFERENTIAL Push down Wait approx. 5min 964031 S 3.5x10x0.2 Rotate #104002 HUDY AIR VAC – VACUUM PUMP #335081 ALU DIFFERENTIAL PIN - HARDCOATED (2) GEAR DIFF ADJUSTMENT 971240 O 24x0.7 After disassembling the differential, the large O-ring may have an increased size and may be more difficult to re-install.
Page 13
2. REAR SUSPENSION NOTE ORIENTATION 903306 SFH M3x6 NOTE ORIENTATION 903308 SFH M3x8 NOTE ORIENTATION 940508 BB 5x8x2.5 BEARING WITH BLUE COVERS REAR ARMS 901308 SB M3x8 1.3mm 1.3mm 2.5mm 2.5mm REAR SUSPENSION ARMS #333110 MEDIUM OPTION #333111 HARD INCLUDED #333111-G GRAPHITE OPTION REAR DOWNSTOP...
Page 14
2. REAR SUSPENSION 303123-K SHIM 3x6x2 902308 SH M3x8 903306 SFH M3x6 INITIAL SETTING NOTE ORIENTATION Composite eccentric bushings INITIAL SETTING It is extremely important that the arms move freely on the pivot pins. If they do not, use the #107633 HUDY Arm Reamer to slightly resize the holes in the arms.
Page 15
2. REAR SUSPENSION NOTE ORIENTATION DETAIL 902306 3x6mm SH M3x6 3x8mm 902308 SH M3x8 3x6mm 3x8mm 902308 SH M3x8 6mm THREAD DETAIL Install the pivot balls with Professional Multi Tool (HUDY #183011). approx. 26mm...
Page 17
2. REAR SUSPENSION CENTER DETAIL 901302 3x3mm SB M3x2.5 901303 SB M3x3 3x2.5mm Set the bar into the center, remove the play in the bushings, and tighten the set-screws fully. VIEW 3x2.5mm If the sides still do not move at the same time, When the bars are set, verify that both sides move at the same adjust the length of the time.
Page 18
2. REAR SUSPENSION BALL JOINT WRENCH (HUDY #181110). 303241 Use ball joints WITH DOT. BALL 5.8 10.2mm 90° angle difference between the ball joints. Install the pivot balls with Professional Multi Tool (HUDY #183011). REAR CAMBER ADJUSTMENT Ensure that both suspension assemblies move freely.
Page 19
2. REAR SUSPENSION 8.0mm Roughen steel plates with sandpaper before gluing SLS pads. DETAIL 960030 N M3 STEEL STEEL We recommend gluing the brake pads #372176 to the steel pads, however there is no SPRING 4.0 COILS 3.6x6x0.5mm performance difference between glued C=1.5 - GOLD (SOFT) &...
Page 20
2. REAR SUSPENSION #335801-O BELT PULLEY 20T ➋ LOW FRICTION COMPOSITE BELT PULLEY SET - GRAPHITE BELT PULLEY 20T - 2-SPEED CENTER BELT PULLEY 18T - 2-SPEED SIDE 965070 BELT PULLEY 19T - MID-CENTER BELT PULLEY 25T - MID-SIDE BELT PULLEY 26T - MID-SIDE ➊...
Page 22
3. REAR TRANSMISSION SHIFT-POINT SCREW ➎ 901303 SHOE-GAP SET-SCREW ➊ SB M3x3 ➍ Set-screws must NOT protrude. 908260 ➋ SCH M2.5x10 Top of screw head should be level with hole bottom edge. ➌ 983404 NOTE RP 4x4 ORIENTATION ➋ Set-screws must Do not overtighten gap-setting set-screws.
Page 23
4. FRONT SUSPENSION 332212-H 902308 302080 332733 337222 332039 362316 902306 332018 332743 903308 332039 302080 903308 #335432 902308 335430 903305 LOW FRICTION DRIVE BELT FRONT 332711 362316 5.0 x 186 MM 337211 332133 903305 332070 901306 332113 FRONT SUSPENSION ARMS 335000 #332112 MEDIUM...
Page 24
4. FRONT SUSPENSION 901410 SB M4x10 NOTE ORIENTATION DETAIL 902312 SH M3x12 DETAIL 2.7mm 903308 NOTE SFH M3x8 ORIENTATION 901308 SB M3x8 6mm THREAD Install the pivot balls with Professional 26mm Multi Tool (HUDY #183011). IMPORTANT! The position of the front arm directly influences the steering Ackermann (angle of the steering REARWARD ARM POSITION FORWARD ARM POSITION linkages).
Page 25
4. FRONT SUSPENSION NOTE ORIENTATION Both bushings must be in same position. #335432 LOW FRICTION DRIVE BELT FRONT 5.0 x 186 MM NOTE ORIENTATION ➊ ➋ 941016 BB 10x16x4 BEARING OIL ➌ ➋ ➊ NOTE ORIENTATION Both bushings must be in same position.
Page 26
4. FRONT SUSPENSION FRONT UPPER ARMS 901306 #332135 GRAPHITE OPTION SB M3x6 #332134 SOFT OPTION #332133 HARD INCLUDED #332132 MEDIUM OPTION ➊ ➍ Composite eccentric bushings ➍ ➎ INITIAL SETTING ➌ ➊ ➋ NOTE ORIENTATION Composite eccentric bushings STEP DETAIL ➎...
Page 27
4. FRONT SUSPENSION #332290 GRAPHITE EXTENSION FOR STEERING BLOCK (2) 902308 SH M3x8 MARKED "L" NOTE ORIENTATION Optional graphite steering arms are available. They give more flex and front traction, but they are more fragile. ➊ ➎ DETAIL THREADLOCK 901302 SB M3x2.5 STEP DETAIL...
Page 28
4. FRONT SUSPENSION FRONT ANTI-ROLL BARS COLLARS BEARING WITH STEEL COVERS #332479 1.8mm OPTION 930508 #332480 2.0mm OPTION BB 5x8x2.5 #333443-L + 343483-K INCLUDED #332482 2.2mm INCLUDED #332484 2.4mm OPTION #333442-L + 343484-K #332486 2.6mm OPTION #333442-L + 343482-K BEARING OIL DETAIL NOTE 901302...
Page 29
5. FRONT TRANSMISSION #335443 LOW FRICTION DRIVE BELT SIDE 4.5 X 396 MM 303075 336234 950508 950508 903308 336271 903306 303126-K 333072 336234 930508 903306 902320 903308 336250 903308 335441 965050 335800 335859 940613 335724 962060 335790 335790 981212 940613 335885 903308 335886...
Page 30
5. FRONT TRANSMISSION NOTE ORIENTATION BEARING OIL 940613 BEARING OIL BB 6x13x5 #335801-O LOW FRICTION COMPOSITE BELT PULLEY SET - GRAPHITE BELT PULLEY 19T ➏ BELT PULLEY 20T - 2-SPEED CENTER 962060 SHIM 6x8x0.5 BELT PULLEY 18T - 2-SPEED SIDE 6x8x0.5mm BELT PULLEY 19T - MID-CENTER ➌...
Page 31
5. FRONT TRANSMISSION 903306 SFH M3x6 903308 SFH M3x8 3x8mm 3x6mm 3x8mm 3x8mm NOTE ORIENTATION 903306 SFH M3x6 DETAIL 303126-K SHIM 3x6x5 NOTE ORIENTATION ➊ BEARING WITH STEEL COVERS 902320 SH M3x20 ➋ TO ADJUST THE BELT TENSIONER 1. Loosen upper screw. 930508 BB 5x8x2.5 2.
Page 33
6. STEERING ACKERMANN SETTINGS INITIAL SETTING DETAIL 902308 SH M3x8 There are two different Ackermann inserts labeled AD and CB. NOTE You can insert each of the Ackermann inserts in two different ORIENTATION NOTE orientations which will result in the different Ackermann ORIENTATION settings.
Page 35
7. FUEL TANK & ELECTRONICS NOTE ORIENTATION THREAD THREAD Install the pivot balls with Professional Multi Tool (HUDY #183011). Note the 90° angle difference between the ball joints. 902308 SH M3x8 Use for offset servo adjustment. 3x10mm 902310 SH M3x10 3x8mm Use different servo shims depending on your steering servo.
Page 36
7. FUEL TANK & ELECTRONICS FRONT FLEX GRAPHITE BRACES 3x6mm (DO NOT USE FOR INITIAL SETTING) 902306 SH M3x6 3x8mm 902308 ALTERNATIVE 1 SH M3x8 Front Brace ALTERNATIVE 2 Front Brace Triangle Tighten fully DETAIL DETAIL Attach steering linkage to servo saver. 90°~95°...
Page 37
7. FUEL TANK & ELECTRONICS 902258 SH M2.5x8 3x8mm 902308 SH M3x8 2.5x8mm Use an appropriate receiver battery pack. #336156 BRASS BATTERY PLATE FOR The NT1 accommodates standard 5-cell LIPO BATTERIES-100g - V2 receiver packs or optional micro-size packs. Battery (NOT INCLUDED) #336155 GRAPHITE BATTERY PLATE - V2 Use tape to mount the receiver battery...
Page 38
964073 964074 FX 639700 Manifold 964075 (NOT INCLUDED) FX 639500 Muffler 908310 (NOT INCLUDED) 338720 Screw XRAY FLYWHEEL COLLAR (NOT INCLUDED) #338540 ø7.0mm INCLUDED 338722 #338541 ø6.0mm OPTION #338721 #338713 #338578 903310 CLUTCH SHOE - HIGH-DYNAMIC - RED ALU MONOBLOCK ENGINE MOUNT...
Page 39
(NOT INCLUDED) #338540 ø7.0mm INCLUDED 964073 #338541 ø6.0mm OPTION S 7x10x0.2 Use the flywheel collar that comes with your engine, or use XRAY collars. Shim (for adjusting flywheel distance). 964074 DETAIL S 7x10x0.3 964075 S 7x10x0.5 The flywheel collar must stay inside the flywheel.
Page 40
➊ To tighten the 23T pinion gear use the optional To tighten the 18T pinion gear use the optional #339901 XRAY NT1 Pinion Tool (20~23T; 15~18T). #339901 XRAY NT1 Pinion Tool (20~23T; 15~18T). 2ND PINION GEARS - XCA HARDCOATED 1ST PINION GEARS - XCA HARDCOATED...
Page 41
8. ENGINE & CLUTCH The engine should be installed on the split mounts as follows: STEP 1: Attach lower mounts to chassis. STEP 2: Attach upper mounts to lower mounts. STEP 3: Attach engine to upper mounts. 903310 SFH M3x10 STEP 4: Loosen lower mount screws, adjust gear mesh, and then retighten lower mount screws.
Page 43
9. CARB LINKAGE & BODYMOUNTS 903308 SFH M3x8 960030 N M3 #331216 3x6mm GRAPHITE UPPER HOLDER FOR BUMPER 2.5MM 3x10mm 353381 ALTERNATIVE SHIM 4x7.5x2 COMPOSITE UPPER HOLDER ALTERNATIVE 902306 #331221 GRAPHITE UPPER HOLDER SH M3x6 FOAM BUMPER FOR ANTI-ROLL BAR - HARD - V2 (INITIAL SETTING) 4x7.5x2mm 4x7.5x2mm...
Page 44
9. CARB LINKAGE & BODYMOUNTS 901303 SB M3x3 Thread Do not overtighten screws; pivots must rotate freely. DETAIL 902310 Insert rod through hole in brake SH M3x10 arm. Bend rod to proper shape. 961022 S 2.2 Use appropriate servo arm: K - (23T) H - (24T) F - (25T)
Page 45
O-RING 12.1x1.6 (10) 308316 COMPOSITE SHOCK BALL JOINT - OPEN (4) 972030 SILICONE O-RING 3x2 (10) 308327-K ALU CAP FOR XRAY SHOCK BODY - BLACK (2) 308331 COMPOSITE FRAME SHOCK PARTS 4-STEP - SHORT 338287 SPRING-SET C=4.5 - MEDIUM-MEDIUM HARD (2)
Page 46
10. SHOCK ABSORBERS 970121 O 12.1x1.6 SHOCK OIL Be careful not to cross-thread ➊ the collar on the shock body. ➋ INCORRECT Install the ball joint with Professional Multi Tool (HUDY #183011). CORRECT 1~2mm SHOCK OIL SHOCK FILLING Fully extend the piston rod so the piston is at the ➊...
Page 47
LOWER COLLARS (#308335) C=4.0 LONG SPRINGS STANDARD COLLARS (#308331) #308031-O or #308031-K SPRINGS - SHORT SPRINGS - LONG ALU XRAY SHOCK SPRING RETAINING COLLAR (4) 338182 PROGRESSIVE C=4.0-5.6 OPTION 338281 PROGRESSIVE C=3.7-4.7 OPTION 338183 C=4.6 OPTION 338286 C=3.6 OPTION 338184 C=5.0...
Page 48
FINAL ASSEMBLY 960032 338001-K 309402 902308 309402 960240 309402 902306 960240 338001-K Wheels 960032 (NOT INCLUDED) 309402 BODY CLIP FOR 6MM BODY POST (4) 902306 HEX SCREW SH M3x6 (10) 902308 HEX SCREW SH M3x8 (10) 338001-K ALU SHOCK ABSORBER-SET - BLACK (2) 960032 NUT M3 (10) 960240...
Page 49
FINAL ASSEMBLY 902308 SH M3x8 960032 N M3 (INITIAL POSITION) REAR SHOCKS (LONGER SPRINGS) SHOCK POSITION ADJUSTMENT TIRES NOT INCLUDED 960240 N M4 OPTIONAL #335370 REAR TIRES (WIDE) (NOT INCLUDED) FRONT TIRES (NARROW) (NOT INCLUDED) OPTIONAL #335270 #335270 GRAPHITE AERODYNAMIC DISK - FRONT For improved steering.
Page 50
FINAL ASSEMBLY ALTERNATIVE 1 Fuel tube routed from muffler directly into the fuel tank. Cut 2 pieces of silicone tubing and install as follows: SILICONE TUBING MARKED AS RED SILICONE TUBING MARKED AS BLUE muffler to fueltank cap fuel tank to carburetor ALTERNATIVE 2 Fuel tube routed from muffler into the fuel tank through 2 holders on radio tray.
Page 51
CARB LINKAGE ADJUSTMENT NEUTRAL (IDLE) IDLE ADJUSTMENT SCREW Approx. 0.5mm Do not allow carburetor to close to less than 0.5mm. Turn on transmitter and receiver and set the throttle servo trim to the neutral position. Adjust the idle adjustment screw on the carburetor to open approx. 0.5-1mm. Approx.
Page 52
RC AMERICA, 2030 Century Center Blvd #15, Irving, TX 75062, USA PHONE: 214-744-2400, FAX: 214-744-2401, xray@rcamerica.com...
