    Read carefully and fully understand the instructions before beginning assembly. Make sure you review this entire manual and examine all details carefully. If for some reason you decide the X10 is not what you wanted or expected, do not continue any further.
  • Page 3: Equipment Required

    (here twice) movement EQUIPMENT INCLUDED TOOLS REQUIRED Diff. Grease Allen Wrench 1.5mm Allen Wrench 2.0mm Allen Wrench 2.5mm Socket Driver 5.5mm XRAY Premium (HUDY #111540) (HUDY #112040) (HUDY #112540) (HUDY #170055) (HUDY #106211) Silicone Oil 700cSt (#359270) & Silicone Oil 3000cSt...
  • Page 4 GRAPHITE PARTS PREPARATION PREPARE ALL GRAPHITE PARTS To protect and seal edges of graphite parts, sand edges smooth and then apply CA glue. Fine sandpaper Use fine sandpaper to sand smooth the edges of all graphite parts. Apply CA glue to all edges of the graphite parts.
  • Page 5: Table Of Contents

    371002 X10‘15 CHASSIS - 2.5MM GRAPHITE 372280 KING PIN (2) 375220 FRONT WHEEL AXLE - HUDY SPRING STEEL™ (2) 371050 X10 GRAPHITE 2.5MM MOUNTING PLATE RISERS (2) 372290 ALU SHIM 3.2x4.8x0.5 (4) 377220 FRONT UPPER PIVOT PIN 2x31MM (2) 371061 X10‘15 GRAPHITE 2.5MM ARM MOUNT PLATE 372292 STEEL SHIM 0.2MM - SILVER (2)
  • Page 6 NOTE ORIENTATION 3x12 Marked “L“ STEEL BALL 1+0.5mm CASTER REACTIVE CASTER SETTING 5.2mm 5.2mm = 2.5° COMPOSITE BALL = 5° INITIAL SETTING = 7.5° If the arm does not have enough play, remove the clips Use same bushings in left and right sides. and thin the clips slightly with Make sure that sandpaper.
  • Page 7: C=5.0 -

    ORIENTATION USE XRAY SILICONE OIL LOW traction & bumpy track 0.2mm 10K cSt (#359310 XRAY) The flat of the nut must be PARALLEL to the lower arm. HIGH traction & flat track FRONT RIDE HEIGHT ADJUSTMENT 30K cSt (#359330 XRAY) INITIAL SETTING above upper arm (0.5mm)
  • Page 8 The X10’14 Link has adjustable track-width of the front suspension. There are 3 different bushings 0mm centric (in the kit), 0.5mm eccentric (optional), and 1mm eccentric bushing (optional). Use the same bushing in front and rear and also use the same orientation of the bushing on both right and left side.
  • Page 9: Alu Nut

    378150 DELRIN SIDE LINKAGE SHAFT (2) 960031 ALU NUT M3 (10) 371190 COMPOSITE POD LINK (2) 373544 X10‘15 GR. LINK REAR POD UPPER PLATE 372650 BALL-END 4.2MM THREADED (2) 373582 TAPERED SPRING C=1.4 - GOLD (2) 901308 HEX SCREW SB M3x8 (10)
  • Page 10 Lightly tighten the screws so there is no free play, but do not overtighten otherwise the ball will not move freely. 3x10 3x10 Ensure free, smooth movement without excessive freeplay. DO NOT TIGHTEN FULLY 903306 903310 902306 960031 903310 SFH M3x6 SFH M3x10 SH M3x6 ALU N M3...
  • Page 11 NOTE ORIENTATION DO NOT TIGHTEN FULLY, BALLS MUST TURN FREELY. ASSEMBLED VIEW TIGHTEN FULLY 960031 903314 902258 903306 ALU N M3 SFH M3x14 SH M2.5x8 SFH M3x6...
  • Page 12 NOTE ORIENTATION 0.5mm "CLICK" 306219 901308 960031 903306 902306 306219 902306 960031 SHIM 3x6x2.0 SB M3x8 ALU N M3 SFH M3x6 SH M3x6 SHIM 3x6x3.0 SH M3x6 ALU N M3...
  • Page 13 902308 306219 902306 901304 903306 SH M3x8 SHIM 3x6x3.0 SH M3x6 SB M3x4 SFH M3x6...
  • Page 14 Add oil in each slot of the Derlin™ side shock tubes. NOTE: Add oil only in the slots, not on the whole tube. After assembling the side tubes, check for smooth operation. NOTE: It is very important to re-oil the side tubes, as least once per race day.
  • Page 15: Ball Differential

    STEEL REAR AXLE SHAFT - HUDY SPRING STEEL™ 930130 CARBIDE BALL 3.175MM (12) 963030 CONE WASHER ST 3x8x0.5 (10) 375035 X10 ALU REAR WHEEL HUB - RIGHT 930138 CARBIDE BALL-BEARING AXIAL F3-8 3x8x3.5 375045 X10 ALU REAR WHEEL HUB - LEFT 930230 CERAMIC BALL 3.175MM (12) - OPTION...
  • Page 16 Bearing Oil (HUDY #106230) Use additional shims to widen the rear track-width. Use the same shims on both sides. For initial assembly use 6.4x8.4x1mm shims. Flanged Bearing Oil (HUDY #106230) Flanged The axle must have a VERY small amount of Use these Ride Height Adjusters sideplay.
  • Page 17 3.2mm 3.0mm 8.0mm 7.8mm Diff Grease (HUDY #106211) Diff Grease NOTE (HUDY #106211) ORIENTATION NOTE ORIENTATION Bearing Oil Diff Grease (HUDY #106230) This nut affects the tightness and stiffness of the (HUDY #106211) NOTE rear differential. ORIENTATION Tighten the nut gently so the diff does not slip under power, but do not overtighten or damage Bearing Oil Diff Grease...
  • Page 18: E-Clip 1

    5. SHOCK ABSORBER SHOCK SPRINGS #378090 C=0.9 - BLACK 378050 #378092 C=1.5 - SILVER 378010 #378093 C=1.8 - GOLD 378010 #378094 C=2.1 - BLACK SHOCK OILS #359210 100cSt 378060 378080 #359215 150cSt 965015 #359220 200cSt #359225 250cSt 971022 #359230 300cSt 378030 #359235 350cSt...
  • Page 19 Carefully remove the shock piston from the frame, and remove all excess plastic flash Shock Oil Shock Oil ASSEMBLED VIEW 965015 971022 C 1.5 O 2x2...
  • Page 20 DEFAULT SHOCK SETTING FOR CENTER SHOCK ABSORBER Follow the steps below to set the shock. HALF TIGHTEN TIGHTEN FULLY 100% 700cSt ......3~5x UP &...
  • Page 21 CENTER SHOCK ABSORBER INITIAL SETTING Press the collar FULLY onto the end of the shock shaft and tighten the M3x3 setscrew. For initial setting, thread fully. DOWNSTOP ADJUSTMENT The length of the shock ASSEMBLED VIEW absorber affects the amount of rear downstop. To adjust, thread the ball-joint on or off the threaded post on the bottom spring cap.
  • Page 22: Final Assembly

    BODY CLIP FOR 6MM BODY POST (4) 375390 ALU HEX SCREW M3x8 FOR REAR WHEELS (6) 903310 HEX SCREW SFH M3x10 (10) 371040 X10 GRAPHITE 2.5MM FRONT BUMPER & SHIMS - V2 376255 X10 ALU SERVO MOUNT (2) 903312 HEX SCREW SFH M3x12 (10) 371225...
  • Page 23 STANDARD size servo MID size servo MID size servo STANDARD For basic set-up use For basic set-up use size servo 3x6x2 composite shims. 3x6x2 composite shims. For MID size servo use the For STANDARD size servo use the included #376255 alu servo mounts. optional #306200 alu servo mounts.
  • Page 24 NOTE ORIENTATION Note groove position The bodies for 1/10 pan cars are NOTE available in different lengths. ORIENTATION The bumper position depends Note groove position on the length of the body INITIAL POSITION 3x12 3x12 3x12 902310 981212 903308 903312 960031 ACKERMANN ALU N M3...
  • Page 25 Motor PINION GEARS ALU (Not included) HARDCOATED Pinion #305968 18T / 64P (option) (Not included) #305969 19T / 64P (option) #305970 20T / 64P (option) #305971 21T / 64P (option) #305972 22T / 64P (option) #305973 23T / 64P (option) #305974 24T / 64P (option) #305975 25T / 64P (option) #305976 26T / 64P (option)
  • Page 26 ELECTRONIC CONFIGURATION: ELECTRONIC CONFIGURATION: ELECTRONIC CONFIGURATION: INITIAL POSITION Battery Pack (not included) Battery Pack (not included) Battery Pack (not included) 2S LiPo BATTERY 1S LiPo BATTERY 1S LiPo BATTERY When inserting or removing batteries, When inserting or removing batteries, When inserting or removing batteries, Forward Position Rearward Position remove graphite plate for mounts and...
  • Page 27 To ensure that you always have access to the most up-to-date version of the XRAY Set-up Book, XRAY will now be offering only the digital online version at our Web site at www. teamxray.com. By offering this online version instead of including a hardcopy printed version in kits, you will always be assured of having the most current updated version.
