Bamboo Clothes Rail (Half size)
Assembly Instructions
322/8645
- Please keep for future reference
Dimensions
Width - 45cm
Depth - 45cm
Height - 148.5cm
Important –
Please read these instru ctions ful ly before startin g assembl y
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
Issue 1 - 11/ 12 /2014
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 322/8645
Summary of Contents for Argos 322/8645
- Page 1 Bamboo Clothes Rail (Half size) Assembly Instructions 322/8645 - Please keep for future reference Dimensions Width - 45cm Depth - 45cm Height - 148.5cm Important – Please read these instru ctions ful ly before startin g assembl y If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Pls do not stand or put weight • We do not on the product during assembly, components and tools listed on recommend the this could cause damage.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 0845 640 0800 Please check you have all the parts listed below Bottom Leg x 4 Top Leg x 4 Rail x 1 Small Shelf x 1 Large shelf x 1 P eg x 4 Small Support x 2...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Wooden dowel x 8 Bolt Bolt x 2 (M6 x 30mm) ( M6 x 20mm ) Bolt x 2...
- Page 5 Assembly Instructions Step 1 Building the legs Insert rivet nuts bolts into leg Use Allen key Phillips screwdriver to lock bolts and rivet nuts together. Repeat with the remaining three legs. Step 2 Assembling the leg frames Insert a wooden dowel into each end of small support and large...
- Page 6 Assembly Instructions Step 3 Assemble the rail and shelf to side stretchers Attach rail , small shelf and large shelf one leg frame with bolts as shown. Note: The side of the shelf with mark ‘Down’ is the bottom side. Attach the other leg frame to the assembly with bolts Fasten the bolts...
- Page 7 MAX 10 kg MAX 1 kg MAX 1 kg MAX 10 kg MAX 10 kg If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Argos Ltd MK9 2NW...
