C•SHELL 4X3 ASSEMBLY INSTRUCTIONS
®
I. EQUIPMENT & SUPPLIES REQUIRED
The C•Shell pump series have pump-motor unit gross weights up to 800lbs. It is highly recommended an experienced pump mechanic or millwright
®
perform any assembly or disassembly required. Failing to properly handle and install the pump components may result in damage and will void the
factory warranty. When performing any assembly or disassembly of the pump-end components, please make certain the proper equipment and
supplies required are present for all service and maintenance work.
A. Safety glasses
B. Latex/Rubber Gloves (for working with fasteners, elastomers, lubricants, and greases)
C. Safety Boots with Toe Protection
D. Rags
E. Lint Free Rags (McMaster-Carr p/n:7366T35)
F. Lint free Paper Dry Wipes (McMaster-Carr p/n: 7367T38)
G. Isopropyl Alcohol (McMaster-Carr p/n: 54845T42)
H. Anti-Seize Grease (McMaster-Carr reference p/n:1820K23)
I. Molykote 111 Silicon Based Dielectric Grease (McMaster-Carr reference p/n: 1204K32)
®
J. Socket Wrench Kit (up to 1-13/16" sockets)
K. Torque Wrench kit (up to 100 ft/lbs & up to ¾" driver)
L. 1 Ton Scissor Lift or Cart
M. 1 Ton Chain Hoist
N. 1 Ton Gantry System
0. 12" Adjustable C-Clamp
II. PUMP COMPONENTS IDENTIFICATION
Pump-End Exploded View
Review all components and make certain required items are on hand before performing the assembly steps.
III. PUMP END ASSEMBLY TO MOTOR
Motor Preparation
a. The entire C•Shell pump is built onto the motor, so to begin assembly motor must be firmly secured to a work surface. The feet can be clamped
®
or bolted onto the surface to prevent movement or tipping. The motor's mounting face should hang over the edge of the work surface so there is
no interference during assembly (See Figure 1). A smaller motor is more prone to tipping when the wet end is installed than a larger motor, but
all should be firmly secured.
b. Prepare motor by removing all stickers and wiping off excess lubricant from the shaft. Remove the Square Key (9) and fit the Shaft Sleeve (8)
over the motor shaft. Place the Square Key (9) into the motor shaft keyway along with the Shaft Sleeve (8) and cut the Square Key (9) stock so
that it does not protrude past the shoulder of the Shaft Sleeve (8). (See Figure 7 & 8).
c. Remove Square Key (9) and Shaft Sleeve (8) from shaft. Ensure there is a light application of anti-seize on the motor shaft.
d. Apply a light application of Anti-Seize (Item H) to front motor face/flange.
e. Apply a light application of Anti-Seize (Item H) to shaft.
LIGHTLY LUBRICATE ALL SEAL O-RINGS TO PREVENT DAMAGE & HOLD O-RINGS IN PLACE DURING ASSEMBLY.
PROUDLY MADE
IN THE USA
4X3 GENERAL ASSEMBLY
®
FULL THREAD LENGTH ENGAGEMENT IS REQUIRED FOR ALL FASTENERS.
