MDM SEQUENCE PRIMER Series Installation And Service Manual

INSTALLATION AND SERVICE MANUAL
PLEASE FILL IN FOR FUTURE REFERENCE:
MODEL: ___________________________
SERIAL NUMBER: ____________________
DATE PURCHASED: ___________________
* PLEASE FILL OUT THE WARRANTY REGISTRATION
CARD INCLUDED WITH THIS PRODUCT OR ONLINE
AT: WWW.MDMINC.COM
HORSEPOWER: 1/3, 1/2 (1750 RPM) 2 (3450 RPM)
PRIMER ALPHA: 2" FNPT INLET AND DISCHARGE WITH 2" & 2 1/2" SLIP ADAPTERS
PRIMER CHAMPION: 2" FNPT INLET AND DISCHARGE WITH 2" SLIP ADAPTERS
Model
INLET
DISCHARGE
MAX FLOW (gph)
MAX HEAD (feet)
MAX POWER (watts)
MAX CURRENT (amps)
VOLTS
MOTOR HP
MOTOR TYPE
MOTOR ENCLOSURE
WARNING: Please read completely before you install or operate your new pump. This is an external "out-of-pond" pump.
It is NOT submersible. Do NOT allow this pump to become submerged. Never run dry.
PROUDLY MADE
IN THE USA
XXXXPRMXX
S/N: XXXX-XXXXXX
PRIMER CHAMPION
TYPE: SELF PRIMING CENTRIFUGAL
MOTOR: NEMA 56Y
PRIMER CHAMPION
3700PRM21 4900PRM21 6600PRM24 6800PRM19
2" 2" 2"
2" 2" 2"
3700 4900 6600
21' 21' 24'
228 310 457
2.76 @115V 3.37 @115V 4.61 @115V 3.93 @115V
115/230 115/230 115/230
1/2, 1/3 1/2, 1/3 1/2, 1/3
56Y 56Y 56Y
TEFC TEFC TEFC
Efficiency and Longevity.
PRIMER
®
PRIMER ALPHA
7800PRM24 6300PRM77
2" 2" 2"
2" 2" 2"
6800 7800 6300
19' 24' 77'
369 504 1496
5.02 @115V 8.7 @ 230
115/230 115/230 230 /115
1/2, 1/3 1/2, 1/3 2
56Y 56Y 56Y
TEFC TEFC ODP
PRIMER ALPHA
MATERIAL: GLASS-FILLED POLYPROPYLENE
HARDWARE: STAINLESS STEEL HARDWARE
OPTIONS: SALTWATER SERVICE
ACCESORIES: SWING CHECK VALVES (1.5", 2", 3")
PRIMER POWER
8100PRM81 9300PRM83
2" 2"
2" 2"
8100 9300
81' 83"
1807 2222
9.8 @ 230 11.4 @ 230
230 /115 230 /115
2 2
56Y 56Y
ODP ODP
WWW.MDMINC.COM
© MDM INC.
