Code
A
B
C
D
E
F
G

5.3 AC Connection

Cross-sectional area of cables（mm² ）
Scope
6.0-10.0
Table 5.3 Recommended power grid connecting cable specification
If the grid-connection distance is too far, please select an AC cable with larger
diameter as per the actual condition.
5.3.1 R5-3K~10K-T2-AUS AC side electrical connection
Ground of the inverter. After penetrating the external hex head screw through
1.
OT terminal of the grounding line, screw in the grounding port of inverter
enclosure in clockwise direction and make sure it is screwed up tightly.
RS232 Communication(GPRS/ Wi-Fi /4G)
Table 5.2 Specifications for interface
Recommended value
6.0
5.4 Inverter ground protection
- 26 -
Name
DC Switch
Decompression Valves
DC Input
RS485 Communication
Ground Connection
AC Output
External diameter（mm）
R5
Series
5.3~6.7
