insulated enclosure and make them tight.
7. Connect the positive and negative connectors into positive and negative DC input
terminals of the inverter, a "click" sound should be heard when the contact cable
assembly is seated correctly.
· Before inserting the connector into DC input terminal of the inverter, please make sure that
the DC switch of the inverter is OFF.
· Please use the original H4 terminal to install.
1. Connection port
Figure 5.15 Connect the inverter
NOTICE
- 32 -
R5
Series
