Temperature Regulation; Enabling And Disabling Optional Lighting - Minibar Systems SMARTCUBE SC-40T User Manual

User Manual

Temperature Regulation:

• The operating temperature of the SmartCube is subject to many factors: the correct and level
installation, proper ventilation, the internal product
• The temperature control box is factory set for optimum performance for the SmartCube.
• For cooling adjustment, the temperature control box can be reset by moving the dial on the unit – see
the Temperature Adjustment Diagram below.
• The box is positioned on the back of the SmartCube.
• The cooling cycle has automatic defrost every 24 hours.

Enabling and Disabling Optional Lighting

SmartCube has a standard exterior and interior lighting feature for Flexi and Automated models. The
intensity of the lighting is controlled via the S3 software and can be adjusted from an off position to level
10 as desired. This is a programmable feature set up during the installation of the SmartCubes at the
hotel. Classic model lights are not programmable. If the hotel requires the BLUE LEDs to be switched off,
there is an isolator switch fitted to the PCB at the front of the service tray. It can be set to the off
position.Enabling and Disabling Optional Lighting:
2021
Temperature Adjustment Diagram
The factory setting can be adjusted by rotating the dial.
MAX is for maximum cooling.
load, etc.
MIN
37.4°F/ 3°C
 1
42.8°F/ 6°C
 2
48.2°F/ 9°C
MED
53.6°F/ 12°C
 3
59°F/ 15°C
 4
64.4°F/ 18°C
MAX
71.6°F/ 22°C
Page 15
