- Page 1 PixLite E16-S Mk3 User Manual www.advateklights.com PixLite E16-S Mk3 User Manual V20220819...
-
Page 2: Table Of Contents
7.2 - Sending Ethernet Data 7.3 - Pixel Outputs 7.4 - Button Actions 7.5 - Hardware Test Pattern 7.6 - Operating Refresh Rates 7.7 - sACN Priorities 7.8 - Advatek SHOWTime - 2 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819... - Page 3 9.3 - Electrical Fault Protection 10 - Troubleshooting 10.1 - LED Codes 10.2 - Statistical Monitoring 10.3 - Solutions for Common Issues 10.4 - Other Issues 10.5 - Reset to Factory Defaults 11 - Disclaimer - 3 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819...
-
Page 4: Introduction
2 - Introduction This is the user manual for the PixLite E16-S Mk3 pixel controller. The PixLite E16-S Mk3 is a powerful pixel LED controller built upon Advatek’s 3rd generation PixLite Mk3 processor. At its core, the controller converts sACN, Art- Net and DMX512 protocols from lighting consoles, media servers or computer lighting software into various pixel LED protocols. -
Page 5: Safety Notes
The pixel output connectors shall be used for pixel output connection only. Completely disconnect the supply source during abnormal operation and before making any other connections to the device. Specification and certification markings are located on the side of the device. - 5 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819... -
Page 6: Physical Installation
(not supplied). The screws should be a pan head type, 3mm in thread diameter and at least 15mm long, as shown in Figure 2 below. Figure 2: Controller Assembled to Wall - 6 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819... -
Page 7: Din Rail Mount
1. Align the controller's mounting holes with the outermost mounting holes on each bracket. Using the four supplied M3, 12mm long screws, assemble the controller to the mounting brackets, as shown in Figure 3 below. Figure 3: Controller Assembled to Bracket - 7 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819... - Page 8 2. Align the lower edge of the bracket with the lower edge of the DIN rail (1), and push the controller down so it clicks onto the DIN rail (2), as shown in Figure 4 below. Figure 4: Controller Assembled to DIN Rail - 8 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819...
- Page 9 3. To remove the controller from the DIN rail, pull the controller horizontally, toward its power connector (1) and rotate the controller up and off the rail (2), as shown in Figure 5 below. Figure 5: Removal of Controller from DIN Rail - 9 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819...
-
Page 10: Electrical Connections
Figure 6: Location of Power Input Pixels that are connected to the PixLite E16-S Mk3 cannot be powered through the device itself; any pixels connected must have their power sourced separately from a power supply instead. -
Page 11: Control Data
Figure 7 below. Figure 7: Position of Ethernet 5.3 - Connecting Pixel LEDs A high level wiring diagram for connecting pixel LEDs to a PixLite E16-S Mk3 is shown in Figure 8 below. Refer to Section 7.3 for the specific capacity of a pixel output. -
Page 12: Expanded Mode
This becomes more important as the number of pixels per output increases. - 12 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819... - Page 13 Management Interface Output Pixel Output Pin Name Data Data Data Data etc. The pinout for expanded mode is shown in Figure 10 below. Figure 10: Pixel Output Pinout - Expanded Mode Enabled - 13 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819...
-
Page 14: Aux Port
Ethernet-based data. The Aux port connector is located on the front side of the unit as shown in Figure 11 below. Figure 11: Location and Pinout of the Aux Port - 14 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819... -
Page 15: Network Configuration
Figure 12: Network Layout using a Switch and Router Figure 12 shows a typical network topology for the PixLite E16-S Mk3. The Lighting Control Device could be any source of Ethernet data - e.g. desktop PC, laptop, lighting console, or media server. -
Page 16: Igmp Snooping
PixLite Mk3 devices have. This feature removes the need for IGMP Snooping. This means that operation of the PixLite E16-S Mk3 in the situation described above will require IGMP Snooping, as there is no hardware firewall in place. -
Page 17: Static Ip
This then means that connecting a PixLite E16-S Mk3 directly to a PC typically does not require any IP address configuration - communication will be possible because both devices would generate their own valid AutoIP. While the device has an AutoIP address in use, it continues searching for a DHCP address in the background. - Page 18 Note: The Factory IP is only a temporary setting used to regain connectivity to the device. When the device is reset (powered off and on again), the IP address settings will revert to what is configured in the device. - 18 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819...
-
Page 19: Operation
7.3 - Pixel Outputs Each of the 16 pixel outputs on the PixLite E16-S Mk3 can drive up to 6 universes of data. This allows for a total of up to 96 universes of pixel data to be driven out of the one controller. -
Page 20: Button Actions
Solid Blue White Solid White Outputs will slowly move through a continuous color fade. Color Fade Pressing the TEST button will loop back to the original color cycle test mode. - 20 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819... -
Page 21: Operating Refresh Rates
For this to take place, the PixLite still needs to receive and process each universe, including universes that will be dropped due to a lower priority. Low priority sACN handling with the PixLite E16-S Mk3 will require that the total number of universes being streamed to the controller from all sources combined, for any purpose, should not exceed 100 universes. -
Page 22: Advatek Showtime
SHOWTime ™ also unlocks the ability to create up to 25 powerful triggers and use advanced intensity controls to enable true standalone behavior and enhance live environments. For more information, download the PixLite Mk3 Management Guide here: www.advateklights.com/downloads/user-manuals/pixlite-mk3-management-guide - 22 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819... -
Page 23: Firmware Updates
The controller is capable of having its firmware updated (new software). An update is typically performed to fix problems or to add new features. To perform a firmware update, ensure that you have your PixLite E16-S Mk3 controller connected to the LAN network as per Section 6.1. -
Page 24: Specifications
9 - Specifications 9.1 - Operating Specifications The table below specifies the operating conditions for a PixLite E16-S Mk3 controller. 9.1.1 - Power Parameter Value/Range Units Input Power 5 - 24 V DC Maximum Power Consumption 9.1.2 - Thermal Parameter... -
Page 25: Electrical Fault Protection
DC power lines and data or clock lines on any output, it will not damage the device. The Aux Port is also protected against direct shorts of up to +/- 48V DC. The PixLite E16-S Mk3 is protected against damage from reversed polarity power input. - 25 - www.advateklights.com... -
Page 26: Troubleshooting
10 - Troubleshooting 10.1 - LED Codes There are multiple LEDs on the PixLite E16-S Mk3 that are useful for troubleshooting. The location of each is shown in Figure 15 below. Figure 15: Location of LEDs Please refer to the tables below for condition codes for the multi-color status LED, and the Ethernet port LEDs. -
Page 27: Statistical Monitoring
Many issues that may occur are often due to complications in the network, configuration, or wiring. For this reason, the Management Interface features a statistics page for statistical monitoring and diagnostics. Refer to the PixLite Mk3 Management Guide for more information. - 27 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819... -
Page 28: Solutions For Common Issues
10.5 - Reset to Factory Defaults To reset the controller to its factory default settings, do the following: 1. Ensure the controller is powered up. 2. Hold down the 'Reset' button for 10 seconds. - 28 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819... - Page 29 5. Alternatively, reset to factory defaults via the Management Interface, in the "Configuration" page. Note: This process will reset all configuration parameters to Factory Defaults, including IP Address settings (listed in Section 6.3.4), as well as Security settings. - 29 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819...
-
Page 30: Disclaimer
Conducted Immunity EN 61000-4-6 RoHS 2 + DD (EU) Restriction of Hazardous Substances 2015/863 (RoHS 3) Through testing to the above standards, the PixLite E16-S Mk3 has the certifications and marks listed in the table below. Certification Relevant Country ETL Listing North America and Canada. - Page 31 Art-Net™ Designed by and Copyright Artistic Licence Holdings Ltd. This product has been manufactured by: Advatek Lighting Pty Ltd 16 / 52 Corporate Blvd Bayswater, 3153 VIC, AUSTRALIA - 31 - www.advateklights.com PixLite E16-S Mk3 User Manual V20220819...
