SchwankAir
Installation Manual
SchwankAir 4000-Recessed Series
The air curtains shown herein are licensed to bear the AMCA Seal. The ratings shown are based on tests and
procedures performed in accordance with AMCA Publication 211 and AMCA Publication 311 and comply
with the requirements of the AMCA Certified Ratings Program. The AMCA Certified Ratings Seal applies to
airflow rate, average outlet velocity, outlet velocity uniformity, velocity projection and power rating at free
delivery only.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SchwankAir 4000-Recessed Series and is the answer not in the manual?

Questions and answers

Related Manuals for Schwank SchwankAir 4000-Recessed Series

Summary of Contents for Schwank SchwankAir 4000-Recessed Series

  • Page 1 SchwankAir Installation Manual SchwankAir 4000-Recessed Series The air curtains shown herein are licensed to bear the AMCA Seal. The ratings shown are based on tests and procedures performed in accordance with AMCA Publication 211 and AMCA Publication 311 and comply with the requirements of the AMCA Certified Ratings Program.

  • Page 2: Technical Specification

    Technical Specification Ambient, no heat [IP20] Model Output Airflow* Sound power* Sound Pressure Motor Voltage Amperage Weight [MBH] [CFM] [dB[A]] [dB[A]] power [W] motor [V] motor [A] [lb] 1530 208V1~ AC-VA36-23-R 2150 208V1~ AC-VA60-23-R 3050 1008 208V1~ AC-VA72-23-R 3650 1174 208V1~ AC-VA96-23-R Electrical heat [IP20]...
  • Page 3 Technical Specification Model Nozzle Max Velocity Outlet Velocity Outlet Velocity width x depth [in] at nozzle [fpm] [fpm] Uniformity [%] 38.2x3.1 2943 2679 AC-VA36-23-R 38.2x3.1 2943 2679 AC-VE36-20[48][60] -R 58.5x3.1 2827 2581 AC-VA60-23-R 58.5x3.1 2827 2581 AC-VE60-20[48][60] -R 77.8x3.1 2943 2679 AC-VA72-23-R 77.8x3.1...
  • Page 4 The introduction pages consist mainly of pictures. For translation of the English texts used, see the respective language pages. Les pages de présentation contiennent principalement des images. Pour la traduction des textes en anglais, consultez la page correspondante à la langue souhaitée. schwankgroup.com/schwankair...
  • Page 5 Dimensions E / F / G / H 1 m: 4 x M8 1,5 m: 4 x M8 2 m: 6 x M8 2,5 m: 6-8 x M8 ø29 ø29 ø20 A / B / C / D Dimensions 3.3 ft: 4 x M8 4.9 ft: 4 x M8...
  • Page 6 Mounting on threaded bars outside the unit Top view All 36" Recessed Models Ref [inch] Model 35.36 36” Models 34.04 36” Models 0.80 36" Models ø20 1.16 36" Models ø29 2.84 36" Models ø29 2.24 36" Models 8.72 36" Models 56.00 60"...
  • Page 7 Mounting on threaded bars outside the unit Fig. 1a: Mounting brackets on delivery. For 72" & 96" Models Fig. 1b. Mounting on threaded bars outside the unit. schwankgroup.com/schwankair...
  • Page 8 Mounting on threaded bars outside the unit Top view All 36" Recessed Models ø29 Ref [inch] Model ø20 14.52 36” Models ø29 13.60 36” Models 17.20 36” Models 0.80 36” Models All 60" Recessed Models 1.16 36” Models 2.24 36” Models 11.64 36”...
  • Page 9 Mounting on threaded bars outside the unit 3.3 ft: 4 x M8 4.9 ft: 4 x M8 6.6 ft: 6 x M8 8.2 ft: 6-8 x M8 Fig. 2. Mounting on threaded bars inside the unit. schwankgroup.com/schwankair...
  • Page 10 90° Service hatch Fig. 3: Snap fixings Fig. 4: Controller inside the unit. Fig. 5: Hoses are mounted via cable glands at knockouts to protect the hose and prevent air leakage. schwankgroup.com/schwankair...
  • Page 11 Accessories JC-0706-15/20/3 JC-0755-10/15/20/25 JC-0709-15/20/30 JC-0754-15/20 Ceiling Brackets Intake & Nozzle Extension Kit Vibration Dampeners 3.3ft Threaded Rods Ceiling Bracket Model Air Curtain Models: Quantity included 36” & 60” Models 4 pcs JC-0706-15 72” Models 6 pcs JC-0706-20 96” Models 8 pcs JC-0706-30 Vibration Dampener Model Air Curtain Models:...
  • Page 12 Controller JC-0745-XX JC-0749-XX - 4000 Series Return Water Temp. Sensor JC-0744-XX Controller - Ambient Models Controller Recessed Kit JC-0750-XX - 4000 Series Controller - Heated Models JC-0732 JC-0742-XX RJ12 Cable next to JC-0732-XX Temperature Sensor [Different Lengths Available] JC-0751-XX - 3/4 Plumbing Kit Includes: •...
  • Page 13 Wiring Diagram - SchwankAir 4000 Recessed Series Ambient & Water Heated All Ambient & Water Heated Models [except 36"] Air Curtain PCB Trafo PE L1 L2 208V1~ schwankgroup.com/schwankair...
  • Page 14 Wiring Diagram - SchwankAir 4000 Recessed Series - 36” & 60” Electric Heated 208V Actuator 230VSupply 230V Room schwankgroup.com/schwankair...
  • Page 15 Wiring Diagram - SchwankAir 4000 Recessed Series - 72” & 96” Electric Heated 208V Supply 2 30V Room schwankgroup.com/schwankair...
  • Page 16 Wiring Diagram - SchwankAir 4000 Recessed Series - 36” & 60” Electric Heated 600V A ctuato r 230V S upply 230V R oom schwankgroup.com/schwankair...
  • Page 17 Wiring Diagram - SchwankAir 4000 Recessed Series - 72” & 96” Electric Heated 480V/600V Actuator 230VSupply 230V Room schwankgroup.com/schwankair...
  • Page 18 Replacement parts list SchwankAir 4000R Series - Ambient Item Description Part # Model # 4000 Air Curtain Lock Parts [Recessed] JC-0543-XX AC-VA36-23-R AC-VA60-23-R AC-VA72-23-R AC-VA96-23-R 4000 Air Curtain Washer [Recessed] JC-0645-XX AC-VA36-23-R AC-VA60-23-R AC-VA72-23-R AC-VA96-23-R 4000 Air Curtain Lock Pin [Recessed] JC-0646-XX AC-VA36-23-R AC-VA60-23-R...
  • Page 19 4000 Air Curtain Inspection Casing 36” [Recessed] JC-0647-10 AC-VA36-23-R 4000 Air Curtain Inspection Casing 60” [Recessed] JC-0647-15 AC-VA60-23-R 4000 Air Curtain Inspection Casing 72” [Recessed] JC-0647-20 AC-VA72-23-R 4000 Air Curtain Inspection Casing 96” [Recessed] JC-0647-25 AC-VA96-23-R 4000 Air Curtain Inlet Grill 36” [Recessed] JC-0648-10 AC-VA36-23-R 4000 Air Curtain Inlet Grill 60”...
  • Page 20 Replacement parts list SchwankAir 4000R Series - Electric Item Description Part # Model # 4000 Air Curtain Lock Parts [Recessed] JC-0543-XX AC-VE36-20-R AC-VE36-48-R AC-VE36-60-R AC-VE60-20-R AC-VE60-48-R AC-VE60-60-R AC-VE72-20-R AC-VE72-48-R AC-VE72-60-R schwankgroup.com/schwankair...
  • Page 21 AC-VE96-48-R AC-VE96-60-R 4000 Air Curtain Inlet Grill 36” [Recessed] JC-0648-10 AC-VE36-20-R AC-VE36-48-R AC-VE36-60-R 4000 Air Curtain Inlet Grill 60” [Recessed] JC-0648-15 AC-VE60-20-R AC-VE60-48-R AC-VE60-60-R 4000 Air Curtain Inlet Grill 72” [Recessed] JC-0648-20 AC-VE72-20-R AC-VE72-48-R AC-VE72-60-R 4000 Air Curtain Inlet Grill 96” [Recessed] JC-0648-25 AC-VE96-48-R AC-VE96-60-R...
  • Page 22 AC Thermal Cut Off Electric Heated [Recessed] JC-0529-XX AC-VE36-20-R AC-VE36-48-R AC-VE36-60-R AC-VE60-20-R AC-VE60-48-R AC-VE60-60-R AC-VE72-20-R AC-VE72-48-R AC-VE72-60-R AC-VE96-48-R AC-VE96-60-R 4000 Air Curtain Washer [Recessed] JC-0645-XX AC-VE36-20-R AC-VE36-48-R AC-VE36-60-R AC-VE60-20-R AC-VE60-48-R AC-VE60-60-R AC-VE72-20-R AC-VE72-48-R AC-VE72-60-R AC-VE96-48-R AC-VE96-60-R Internal Temp Sensor for Smart Controller JC-0663-XX AC-VE36-20-R AC-VE36-48-R...
  • Page 23 4000 Air Curtain EC Motor JC-0605-XX AC-VE36-20-R AC-VE36-48-R AC-VE36-60-R AC-VE60-20-R AC-VE60-48-R AC-VE60-60-R AC-VE72-20-R AC-VE72-48-R AC-VE72-60-R AC-VE96-48-R AC-VE96-60-R 4000 Air Curtain Discharge Nozzle 36” JC-0606-10 AC-VE36-20-R AC-VE36-48-R AC-VE36-60-R 4000 Air Curtain Discharge Nozzle 72” JC-0606-15 AC-VE60-20-R AC-VE60-48-R AC-VE60-60-R 4000 Air Curtain Discharge Nozzle 60” JC-0606-20 AC-VE72-20-R AC-VE72-48-R...
  • Page 24 4000 Air Curtain Lock Pin [Recessed] JC-0646-XX AC-VE36-20-R AC-VE36-48-R AC-VE36-60-R AC-VE60-20-R AC-VE60-48-R AC-VE60-60-R AC-VE72-20-R AC-VE72-48-R AC-VE72-60-R AC-VE96-48-R AC-VE96-60-R 4000 Air Curtain Front Cover 36” [Recessed] JC-0649-10 AC-VE36-20-R AC-VE36-48-R AC-VE36-60-R 4000 Air Curtain Front Cover 60” [Recessed] JC-0649-15 AC-VE60-20-R AC-VE60-48-R AC-VE60-60-R 4000 Air Curtain Front Cover 72”...
  • Page 25 Replacement parts list SchwankAir 4000R Series - Hot Water Item Description Part # Model # 4000 Air Curtain Lock Parts [Recessed] JC-0543-XX AC-VW36-23-R AC-VW60-23-R AC-VW72-23-R AC-VW96-23-R 4000 Air Curtain Washer [Recessed] JC-0645-XX AC-VW36-23-R AC-VW60-23-R AC-VW72-23-R AC-VW96-23-R 4000 Air Curtain Lock Pin [Recessed] JC-0646-XX AC-VW36-23-R AC-VW60-23-R...
  • Page 26 4000 Air Curtain Inspection Casing 36” [Recessed] JC-0647-10 AC-VW36-23-R 4000 Air Curtain Inspection Casing 60” [Recessed] JC-0647-15 AC-VW60-23-R 4000 Air Curtain Inspection Casing 72” [Recessed] JC-0647-20 AC-VW72-23-R 4000 Air Curtain Inspection Casing 96” [Recessed] JC-0647-25 AC-VW96-23-R 4000 Air Curtain Inlet Grill 36” [Recessed] JC-0648-10 AC-VW36-23-R 4000 Air Curtain Inlet Grill 60”...
  • Page 27 • Read the safety instructions before performing installation and/or maintenance activities on the unit. • Installation and/or maintenance activities on the unit may only be performed by qualified technical staff. • The unit shall not be installed and used outdoors or in environments that are aggressive, or potentially explosive.
  • Page 28 Installation and operating instructions For the protection of wider doorways, several General Instructions units can be mounted in series alongside each Read these instructions carefully prior to other. Minimum distance from outlet to floor for installation and use. Keep this manual for future electrically heated units is 70.9 in.
  • Page 29 The connections to the heating coil must be Unit with electrical heating equipped with shut off valves to allow trouble- 208V3~/480V3~/600V3~ power supply for heat free removal. Water coil is equipped with a drain and control [*1 *2] should be connected to a and a vent valve.

  • Page 30: Maintenance

    Maintenance Replacing heating elements/heating Since fan motors and other components are package [TE] maintenance-free, no maintenance other than 1. Mark and disconnect the cables to the heating cleaning is necessary. The level of cleaning can elements/package. vary depending on local conditions. Undertake 2.
  • Page 31 For units with a water coil, also check the Safety following: • For all installations of electrically heated • That the water coil is air free. products a residual current circuit breaker 300 • That there is sufficient water flow and pressure. mA for fire protection should be used.
  • Page 32 Consignes de montage et mode d’emploi Généralités Montage Lisez attentivement les présentes consignes Le rideau d'air s'encastre horizontalement dans avant d'installer et d'utiliser l'appareil. Conservez le faux plafond, grille de soufflage vers le bas, ce manuel afin de pouvoir le consulter le plus près possible de l’entrée.
  • Page 33 Le système de régulation est préinstallé dans le Démarrage [TE] rideau d'air à l'aide d'une carte de régulation Lorsque l'unité sert pour la première fois, ou suite intégrée. SIRe est préprogrammé avec des à une longue période d'inactivité, de la fumée raccords rapides.

  • Page 34: Entretien

    Réglage de l'appareil et du débit d'air Entretien La direction et la vitesse du jet d'air doivent Les moteurs du ventilateur et les autres être réglés en tenant compte de la charge sur organes de l'appareil ne nécessitant aucune l’ouverture. Les pressions d'air présentes au niveau maintenance, seul un nettoyage régulier est de l'entrée influent sur le débit d'air, le repoussant nécessaire.

  • Page 35: Dépannage

    Remplacer une résistance/kit de Dépannage chauffage [TE] Si les ventilateurs ne fonctionnent pas ou ne 1. Repérer et débrancher les câbles des éléments/ soufflent pas suffisamment, contrôler les points du kit de chauffage. suivants : 2. Retirer les vis de fixation qui maintiennent les •...
  • Page 36 Sécurité Disjoncteur à courant résiduel [TE] Si l'installation est protégée par un disjoncteur à • Un disjoncteur à courant résiduel de 300 mA courant résiduel, et que ce dernier se déclenche doit être utilisé contre les risques d'incendie à la mise sous tension de l'appareil, le problème dans les installations de produits avec peut être lié...
  • Page 37 Traduction des pages de présentation • Mounting on threaded bars outside the unit. Montage avec tiges filtées à l'extérieur de l'appareil • Top view Vue du dessus • Mounting brackets on delivery Equerres de montage lors de la livraison • Mounting on threaded bars inside the unit.
  • Page 38 Tableaux de dimensionnement • Supply water temperature Température de l'eau d'alimentation • Room temperature Température ambiante • Outlet air temperature*1 Température de l'air de sortie • Water temperature Température de l'eau • Fan position Position ventilateur • Airflow Débit d'air •...
  • Page 39 This warranty gives you specific legal rights. You may also have other rights which vary by jurisdiction. SCHWANK USA, INC. 2 SCHWANK WAY, WAYNESBORO, GEORGIA. 30830 SCHWANK LTD. 5285 BRADCO BLVD.
  • Page 40 SchwankAir 1-877-686-3779 [toll-free] 1-706-554-6191 csr@schwankgroup.com schwankgroup.com/schwankair Canada 2 Schwank Way, 5285 Bradco Blvd., Waynesboro, GA Mississauga, ON 30830 L4W 2A6 schwankgroup.com/schwankair...
