Mazda Highbay BY007P Quick Start Manual

Highbay
BY007P
Please read these instructions carefully before installing this product.
Suggest you keep these instructions in a safe places for future reference.
The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar quali ed person.
The external exible cable or cord of this luminaire cannot be replaced; if the cord is damaged, the luminaire shall be destroyed.
IF IN DOUBT, CONSULT A QUALIFIED ELECTRICIAN.
Description
MAZDA BY007P LED150S/840 PSU WB
MAZDA BY007P LED200S/840 PSU WB

Dimensions

Inrush current
©
HOOK
220V 50Hz
IK06
240V 60Hz
IP68 connector
CCT (K) P (W)
150 270
4000
200 320
Electrical characteristics
Imax（A）
Tref（µs）
Maximum number of luminaires
MCB
B-16A
C-16A
35
Dimensions in mm
D H1
45 100
50 102
150W 200W
3.52 3.28
25.4 26.26
13 10
15 11
Data subject to change without notice
22
23
H
1.65
2.45
