Page 1
Aufbauanleitung / assembly instructions mod. 1580, 1582 & 1590, 1592 & 1595, 1597 Holzfuß, fest (L: 140 & 190 cm) 30 x 10,5 4,5 x 30 4,5 x 45 L = 179 1.Montagematerial. 1. Fitting material. 4,5 x 45 2. Den Oberbau umgedreht auf gepolsterten Montageböcken ablegen.
Page 2
3. Stick the bolts of the table legs into the holes which are shown in the picture above. Fix each bolt with a washer and a nut. Fix the reinforcing plate with 4 screws. 2 / 3 1580, 1582 & 1590, 1592 & 1595, 1597 Holzfuß, fest Änderungsdatum: 12.03.21...
Page 3
5. While turning the table the feet must not touch Fertig. the ground ... 6. … and then put all the 4 table-legs onto the floor synchronistically. Ready. 3 / 3 1580, 1582 & 1590, 1592 & 1595, 1597 Holzfuß, fest Änderungsdatum: 12.03.21...
Page 4
Aufbauanleitung / assembly instructions mod. 1581, 1583 & 1591, 1593 & 1596, 1598 Holzfuß, fest (L: 160 & 220 cm) 30 x 10,5 4,5 x 30 4,5 x 45 L = 179 1.Montagematerial. 1. Fitting material. 4,5 x 45 2. Den Oberbau umgedreht auf gepolsterten Montageböcken ablegen.
Page 5
4,5 x 30 Untere Markierungs- bohrungen nutzen! Use lower makings! 3. Die Bolzen der Tischbeine in die im Bild gezeigten Löcher stecken. Jeden Bolzen mit mit einer Unterlegscheibe und einer Mutter fixieren. 30 x 10,5 Die Schrauben des Verstärkungsblechs in die Markierungsbohrungen der Holzbeine schrauben.
Page 6
4,5 x 45 4. Die Sperrholz-Platte des vormontierten Unterbaus nun wieder an den Oberbau schrauben. Auch die zusätzlichen Spax- Schrauben eindrehen. 4. Screw on the plywood-plate of the pre- assembled table-base to the table top again. Also screw in the additional Spax-screws. 5.
