Aufbauanleitung / assembly instructions mod. 1590 - 1593 & 1595 - 1598 Metallfuß, Frontauszug Bitte diese Aufbauanleitung sorgfältig aufbewahren! Please keep this assembly instructions safe! M6 x 16 30 x 10,5 M10 x 30 M5 x 20 4,5 x 45 L = 179 1.Montagematerial.
Page 2
Please check the distance of the steel-plate to the end of the aluminium frame and adjust it if needed. 2 / 5 1590 - 1593 & 1595 - 1598 Metallfuß, Frontauszug Änderungsdatum: 30.09.21...
Page 3
Fix the plywood-plate with the washers and the screws in the way as shown in the picture. Fix the reinforcing plate with 4 screws. 3 / 5 1590 - 1593 & 1595 - 1598 Metallfuß, Frontauszug Änderungsdatum: 30.09.21...
Page 4
8. While turning the table the feet must not touch Fertig. the ground ... 9. … and then put all the 4 table-legs onto the floor synchronistically. Ready. 4 / 5 1590 - 1593 & 1595 - 1598 Metallfuß, Frontauszug Änderungsdatum: 30.09.21...
Page 5
= Bruchgefahr!!! two black screws must be released. 11. Attention, always fold the right of the extension, never fold the left side = risk of breakage!!! 5 / 5 1590 - 1593 & 1595 - 1598 Metallfuß, Frontauszug Änderungsdatum: 30.09.21...
