Information About The Device - Trotec BS30WP Operating Manual

Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
Note
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Note
Do not use abrasive cleaners or solvents to clean the
device.

Information about the device

Device description
Used in combination with Trotec's MultiMeasure Mobile app the
sound level measuring device permits the measurement of
noise emissions.
In case of individual measurements, the measurement value
display can be refreshed both via the app and by a brief
actuation of the measurement button at the measuring device.
Apart from the hold function, the measuring device can indicate
minimum, maximum and average values and carry out series
measurements.
In the app you can specify MAX and MIN alarm thresholds for all
parameters measured with the device.
The measurement results can be displayed and saved on the
terminal device either numerically or in form of a chart. Then,
the measurement data can be sent in PDF or Excel format.
The app also includes a report generation function, an organiser
function, one for customer management and further analysis
options. Moreover, it is possible to share measurements and
project data with colleagues in another subsidiary. If
MultiMeasure Studio Professional is installed on a PC, you can
even use report templates and ready-made text blocks for
various fields of application to turn the data into professional
reports.
4
Device depiction
1
2
3
No. Designation
1 Measuring sensor
2 LED
3 On / off / measurement button
4 Battery compartment with cover
5 Lock
Technical data
Parameter
Model
Measuring range
Accuracy
Measuring range resolution 0.1 dB
Response time
General technical data
Bluetooth standard
Transmission power
Radio range
Operating temperature
Storage temperature
Power supply
Device switch-off
Protection type
Weight
Dimensions
(length x width x height)
sound level measuring device controlled via smartphone BS30WP
4
5
BS 30 WP
Value
BS30WP
35 to 130 dB(A) (31.5 Hz to 8 kHz)
± 3.5 dB (at 1 kHz and 94 dB)
125 ms
Bluetooth 4.0, Low Energy
3.16 mW (5 dBm)
approx. 10 m
(depending on measuring
environment)
-20 °C to 60 °C / -4 °F to 140 °F
-20 °C to 60 °C / -4 °F to 140 °F
with <80 % RH
non-condensing
3 x 1.5 V batteries, type AAA
after approx. 3 minutes without
active Bluetooth connection
IP40
approx. 180 g (incl. batteries)
110 mm x 30 mm x 20 mm
