WM7003A
Computerized Full-auto
Washing Machine
Please read this manual carefully before using.
Retain it for future reference.
Please check if the power receptacle has good earthing
condition before using to guarantee your safety.
The manufacturer will not take responsibility for those
risks occurred from not obeying this manual.
CONTENTS
Before using
Names of the parts.............the 2nd cover
Safety precautions .............................................1
Installation and adjustment .........................3
Install the water inlet hose............5
Preparation before washing ...............7
Put in the laundries .............................8
Put in the detergent ............................9
Use the operation buttons ...................10
Close the top lid .................................14
Finish washing ...................................14
Disposal after washing .........................15
Trouble shooting..............................16
Packing list.....................................17
Specification................the back cover
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Haier WM7003A
Summary of Contents for Haier WM7003A
-
Page 1: Table Of Contents
WM7003A Computerized Full-auto Washing Machine Please read this manual carefully before using. Retain it for future reference. Please check if the power receptacle has good earthing condition before using to guarantee your safety. The manufacturer will not take responsibility for those risks occurred from not obeying this manual. -
Page 2: Names Of The Parts
Names of the parts Top lid Washbox Control pannel Lint filter fixing Filter cap Water channel Control pannel sheet Pulsator Cabinet Accessories Meaning and description of the symbols Contents marked with that symbol are related to the safety of the product and the personal safety of the users. -
Page 3: Safety Precautions
Safety precautions Please plug the plug on special 220-240V AC receptacle. Be sure to use three phase power receptacle.Ensure the earthing prong of the power receptacle is earth- ed reliably.Use leakage protector if possible. earth Do not bend, stretch, twist, bind the power cord by force, or reformit. Do not press or clamp it with heavy items. -
Page 4: Safety Precautions Safety Precautions
Safety precautions Safety precautions Do not put hand into the rotating tub.It is dangerous even if the rotation speed is slow. Take special care of the children. Keep children away from the washing machine to avoid them climbing on. Do not put any hot or heavy items (such as the kettle with hot water) on the washing machine. -
Page 5: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the mannual. It is very important to your security and correct operating the machine. Install the bottom plate After open the package, please lean the washing machine gently down to soft items (towel cloth, blanket, etc.). -
Page 6: How To Change The Direction Of The Drain Hose
How to change the direction of the drain hose 1.Disassemble the bottom plate. Lean the machine down gently with the front surface facing the ground. Loosen the eight screws by a cross screwdriver. Back Front 2.Pull out the drain hose from the right side groove. Useage the drain hose The drainage shall be smooth with the drain hose. -
Page 7: Install The Water Inlet Hose
Install the water inlet hose Confirm the water faucet water faucet, suitable The exit end face of the faucet It is required that the front end shall be longer than 10mm. The exit end face of the faucet shall be flat and smooth. If not please file it to avoid leakage. Connection between the water inlet hose jointer and the water faucet Use the new water inlet hose provided with the machine to connect to the water faucet.Old hose sets should not be reused. - Page 8 Connection between the water inlet hose and the washer 1.Do not take off the water absorption cushion. Please check if the cushion is dropped or damaged before each usage. If it happens please contact our after-sale department immediately. 2 Put the nut of the water inlet hose on the valve jointer.
-
Page 9: Using Process
1 Preparation before washing Pay attention to followings before washing the laundries Confirm if there's Clear the pocket. special requirement Take out the coins , for the laundries. sand,hairpins etc. a. Check if the laundries are applicable for washing with machine. b. -
Page 10: Put In The Laundries
Using process Using process 2 Put in the laundries The capacity of washing of the machine refer to the largest weight of the standard laundries under dry condition that can be washed in one time. Laundries quantity in one washing cycle shall be lower than the rated capacity. -
Page 11: Put In The Detergent
3 Put in the detergent How to use the whitener Fill water to decided level .Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laundries with colour or pattern as they are prone to lose colour. The whitener shall not touch the laundries directly. -
Page 12: Use The Operation Buttons
4 Use the operation knobsand buttons Description of the function of the knobs and buttons Mode and meaning of the indicators Flashing: indicate the running program On: indicate the program about to run, or indicate the selected mode Flashing rapidly: indicate abnormal condition "WATER LEVEL"... - Page 13 START/PAUSE button After the power is switched on, push it to start the machine During working, push it to pause working. During pause, push it to resume working. START PAUSE PROCESS "RESERVE" button Push this button washing-over time's available from 2 to 24 hours. After select reserve , the light of reserve and surplus will light ,the decimal point will glitter, the rest is dark.
- Page 14 Steps of using the operation buttons and description of the steps Push the "POWER ON/OFF" button to switch on the power. Push the "PROGRAM " button to select the suitable process. After switching on the power, the machine will set to standard program automatically . To select other program, push the "PROGRAM "...
- Page 15 Attention Even there's no water in the tub, the spinning will start after a certain period. Do not use the "JEANS" program for the woollen laundries. Wash the laundries that are prone to lose color separately from other laundries. The pulsator will not rotate unless the water is filled to selected water level. Selection method of the procedure programs Times of pushing Selected procedure...
-
Page 16: Close The Top Lid
After turning on the power , pre-wash program will be selected automatically as initial state .if you wish the washer would have finished work in preset time, push reserve button and select pre-wash program . Refer to the reserve for the selection.(See to page11) "... -
Page 17: Disposal After Washing
Disposal after washing After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Clean the detergent box and set it on the control panel seat. -
Page 18: Trouble Shooting
Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company. Do not repair it by yourself. Phenomenan In pre-wash , the washer stops running, the numeral tube shows E0 The draining does not work, or the speed... -
Page 19: Packing List
Packing list Name User's manual Lint filter Components of the water inlet hose Bottom plate Tapping screws ST4x16-B Computerized Full-auto washing machine Quantity Storage position One Piece Inside the document bag One Piece Inside the document bag One Piece Inside the accessory bag Between the upper cushion of the One Piece washing machine package and the... -
Page 20: Specification
Max water consumption Injection pressure Rated washing power Rated spinning power Weight About Dimension WM7003A 220-240V ~ 50Hz 7.0kg (weight of standard dry cloth) 1/22L 2/27L 3/30L 4/34L 5/38L 6/42L 7/45L 8/49L 9/53L 10/57L About 171L(High water level; Standard program) 0.03MPa~0.78MPa...
