- Page 1 User's manual Full automatic washing machine This manual is for HWM80-68B Please read this manual carefully before using. Retain it for future reference.
- Page 2 Contents Names of the parts Safety precautions Installation and adjustment Usage of the drain hose Installation the water inlet hose Preparation before washing Put in the laundries Add the detergent and softener Use the operation knobs and buttons Close the top lid Finish washing Disposal after washing Answers to question...
-
Page 3: Names Of The Parts
Names of the parts Top lid B Detergent box Control panel Level meter Lint filter(Installed by user) Filter cover Control panel film Front control board Pulsator Cabinet Adjustable foot Meaning and description of the symbols Warning sign Forbidding sign Please check if the power receptacle has good earthing condition before using to guarantee your safety. -
Page 4: Safety Precautions
Safety precautions Please insert the power cord into special receptacle with rated vol- tage.Be sure to use single-phase three pins receptacle.The earthing terminal of the receptacle must be earthed reliably.If possible,please adopt electric leakage protector. Earth If the power cord is bad, to avoid risk it is required to replace it by the technicians of our special shop or the after-sale service department. - Page 5 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items (such as the kettle with hot water ) on the washing machine.
-
Page 6: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the bottom plate After opening the package, please lean the washing machine gently down on soft items (like towel cloth, blanket, etc.). -
Page 7: Usage Of The Drain Hose
Install the lint filter After opening the package, please take out the lint filter from the document bag, install it to the filter cover of inner tub. See to the figure. How to change the direction of the drain hose 1.Dismount the back cover of the washing machine. -
Page 8: Install The Water Inlet Hose
Install the water inlet hose Install the water inlet pipe Water faucet, suitable It is required that the front end shall be longer than 10mm. The outlet end surface of the faucet shall be flat and smooth. If not, please file it smooth to avoid leakage. Connection between the water inlet hose jointer and the water faucet 1.Press the lower end of the lock lever and push down the slider. - Page 9 Connection between the water inlet hose jointer and the water inlet hose 1. Push down the slider. Plug the water inlet hose into the jointer. 2. Hang the lock lever onto the jointer. Release the slider till a click sound is heard. Check the connection between the water inlet hose jointer and the water faucet 1.Swing the hose gently to check if it is fastened stably.
-
Page 10: Preparation Before Washing
1 Preparation before washing Pay attention to followings before washing the laundries Check if Clear the the laundries pocket. Take has special out the coins, requirement sand, hairpins on washing etc. a. Check if the laundries are applicable for washing with machine. b. -
Page 11: Put In The Laundries
2 Put in the laundries 3 Add the detergent and softener Inlet for concentrated washing powder and detergent Detergent box How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laundries with color or pattern as they are prone to lose color. - Page 12 4 Use the operation knobs and buttons a Description of the function of the operation buttons Mode and meaning of the indicator Flash: indicating the running mode On: indicating the mode about to run Flash rapidly: indicating abnormal situation Balance display If the bulb of the level meter is inside the standard circle, I t indicates that the machine is horizontal.
- Page 13 Digitron During operation of programs, it displays the remained time (minute) During reserve procedure, it displays the remained reserve time (in hour) In case of abnormal phenomenon, it displays the abnormal symbol (see to Page 15) FLASH LIGHT SURPLUS(MIN) RESERVE HOURS LATER WATER RESERVE LEVEL...
- Page 14 b Steps of using the operation buttons and description of each step. WATER LEVEL 1 Push the POWER ON/OFF button to switch on the power. 2 Push the program button to select suitable automatic program. After switching on the power, the mach ine will set standard program automatically. To select other automatic program, push the PROGRAM button till the relative indicator is on.
-
Page 15: Close The Top Lid
Procedure selection method Times of pushing the Selected procedure SELECT button WASH - SPIN WASH (the washing liquid remains in the tub) WASH - RINSE (the rinsing liquid remains in the tub) RINSE - SPIN SPIN (spin after drain) SOAK - SPIN Push the SELECT button for 6 times, and it will resume the initial mode. -
Page 16: Disposal After Washing
Disposal after washing After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Please take off the detergent box and wash it with water 1.How to take it off: Pull it upwards slantingly and gently. - Page 17 Trouble-shooting (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
-
Page 18: Packing List
Packing list Name User's manual The end connecting to the washing machine Jointer connecting the water inlet hose to the water faucet The end connecting to the water inlet hose jointer Bottom plate Tapping screws Lint filter Full automatic washing machine Specification Water level/Water quantity (about) Injection pressure...
