Haier XPB56-23S User Manual

Haier twin-tub washing machine user's manual
Hide thumbs

Advertisement

Quick Links

XPB56-23S
Twin-tub Washing Machine
Please read this manual carefully before using.
Retain it for future reference
Please check if the power receptacle has good earthing
condition before using to guarantee your safety.
The manufacturer will not bear the responsibility for
those risks occurred from not obeying this manual.
Contents
Names of the parts.............the 2
Safety precautions ...............................1
Installation and adjustment ..................3
Preparation before washing ................6
The musts in washing .........................7
Usage of the detergent .......................8
Washing sequence ..............................9
Disposal after washing .......................12
Answers to question.....................14
Packing list ......................................16
Specification..............The back cover
cover
nd

Advertisement

loading

  Related Manuals for Haier XPB56-23S

  Summary of Contents for Haier XPB56-23S

  • Page 1: Table Of Contents

    XPB56-23S Twin-tub Washing Machine Please read this manual carefully before using. Retain it for future reference Please check if the power receptacle has good earthing condition before using to guarantee your safety. The manufacturer will not bear the responsibility for those risks occurred from not obeying this manual.
  • Page 2: Before Using

    Names of the parts Water-filling entrance Water selector Wash timer Control panel Overflow filter Quick water-filling entrance Water level adjusting lever Drain hose hanging hole Lint filter(Installed by user) Valve cover Pulsator Wash tub Wash tub cover Drain hose Base frame Accessories Water-filling jointer Water inlet hose...
  • Page 3: Safety Precautions

    Safety precautions Please insert the power cord into special receptacle with rated voltage.Be sure to use single-phase two pins receptacle. The earthing line must be earthed reliably. If possible,please adopt electric leakage protector. Earth If the power cord is bad, to avoid risk it is required to replace it by the technicians of our special shop or the after-sale service department.
  • Page 4 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items ( such as the kettle with hot water ) on the washing machine.
  • Page 5: Installation And Adjustment

    Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Usage of the drain hose The drainage shall be smooth with the drain hose. 1.The height of the drain hose shall be less than 10cm , or the drainage will not be smooth enough and cause...
  • Page 6: How To Change The Direction Of The Drain Hoses

    How to change the direction of the drain hoses Figure 1 indicates the ex factory installation position of the drain hose. Extend the drain hose from the side of spin tub Put soft items on the ground. Lean the machine down gently with the front surface facing the ground.
  • Page 7: Introduction Of The Major Functions

    Introduction of the major function The machine has good comprehensive performance, and nice appearance. For the design on safety and reliability, it adopts the wash shelf, spin shelf and water inlet vessel design, and reduces the unfavorable influence on the electrical component by the vapor.
  • Page 8: Preparation Before Washing

    Preparation before washing Pay attention to followings before washing the laundries Pay attention to followings before washing the laundries Check C l e a r t h e the laundries pocket. Take has special out the coins, requirement sand, hairpins on washing etc.
  • Page 9: The Musts In Washing

    The musts in washing Reference weight of the laundries Working suit up,down cotton,about 1120g Blanket cotton,about 900g Pajamas Shirt cotton,about 300g Undershirt cotton,about 180g The capacity of washing and spinning of the machine refer to the largest weight of the standard laundries under dry condition that can be washed or spinned in one time.
  • Page 10: Usage Of The Detergent

    Usage of the detergent How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laundries with color or pattern as they are prone to lose color. The whitener shall not touch the laundries directly.
  • Page 11: Washing Sequence

    Washing sequence Wash timer Wash selector Water-filling entrance (To set to below 2 minute, (standard current, first set to 5 minute then strong current) turn it back. it can increase the service life of the timer). STRONG STAMDARD WASH SELECTOR WASH TIMER Wash 1.
  • Page 13 Spinning Put the laundries into the spin tub evenly and smoothly. Spin (1) Put the gland in properly. Please put in the gland properly even if the laundries quantity is small. (2) Close the inner and outer cover of the spin tub. (3) Select suitable spin time according to the laundries, and do spinning.
  • Page 17 Spinning Put the laundries into the spin tub evenly and smoothly. Spin (1) Put the gland in properly. Please put in the gland properly even if the laundries quantity is small. Push Gland Push The laundries Proper Proper are slanting (2) Close the inner and outer cover of the spin tub.
  • Page 18: Disposal After Washing

    Disposal after washing After using, please clean the lint and foreign materials of the lint filter and overflow filter in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Cleaning the lint filter The lint filter must be used during washing.
  • Page 19: Cleaning The Overflow Filter

    Cleaning the overflow filter 2. Take off the corrugation pipe. Dismantle the upper part of the corrugation pipe inside overflow filter ( as indicated in Figure 1). 3. Cleaning the overflow filter Clean the lint around the filter and flush with tap water. 4.
  • Page 20: Trouble-Shooting Answers To Question

    Trouble-shooting Answers to question If the laundries fall to the outer side of the spin tub If the laundries fall to the outer side of the spin tub, please take them out immediately. 1.Dismantle As indicated in the figure, push the point marked with "...
  • Page 21 Trouble-shooting Answers to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
  • Page 22: Packing List

    Packing list User's manual Water inlet hose Water-filling jointer Gland Lint filter Twin-tub washing machine One piece One piece One piece One piece One piece One set...
  • Page 23: Specification

    Rated washing capacity kg Rated spinning capacity kg Rated input power W Dimension(mm) Wash pattern Weight kg Injection pressure Twin-tub washing machine XPB56-23S Rated voltage 220 Rated frequency 6 Maximum/43L Medium/36L Minimum/30L Wash 420 Spin 160 L740 W428 H936 New current...

This manual is also suitable for:

Wms663
