Page 1: Service Manual
HAIER Fuzzy Computerized Automatic Washing Machine Service Manual PART # WD-8888-71 HAIER AMERICA TRADING, LLC www.haieramerica.com... -
Page 2: Table Of Contents
Table Of Contents Contents Features Specifications Safety Precaution Warning And Caution Net Dimension Installation And Accessory Parts Parts And Functions Program Diagram Maintenance And Troubleshooting Wiring Diagram... -
Page 3: Features
FEATURES Brand new appearance It adopts full streamline arc model with compact structure, novel and unique. Dual power The unique drive system of "Dual Power" washing machine has applied for the international patent. Basin-shape large pulsator drive system, and the inner wash tub power drive system, make the inner tub rotating with low speed like drum washing machine to reduce the abrasion, and rotating with small angle like agitator washing machine to reduce tangling. -
Page 4: Specifications
SPECIFICATION... -
Page 5: Safety Precaution
SAFETY PRECAUTIONS Please plug the plug on receptacle. In normal usage of the washing machine, the Be sure to use single-phase three pins power plug shall be ready to be pulled or power receptacle. Ensure the earthling plugged with hand. Be sure to pull the plug off prong of the power receptacle is earthed and close the water faucet when encountering reliably. -
Page 6: Warning And Caution
Do not let the machine share one receptacle with other electric appliances. If the power plug is damaged, or the plugging into the receptacle is loose, do not use the plug any more. WARING AND CAUTION Do not put hand into the rotating tub. It is Do not decompose, repair or alter the dangerous even if the rotation speed is slow. - Page 7 The handicapped or children without care To protect your laundries and washing shall not use the machine. machine, please take out all of the coins, buttons, sand, hairpins and other foreign materials before washing. Please keep the lint filter in good condition, Please check if the water faucet is open, and install it to proper position during and if the connection of the water inlet pipe...
-
Page 8: Net Dimension
NET DIMENSION... -
Page 9: Installation And Accessory Parts
INSTALLATION AND ACCESSORY PARTS Install the drain hose • First install the drain hose hook on the parts of outer drain hose component. • Put the drain hose clamp on the outer drain hose, insert the outer drain hose into the joint for it, and then clutch tightly with drain hose clamp. Usage of the drain hose •... - Page 10 5. Check for leaks (1). Swing the water inlet hose gently to confirm if it's suitable. (2). Turn on the water faucets and check for leaks. A small amount of water might enter the washers. You will drain this later. Do not take off the water absorption cushion.
- Page 11 Install the bottom plate After opening the package, please lean the washing machine gently down on soft items like (towel cloth, blanket, etc.). Install the bottom plate to the bottom of the machine with eight screws by a cross screwdriver, then lift the machine up gently.
-
Page 13: Parts And Functions
PARTS AND FUNCTIONS... -
Page 14: Program Diagram
PROGRAM DIAGRAM Detail description of the normal program (rinse/spin 2-in-1) * Indicates that the laundries quantity and cloth character influences the wash time. The soak and wash time do not include the time needed by cloth character detection. The wash time during wash/rinse procedure includes the 30 seconds of balance. Jean program ** The water current relates to the water level. - Page 15 Chemical fiber program ** The water current relates to the water level. Silk program Cotton program Detail description of the woolen program High efficiency program (total 15 minutes) Water inlet to water level 1-- motor rotates clockwise and counterclockwise 0.3s/5s, meanwhile water inlet to 1/2 of set value--set to gentle current, meanwhile water inlet to set value-- wash for 5 min (1.0/1.0 wash for 1 min;...
- Page 16 1.0/0.6 wash for 1 min), and balance for 15s--switch on drain motor, tub and pulsator intermittent act for 10s/15s, operate for 135s-- spin consecutively, the cool water valve is switched on/off for 35s/30s-- spin consecutively, the cool water valve is switched on for 35s--brake after 30s inertia spin the cool water valve performs water inlet for 35s, the motor rotates clockwise and counterclockwise for 0.35s/5s-- spin consecutively, the cool water valve is switched off for 30s-- spin consecutively, the cool water valve is switched on/off for 35s/30s—spin consecutively...
- Page 17 MAINTENACE SERVICE AND TROUBLESHOOTING 1. Trouble and solve method alarm Phenomena The reason How to settle The digitron displays E0. • The top lid is opened during • Close the top lid. reserve procedure. The drainage cannot work, • Is the drain hose put down? •...
- Page 18 The water tap leaks • Is the screw of the jointer of • Fasten the screw of the water inlet hose loose or awry? jointer properly. No water inlet • Is the power plug tightly plugged? • Plug the power plug •...
-
Page 19: Maintenance And Troubleshooting
MAINTENANCE SERVICE AND TROUBLESHOOTING Wash test C2: The remain time digitron displays C2. The medium water level, wash and normal indicator lights are on. After 3 seconds the wash digitron displays 20. The wash digitron flashes. It will execute wash current, and switch off the power automatically after 20 minutes. - Page 21 2. No water filling 3. No rotation in washing (or rotating to one direction only)
- Page 23 4. No draining 5. Keep filling water...
- Page 25 6. No spinning 7. Too much spinning noise...
- Page 27 8. Too much noise in washing...
- Page 28 9. The measured laundry load is inaccurate 10. Break time out...
-
Page 30: Wiring Diagram
WIRING DIAGRAM Actual Circuit Diagram Circuit Diagram...
