VEHICULAR SLIDE GATE OPERATOR
LiftMaster
300 Windsor Drive
Oak Brook, IL 60523
INDUSTRIAL DC
INSTALLATION MANUAL
• THIS PRODUCT MUST BE INSTALLED AND
SERVICED IN ACCORDANCE WITH THIS
MANUAL BY A TRAINED GATE SYSTEMS
TECHNICIAN ONLY.
• This operator is for use on vehicular passage
gates ONLY and not intended for use on
pedestrian passage gates.
• IHSL24UL and INSL24UL are intended
for use in Class II, III, and IV vehicular slide
gate applications.
• Visit LiftMaster.com to locate a professional
installing dealer in your area.
• This gate operator is compatible with myQ
and Security+ 2.0
3.5"
Access installation and technical support
guides or register this product
Access installation and technical support
guides or register this product
3.5"
IHSL24ULTECH
Take a photo of the
1.
camera icon including the
points ( ).
2.
Send it in by texting the photo
2.
to 71403.
P/N: 40-39191-31-C
ARTWORK: 40-39191-31-C
INSL24ULTECH
Rev. Date: 09/14/21
Printing & Finishing:
Box Type: LABEL
Size: See Die
K
202C
Dieline
Colors:
File Name:
accessories.
®
Take a photo of the
1.
camera icon including
the points ( ).
Send it in by texting
2.
the photo to 71403.
PN: 40-39191-31-C
Printout Size
XX%
This printout is for indicating
color breaks only.
Do not use for color matching.
Do not measure for accuracy.
®
