BARRIER ARM GATE OPERATOR
INSTALLATION MANUAL
MODELS
PBG24DCW | PBG24DCG
CBG24DCW | CBG24DCG
IBG24DCW | IBG24DCG
LiftMaster
300 Windsor Drive
Oak Brook, IL 60523
DC Vehicular
THIS PRODUCT MUST BE
INSTALLED AND SERVICED
IN ACCORDANCE WITH THIS
MANUAL BY A TRAINED GATE
SYSTEMS TECHNICIAN ONLY.
•
This operator is for use on
vehicular passage gates ONLY
and not intended for use on
pedestrian passage gates
•
All models are intended
for use in Class I, II, III, and
IV vehicular barrier arm
gate applications.
•
Visit LiftMaster.com to locate
a professional installing
dealer in your area.
•
This gate operator is
compatible with myQ®, myQ®
Smart Facility Access™, and
Security+ 2.0® accessories.
For online troubleshooting and product
information scan QR code, or follow link below:
https://support.partner.liftmaster.com/s/gate-
operators-barrier-gates/techna
Advertisement
Related Manuals for Chamberlain TECHNA PBG24DCW
Summary of Contents for Chamberlain TECHNA PBG24DCW
- Page 1 DC Vehicular BARRIER ARM GATE OPERATOR INSTALLATION MANUAL THIS PRODUCT MUST BE INSTALLED AND SERVICED IN ACCORDANCE WITH THIS MANUAL BY A TRAINED GATE SYSTEMS TECHNICIAN ONLY. • This operator is for use on vehicular passage gates ONLY and not intended for use on pedestrian passage gates •...
- Page 2 Table of Contents Safety Install Warning Signs ........40 Safety Symbol and Signal Word Review.
- Page 3 Safety (continued) Usage Class CLASS I - RESIDENTIAL VEHICULAR GATE OPERATOR A vehicular gate operator (or system) intended for use in garages or parking areas associated with a residence of one to four single families. CLASS II -COMMERCIAL/GENERAL ACCESS VEHICULAR GATE OPERATOR A vehicular gate operator (or system) intended for use in a commercial location or building...
- Page 4 Safety (continued) Safety Installation Information Vehicular gate systems provide convenience and security. Gate systems are comprised of many component parts. The gate operator is only one component. Each gate system is specifically designed for an individual application. Gate operating system designers, trained gate systems technicians/installers, and users must take into account the possible hazards associated with each individual application.
- Page 5 Safety (continued) Role of End Users/Property Owners • Contact a trained gate systems technician to maintain and repair the gate system (end users should never attempt to repair the gate system). • Retain and utilize this installation manual including its maintenance and important safety instructions. •...
- Page 6 Introduction Carton Inventory NOTE: Operator does not include arm. Please see “Operator and Arm Installation Options” on page 12 for arm selection and operator compatibility below. Key (2) Batteries 12 VDC 7AH (2) Operator Front Operator Back Gate Arm Bracket with Harness Moving Barrier Arm Can Cause Serious...
- Page 7 Introduction (continued) Operator Specifications CBG24DCW, CBG24DCG IBG24DCW/IBG24DCG PBG24DCW, PBG24DCG Commercial/Community Parking Operator Industrial Operator Operator Colors Available White, Charcoal Usage Classification Class I, II, III, and IV Maximum Functional Arm 12 feet 14 feet 24 feet Length Open / Close Time 1.9 seconds 2.5 seconds 6 seconds...
- Page 8 Introduction (continued) Top View of Cabinet Footprint 36.63 cm 14.42 in 28.30 cm 11.14 in 23.50 cm 9.25 in 41.20 cm 25.40 cm 25.17 cm 16.22 in 10.00 in 9.91 in 46.32 cm 18.24 in 56.01 cm 22.05 in 42.2 cm 16.61 in 36.37 cm 14.32 in...
- Page 9 Introduction (continued) Networking Specifications Ethernet Compatibility 10 Mbps / 100 Mbps Ethernet Wi-Fi® Compatibility 802.11 b/g/n 2.4 GHz Wi-Fi® Security Operator is compatible with routers using the following security protocols: WPA3- Personal (SAE) (Recommended), WPA2-PSK (AES), WPA2-PSK (TKIP), WPA2 Personal, WPA-PSK (AES), and WPA-PSK (TKIP). Operator is NOT compatible with routers using the following security protocols;...
- Page 10 Installation WARNING • The entrance is for vehicular traffic ONLY. Pedestrians MUST use a separate entrance. • Do not install operator in a manner in which the barrier arm moves within 16 in. (406 mm) of a rigid object in a location up to 6 ft.
- Page 11 Installation (continued) Site Preparation for Safety Devices Every installation is unique. It is the responsibility of the installer to ensure the barrier arm gate operator is installed in a safe manner. If the area surrounding the barrier arm gate operator is expected to have high pedestrian traffic, it is recommended that safety devices, such as Liftmaster photoelectric sensors or wireless edge sensors, be installed at the site.
- Page 12 Installation (continued) CAUTION • To AVOID damaging gas, power • Permanent wiring is to be employed as required by local codes. It is or other underground utility important to ensure proper grounding of the unit. lines, contact underground utility • To avoid creating an entrapment zone, do not install this vehicular locating companies BEFORE barrier arm gate operator in a manner in which the arm moves within 16...
- Page 13 Installation (continued) ARM SWINGAWAY SETUP (OPTIONAL) When using the Arm Swingaway System, the barrier arm swingaway direction can be set up for outward or inward swingaway. NOTE: The Arm Swingaway setup barrier arm can pivot and only swingaway in one direction (outward or inward) at a time, based on the installed option.
