Summary of Contents for SEI FA700100TX
- Page 1 FA700100TX GEL FUEL HURRICANE LANTERN For assistance with assembly contact: Southern Enterprises Inc. Assembly Instruction Customer Service 1-800-633-5096 service@seidal.com www.seidal.com © Southern Enterprises Inc. All Right Reserved.
-
Page 2: Assembly Instruction
FA700100TX GEL FUEL HURRICANE LANTERN Assembly Instruction Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. - Page 3 (10) Bottom Glass (11) Fuel Canister Holder (12) Candle Holder 1 PC 1 PC 1 PC (A) Allen Bolt (B) Allen Bolt (C) Allen Bolt 12 PCS 4 PCS 4 PCS 1/4"x13mm 1/4"x38mm 1/4"x32mm (D) Lock Washer (E) Wrench (F) Glass Pad 20 PCS 1 PC 4 PCS...
- Page 4 FA700100TX GEL FUEL HURRICANE LANTERN Assembly Instruction DANGER PLEASE USE IN WELL VENTILATED AREA The fireplace will have open flames and will generate heat. Make sure to keep all combustible items away from the fireplace when the gel fuel is burning.
- Page 5 Step2: Insert side frame (2) to canister shelf (3), then attach them to leg by using bolt (A) and washer (D) as shown Put adhesive pad (G) on the side glass (8). Every glass use 4pcs adhesive pad. Then insert the side glass (8) into the side frame (2) as shown.
- Page 6 Step 4: Put adhesive pad (G) onto the door glass (9). Every glass use 4pcs adhesive pad. Insert the door glass (9) to the door frame (4). Then attach the stretcher (5) to door frame (4) by using bolt (C) and washer (D) as shown.
- Page 7 Step 6: Put glass pad (F) onto the bottom frame as shown. Then put on bottom glass (10) as shown. Figure 6 Step 7: Remove the fuel canister holders (2, Figure 7) from the fireplace and install one gel fuel canister (1, Figure 7) into each of the holders.
- Page 8 Step 8: Following the instructions on the gel fuel canister, remove the lid (2, Figure 8) from the gel fuel canister (1, Figure 8), and using a long match, light the fuel in each of the canister. Candle holder can be used to extinguish fire.
- Page 9 DANGER PROLONGED USE OF THE GEL FUEL IN THE FIREPLACE WILL CAUSE THE FIREPLACE TO BECOME HOT AND POTENTIALLY CAN CAUSE BURNS IF TOUCHED. BEFORE LIGHTING THE FUEL, MAKE SURE THAT THE PAPER LABEL IS REMOVED FROM EACH OF THE GEL FUEL CANISTERS. USE LONG MATCHES TO LIGHT EACH CANISTER OF FUEL.
- Page 10 We'd love to hear from you! Email us photos of our products in your home at sei@seidal.com we might feature it on our site or use it to model one of our inspirational photos. “PARTS WILL BE SENT IF AVAILABLE FROM SEI” “THIS IS NOT A WARRANTY” Parts Replacement Form...
