SOUTHERN ENTERPRISES INC.
This product has been engineered for easy installation and is
constructed for durability. Please take the time to read through
and follow these assembly instructions.
YOU CAN INSTALL THIS ITEM.
Suggested tools: Flat head screw driver, power drill, ¼" drill bit, 24" level, and a tape measure.
(1) FIREPLACE ASSEMBLY
(4)PLASTIC WALL ANCHOR
HARDWARE LIST
(2) FUEL CANISTER
HOLDER
1 PC
(5) PAN HEAD SCREWS
3PCS
WALL MOUNT FIREPLACE
FA580500TX
(3)CANDLE HOLDER
3 PCS
3PCS
1PC
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SEI FA580500TX
Summary of Contents for SEI FA580500TX
- Page 1 This product has been engineered for easy installation and is constructed for durability. Please take the time to read through and follow these assembly instructions. FA580500TX YOU CAN INSTALL THIS ITEM. Suggested tools: Flat head screw driver, power drill, ¼” drill bit, 24” level, and a tape measure.
- Page 2 INSTALLATION INSTRUCTIONS Please count, identify and compare parts to the hardware and parts list on the preceding page to be sure all parts are present. You will also need a flat head screw driver, drill, ¼” drill bit, tape measure, and a 24” level. If any items are missing, please contact our parts/ service department at 800-633-5096 or in Dallas 972-869-0111 from 9 AM to 4 PM CDT Monday - Friday.
- Page 3 3. Measure the wall and mark the location of the center of each of the three screw mounting holes. See Figure 2. Using the level, make sure that all three marks are level on the wall. 14-1/4" 6-3/8" 7-1/8" Drill three 1/4” holes into wall.
- Page 4 7. Install the fireplace (1, Figure 4) onto the three mounting screws using the mounting holes (2, Figure 4). The proper and secure mounting of the fireplace is when the top edge of each of the mounting holes is resting securely on the mounting screw (3, Figure 4).
- Page 5 NOTICE • Make sure to remove the gel fuel canisters paper label (4, Figure 5) before installing the canister into the holder. • Shake the gel fuel canister before installing it into the canister holder. Figure 5 –Fuel Canister Holder and Gel Fuel Canister 9.
- Page 6 DANGER • PROLONGED USE OF THE GEL FUEL IN THE FIREPLACE WILL CAUSE THE FIREPLACE TO BECOME HOT AND POTENTIALLY CAN CAUSE BURNS IF TOUCHED. • DO NOT BURN MORE THAN THREE CANISTERS OF FUEL AT ONE TIME. • BEFORE LIGHTING THE FUEL, MAKE SURE THAT THE PAPER LABEL IS REMOVED FROM EACH OF THE GEL FUEL CANISTERS.
- Page 7 ANY DAMAGES DUE TO PRODUCT MODIFICATION(S). If this product has been purchased from our retail affiliates more than 9 months ago, we are under no obligation to provide parts or replacement merchandise. Parts will not be available for items arriving fully assembled. FA580500TX Customer Name PARTS...
