Maytronics Dolphin MCC6 User Instructions

Robotic pool cleaner
Hide thumbs Also See for Dolphin MCC6:
Table of Contents

Advertisement

Quick Links

Download this manual
Robotic Pool Cleaner MCC6/MTC6
User Instructions
MCC6
MTC6
8151890

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dolphin MCC6 and is the answer not in the manual?

Questions and answers

Related Manuals for Maytronics Dolphin MCC6

Summary of Contents for Maytronics Dolphin MCC6

  • Page 1 Robotic Pool Cleaner MCC6/MTC6 User Instructions MCC6 MTC6 8151890...

  • Page 2: Table Of Contents

    Robotic Pool Cleaner MCC6/MTC6 User Instructions Contents 1. INTRODUCTION ............... 2 2. SPECIFICATIONS ..............2 3. WARNINGS AND CAUTIONS ........... 2 3.1. Warnings ................2 3.2. Cautions ................2 4. POOL CLEANER PARTS ............3 5. USING THE POOL CLEANER ............ 4 5.1.

  • Page 3: Introduction

    Thank you for purchasing a Maytronics Robotic Pool Cleaner. We are sure that your Maytronics Robotic Pool Cleaner will provide you with reliable, convenient and cost effective pool cleaning. Its reliable filtration in all pool conditions, active brushing, and all-surface climbing brush enhance maximum pool hygiene.

  • Page 4: Pool Cleaner Parts

    4. POOL CLEANER PARTS Robotic Pool Cleaner Model MCC6 Robotic Pool Cleaner Model MTC6 Brushes Combined Brush Combined Brush For rough ceramic For rough ceramic surface and mosiac tiles. surface and mosiac tiles. Optional Brushes Optional Brushes PVC Brush Wonder Brush PVC Brush Wonder Brush For concrete, PVC,...

  • Page 5: Using The Pool Cleaner

    5. USING THE POOL CLEANER The Pool Cleaner is very simple to use. Simply put it into the pool and make sure that it is properly sitting on the floor of the pool. Turn it ON and let it get the job done. 5.1.
  • Page 6 While pushing the button on each Click Click float pull it all the way out. Position the power supply so that it is approximately in the middle of the long side of the pool at a distance of 3.5 m (12 ft). 3.5 m (12 ft) Attach the floating cable to the power supply by inserting it with the notch on the connector (1)

  • Page 7: Putting The Pool Cleaner Into The Pool

    5.2. Putting the Pool Cleaner into the pool Holding the Pool Cleaner upside down in the water gently rock it back and forth with your fingers holding the plastic doors on the bottom lid open to release trapped air. Continue until no more bubbles are released.

  • Page 8: Removing The Pool Cleaner From The Pool

    5.3. Removing the Pool Cleaner from the pool Turn OFF and unplug the power supply CAUTION Using the floating cable, bring the Pool Cleaner to the pool’s edge. Using the handle remove the Pool Cleaner from the pool. DO NOT PULL THE POOL CLEANER FROM THE POOL USING THE CABLE. CAUTION Place the Pool Cleaner on the edge of the pool and let the water drain out.

  • Page 9: Cleaning The Filter Bag Or Cartridges

    6. CLEANING THE FILTER BAG OR CARTRIDGES Depending on the model, your Pool Cleaner may be equipped with a filter bag or cartridges. It is recommended to clean the filter bag or cartridges after each cleaning cycle. 6.1. Removing and cleaning the filter bag Unplug the power supply CAUTION Click...

  • Page 10: Replacing The Filter Bag

    6.2. Replacing the filter bag Put the filter bag over the frame so that the strap is in the middle of the shortest side. Make sure that filter bag is positioned properly on the frame. 6.3. Cleaning the filter cartridges Note: Don’t let the filter cartridges dry out before cleaning.

  • Page 11: Cleaning The Impeller

    Clean the filters with a hose. Insert the filters with the plastic backing facing out. Insert the cartridge unit. In addition to the standard cartridge filters the Pool Cleaner is also supplied with Spring clean-up filters which can be used for the first cleaning of the season or when the pool is unusually dirty.

  • Page 12: Offseason Storage

    Place the impeller cover at an angle so that the notch is on the second ring of the spring. Press down on the impeller cover in the direction of the spring, pushing it into place. Replace the screws. 7. OFFSEASON STORAGE If the Pool Cleaner will not be in use for an extended period, perform the following storage steps: •...

  • Page 13: Troubleshooting

    8. TROUBLESHOOTING If the suggest solutions do not solve the problem contact your dealer Problem Solution Pool Cleaner does not move 1. Check that the power supply is plugged in and turned ON and that the cable is securely connected all the way into the side of the power supply 2.

This manual is also suitable for:

Dolphin mtc6
