CAUTION! Risk of Fire! DO NOT store instruction manuals inside fireplace cavity.
High temperatures could cause a fire.
INSTALLER: Leave this manual with the appliance, not inside the appliance.
CONSUMER: Retain this manual for future reference. Do not store inside the appliance.
NOTICE: DO NOT discard this manual!
Models:
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22
Installation Manual
Installation and Appliance Setup
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and must be installed for
the protection of children and other at-risk
individuals.
Decorative barrier front must be ordered separately at
time of appliance purchase. See Section 3.B.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quartz Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Majestic Quartz Series

Summary of Contents for Majestic Quartz Series

  • Page 1 Decorative barrier front must be ordered separately at gases, unless a certified kit is used. time of appliance purchase. See Section 3.B. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 2: Table Of Contents

    C. Securing and Leveling the Appliance ....40 D. Non-Combustible Material (Factory-Installed) ..41  = Contains updated information. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 3: Installation Standard Work Checklist

    Comments: Further description of the issues, who is responsible (Installer/ Builder/ Other Trades, etc) and corrective action needed _____________________________________________________________________________________ _________________________________________________________________________________________________ Comments Communicated to party responsible ____________________ by ______________________on ___________ (Builder / Gen. Contractor/) (Installer) (Date)  = Contains updated information. 2643-982 4/22 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 4: Product Specific And Important Safety Information

    State of California to cause cancer and reproductive harm. For more information go to: www. P65Warnings.ca.gov. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 5: Requirements For The Commonwealth Of Massachusetts

    VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB- of the installation. STRUCTIONS”. See Gas Connection section for additional Common- wealth of Massachusetts requirements. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 6: Getting Started

    Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. For assistance or additional information, consult a qualified service technician, service agency or your dealer. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 7 Sugges�ons on how to further reduce TV temperatures: Increase “A” dimension. b. Increase “C” dimension, however, increasing “B” dimension beyond maximum recommended typically results in higher temperatures. Figure 2.2 Good Faith TV Guidelines Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 8: Tools And Supplies Needed

    • Improper positioning of the logs/media (as applicable) or the glass assembly. • Installation and/or use of any component part not approved by Hearth & Home Technologies. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 9: Framing And Clearances

    Location Inches Millimeters 1041 36-1/8 30-3/4 15-3/8 32-1/16 15-7/8 21-1/2 6-5/8 37-5/8 2-3/16 3-9/16 6-7/8 26-7/8 33-9/16 37-7/8 39-15/16 1014 9-1/8 8-13/16 16-5/16 Figure 3.1 Appliance Dimensions Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 10: Decorative Barrier Front Dimensions

    Barrier Mesh: Integral to Decorative Barrier Front 33-7/8 24-1/4 35-15/16 1-5/8 2-5/8 30-5/8 32-1/4 QUARTZPLA36IN DBM36 QUARTZPLA36IL Figure 3.2 Decorative Barrier Front Dimensions - DBM36 Decorative Barrier Front Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 11 Barrier Mesh: Integral to Decorative Barrier Front 28-5/8 23-3/16 37-1/16 1-1/4 32-1/4 33-5/8 QUARTZPLA36IN CRD36 QUARTZPLA36IL Figure 3.3 Decorative Barrier Front Dimensions - CRD36 Decorative Barrier Front Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 12: Appliance Location And Clearances To Combustibles

    64-3/8 See Section 45-1/2 64-3/8 16-1/4 48-1/2 68-3/4 16-5/8 7-1/2 QUARTZPLA36IN 10 for Mantel QUARTZPLA36IL 1156 1067 1635 1156 1635 1232 1746 Projections Figure 3.4 Appliance Locations Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 13 **** For installations with vinyl flooring see section 3.E. Figure 3.6 Clearances to Combustibles Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 14: Constructing The Appliance Chase

    Minimum height requirements for an exterior chase on a top- vented appliance are shown in Figure 3.7. Reference Figure 4.5 for additional clearances. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 15: Vinyl Flooring

    110 °F (based on ambient temperature of 70 °F). Consult the manufacturer’s flooring specifications to ensure compatibility. Figure 3.8 Vinyl Flooring Requirements Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 16: Termination Location And Vent Information

    Minimum Height From Roof to Lowest Discharge Opening The pipe is tested to be run inside an enclosed wall. There is no requirement for inspection openings at each joint within the wall. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 17 • Measure horizontal and vertical termination cap clearances as noted in Figure 4.3 and Figure 4.4. H=Measure Horizontal Distances from H V=Measure Vertical Distances from V Figure 4.3 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 18: Vent Terminal Clearances

    12 in. (305 mm)* mum of two sides beneath the floor.) vinyl or composite overhang 42 in. (1067 mm) 42 in. (1067 mm) Figure 4.5 Minimum Clearances for Termination Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 19: Use Of Elbows

    DVP12 8-1/2 DVP24 DVP36 25-1/2 DVP48 1219 DVP6A 3 to 6 76 to 152 2-1/8-4-1/4 54-108 DVP12A 3 to 12 76 to 305 2-1/8-8-1/2 54-216 Figure 4.6 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 20: Use Of Flex Vent (Slp-Flex Series 6-5/8 Inch)

    However, the vent attachment point and the firestop loca- tion are considered to be supports. TERMINATION 3 in. CLEARANCE FLEX-VENT 1 in. CLEARANCE Figure 4.8 Flex Vent Pipe - Generic Fireplace Shown Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 21: Vent Diagrams

    (OUTSIDE MOUNTING SURFACE) Figure 4.10 Measure to Outside Mounting Surface 1/4 in. max. (6 mm) Figure 4.9 Figure 4.11 Measure to Top of Last Section of Pipe Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 22 Fire Risk. • When using SLP-HRC-SS termination cap on top vented fireplaces, a one foot minimum vertical vent section is required before installing first elbow. Figure 4.12 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 23 • When using SLP-HRC-SS termination cap on top vented fireplaces, a one foot minimum vertical vent section is required before installing first elbow. INSTALLED HORIZONTALLY Figure 4.13 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 24 Fire Risk. • When using SLP-HRC-SS termination cap on top vented fireplaces, a one foot minimum vertical vent section is required before installing first elbow. Figure 4.14 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 25 TOP VENT APPLICATION EXHAUST RESTRICTOR REAR VENT APPLICATION EXHAUST RESTRICTOR Figure 4.15 Figure 4.16 Exhaust Restrictor Installation (Top Refractory Panel Removed to Aid in Visual Clarity) Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 26 Maximum= 15 ft. (4.6 m) Maximum = 40 ft. (12.2 m) *No specific restrictions on this value EXCEPT V CANNOT exceed 40 ft. (12.2 m) Figure 4.17 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 27 See Figure 4.8. Maximum = 14 ft. (4.3 m) *No specific restrictions on this value EXCEPT V CANNOT exceed 40 ft. (12.2 m). INSTALLED HORIZONTALLY Figure 4.18 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 28 1.2 m 4 ft. 1.2 m 3-1/2 ft. 1.0 m installation. See Figure 4.8. Maximum= 40 ft. (12.2 m) Note: Use SLP Series components only. Figure 4.19 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 29 90º elbows in a corner installation will affect space require- ments. See Section 3.C. Use of 45º elbow not allowed. Note: Use DVP Series components only. 90-DEGREE ELBOWS Figure 4.21 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 30 6 ft. 1.8 m 13-1/2 ft. 4.1 m Maximum = 7-1/2 ft. (2.3 m) INSTALLED HORIZONTALLY Maximum =13-1/2 ft. (4.1 m) = 40 ft. (12.2 m) Figure 4.23 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 31 610 mm 6-1/2 ft. 2.0 m 3 ft. 914 mm H Maximum = 6-1/2 ft. (2 m) Maximum = 40 ft. (12.2 m) INSTALLED HORIZONTALLY Figure 4.25 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 32 2.3 m 3 ft. 914 mm 7 ft. 2.1 m 14-1/2 ft. 4.4 m Maximum = 7-1/2 ft. (2.3 m) Maximum = 40 ft. (12.2 m) Figure 4.26 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 33 DV-46DVA-GCL adapter and LINK-DV30B CLEARANCE TO COMBUSTIBLES REQUIREMENTS kit. This could result in poor flame appearance, sooting, DV-46DVA-GCL 3 IN. pilot malfunction, or overheating. Exhaust Vent Pipe 5 IN. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 34 3.05 m 0 ft 0 mm Minimum 10 ft 3.05 m Maximum 40 ft 12.2 m 2 ft 610 mm Maximum 40 ft 12.2 m Figure 4.29 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 35: Vent Clearances And Vent Framing

    Top: 2-1/2 in. (64 mm) Bottom: 1/2 in. (13 mm) Sides: 1 in. (25 mm) Figure 5.1 Horizontal Venting Clearances To Combustible Materials Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 36: Wall Penetration Framing/Firestops

    Figure 5.3 Wall Penetration Whenever a non-combustible wall is penetrated, the wall shield firestop is only required on one side and no heat shield is necessary. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 37: Ceiling Firestop/Floor Penetration Framing

    INSTALL ATTIC INSULATION SHIELDS BEFORE OR AFTER INSTALLATION OF VENT SYSTEM CEILING FIRESTOP CEILING FIRESTOP INSTALLED BELOW CEILING INSTALLED ABOVE CEILING Figure 5.5 Installing the Attic Shield Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 38: Appliance Preparation

    The heat shield must remain in the vertical position. 2 SCREWS Figure 6.6 Remove the insulation from the outer vent pipe. Figure 6.3 Replace the two screws as shown. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 39 Use two self-tapping screws to secure Figure 6.9 (Generic Fireplace Shown) Cut the metal gasket to outer wrap. retaining band and fold the sides out. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 40: Prepare For Heat Management

    Figure 6.13 Heat Management Knockout Locations • Optional: Secure the appliance to the floor by inserting two screws through the pilot holes at the bottom of the appliance. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 41: Non-Combustible Material (Factory-Installed)

    Figure 6.14 Proper Positioning and Securing of an Appliance Figure 6.16 Facing Materials Note: Diagonal dimensions (A) and (B) must be within 1/4 inch of each other. Figure 6.15 Positioning the Appliance Squarely Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 42: Venting

    • Only outer pipes need to be sealed. All unit collar, pipe, slip section, elbow and cap outer flues shall be sealed in this manner, unless otherwise stated. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 43 Figure 7.1 High Temperature Silicone Sealant Lances Lances Figure 7.3 Figure 7.2 Note: Make sure that the seams are not aligned to prevent unintentional disconnection. CORRECT INCORRECT Figure 7.4 Seams Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 44 • Only outer pipes need to be sealed. All unit collar, pipe, slip section, elbow and cap outer flues shall be sealed in this manner, unless otherwise stated. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 45: Assemble Slip Sections

    “Assembling Pipe Sections.” NOTICE: If slip section is too long, the inner and outer flues of the slip section can be cut to the desired length. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 46: Secure The Vent Sections

    • SLP ceiling firestops have tabs that may be used to provide vertical support. 120º Figure 7.11 Align and Disassemble Vent Sections Figure 7.8 Securing Vertical Pipe Sections 120º Figure 7.9 Securing Horizontal Pipe Sections Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 47: Vertical Termination Requirements

    Tighten nut and make sure the collar is tight against the pipe section. • Seal around the top of the storm collar. See Figure 7.14. SEAL Figure 7.12 Figure 7.12 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 48: Horizontal Termination Requirements

    • Rest the small leg on the extended heat shield on top of the pipe section to properly space it from the pipe section. Important Notice: Heat shields may not be field constructed. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 49 HRC caps are available. When penetrating a brick wall, a brick extension kit is available for framing the brick. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 50: Electrical Information

    Verify proper operation after servicing. WARNING! Risk of Shock! Replace damaged wire with type 105º C rated wire. Wire must have high temperature insulation. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 51 Ensure it is positioned correctly on the component tray. LED CONTROLLER PLACEMENT TABS IFT-ECM REAR PLACEMENT TAB GUIDE GREEN/WHITE/BLACK WIRES GUIDES IFT-ECM FRONT PLACEMENT TAB Figure 8.2 Electrical Component Tray Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 52: Wiring Requirements

    (PILOT) EMBER LIGHTING NOT USED FOR QUARTZPLA36IN / QUARTZPLA36IL MODELS BLK (GROUND) APPLIANCE 6V DC MODELS. ON/OFF BATTERY PACK CONTROL (OPTIONAL) Figure 8.3 IntelliFire Touch Wiring Diagram Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 53: Gas Information

    Check with your local gas utility to determine proper mm) control valve inlet. orifice size. • If substituting for these components, please consult local codes for compliance. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 54: Air Shutter Setting

    Figure 9.1 Air Shutter Adjustment nut toward the back of the appliance to close the shutter. Pull/Slide the wing nut toward the front of the appliance to open the air shutter. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 55: Burner Identification/Verification

    See Figure 9.2 for burner identification chart. Notch patterns are located on bottom side of burner. QUARTZPLA36IN / QUARTZPLA36IL Figure 9.2 Burner Identification Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 56: Finishing

    Figure 10.2 Finishing Material Installed Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 57: Installing A Television

    TOP OF HOOD OR FIREPLACE OPENING See Dimension V on Appliance Dimension Diagram (Figure 3.1). Figure 10.3 Minimum Vertical and Maximum Horizontal Dimensions of Combustibles Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 58 MINIMUM UNLIMITED FIREPLACE OPENING See Dimension B on Appliance Dimension Diagram (Figure 3.1). Figure 10.5 Combustible Mantel Legs or Wall Projections (Acceptable on one side of opening) Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 59 3-1/2 IN. MIN. 12 IN. MIN. Figure 10.8 Top Vent Non-Combustible Zone Above Appliance Figure 10.7 Rear Vent Non-Combustible Zone Above Appliance Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 60: Decorative Barrier Front Dimensions For Finishing

    DECORATIVE BARRIER FRONT NON-COMBUSTIBLE FINISHING MATERIAL (TOP EDGE) Non-combustible finishing materials 1 in. maximum thick. Stop non-combustible finishing material flush with opening. Figure 10.10 Overlap Fit Door (CRD36) Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 61: Appliance Setup

    Install the refractory kit per the included instructions. BEND TABS TOWARD EMBER TRAY Figure 11.1 Bend Basepan Tabs Figure 11.2 Paint Teco-Sil Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 62: Install The Log Assembly

    See Figure 4. Figure 1 Log Identification LOG PINS EMBERS NOT ALLOWED IN SHADED AREA EMBERS Figure 4 Install Log #2 Figure 2 Log Pin and Glowing Ember Locations Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 63 “right” end will rest on the “left” end of Log #1. See Figure 8. EMBER TRAY TAB EMBER TRAY TAB Figure 6 Install Log #4 Figure 8 Install Log #5 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 64 NOTICE: DO NOT place lava rock on burner. Flame appearance could be affected. LAVA ROCK LAVA ROCK LAVA ROCK LAVA ROCK Figure 10 Install Log #7 Figure 12 Lava Rock Locations 2643-935 Rev. B Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 65: Intellifire Touch ® Control System Setup

    7. The RC400 remote will automatically pair to the appli- (BOTH BOTTOM AND TOP) ance as pre-set at the factory. GLASS ASSEMBLY Figure 11.4 Fixed Glass Assembly Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 66: Install Decorative Barrier Front

    Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one. For more information refer to the instructions supplied with your decorative barrier front. Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 67: Reference Materials

    (508 MM) 6 in. 14 IN. (152 mm) (356 MM) 12 IN. (305 MM) DVP-WS (Wall Shield Firestop) DVP-RDS ROOF DECK INSULATION SHIELD Figure 12.1 DVP Vent Components Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 68 Horizontal Termination Cap DVP-TRAP2 DVP-TRAP1 DVP-TRAPK2 DVP-TRAPK1 DVP-HPC1 DVP-HPC2 Can adjust 2-1/8 in. (4-1/4 to 6-3/8) Can adjust 4-1/8 in. (6-3/8 to 10-1/2) Figure 12.2 DVP Vent Components Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 69 13-7/8 in. 9-1/2 in. (352 mm) (241 mm) 26 in. 660 mm 14 in. (356 mm) DVP-HSM-B DRC-RADIUS Cap Shield Extended Heat Shield Figure 12.3 DVP Vent Components Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 70 High Performance Cap 12 in. 305 mm 7-1/4 in. (184 mm) 12-1/2 in. (318 mm) 5-1/4 in. (133 mm) DVP-TVHW VerticalTermination Cap (Highwind) Figure 12.4 DVP Vent Components Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 71 Only use listed decorative termination caps/shrouds with Hearth & Home Technologies approved venting systems. This applies to both DVP and SLP venting systems. Decorative Terminations Caps/Shrouds DTO134 DTO146 DTS134 DTS146 LDS33 LDS46 LDS-BV Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 72 Option B: IFT-RC150, IFT-ACM, IFT-WFM and an IntelliFire App that can be downloaded from the app store. These accessories are purchased separately from the PVV-SLP. Contact your dealer to order. Figure 12.6 PVV-SLP Vent Components Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 73 16-11/16 IN. (346 mm) 424 mm (424 mm) 12-1/2 IN. SLP-LPC (318 mm) SLP Low Profile Cap (Approved for use with PVI-SLP-B only) Figure 12.7 PVI-SLP-B Vent Components Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 74 PVLP-SLP. Contact your dealer to order. Required Wire Harness DESCRIPTION PART NUMBER PVLP-HS PVLP-BEK Heat Shield Brick Kit Figure 12.8 PVLP-SLP Vent Components Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 75 1-1/2 in. 5-1/2 in. 12 in. 220 mm 38 mm 305 mm 146 mm SLP-WS SLP-FS Wall Shield Firestop Ceiling Firestop Figure 12.9 SLP Series Vent Components Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 76 14-7/16 in. 12-5/8 IN. 10-5/8 IN. 59 mm 367 mm (321 mm) (270 mm) SLP-RDS SLP-WT-BK ROOF DECK INSULATION SHIELD Wall Thimble-Black Figure 12.10 SLP Series Vent Components Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 77 271mm 28-1/2 in. 4-1/8 in. 724 mm 105 mm 13-1/2 in. 4-3/4 in. 343 mm 121 mm SLK-SNKD Snorkel Termination Cap Figure 12.11 SLP Series Vent Components Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
  • Page 78 COAXIAL to COLINEAR VENTING LINK-DV30B 768-380A DV-46DVA-GCL Flex Liner Kit Required Stainless Steel Flex Pipe Coaxial/Colinear Appliance Connector DVP-2SL Adapter Figure 12.13 Coaxial to Colinear Vent Components Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...

  • Page 79: Accessories

    Please contact your Majestic dealer with any questions or concerns. For the location of your nearest Majestic dealer, please visit www.majesticproducts.com. Printed in U.S.A. - Copyright 2022 Majestic • QUARTZPLA36IN / QUARTZPLA36IL Installation Manual • 2643-980 Rev. B • 7/22...
